Panasonic POS Workstation JS-950WS Manuale utente

JS-950WS POS Workstation Technical Speciﬁcations

thepowertochange Panasonic ideas for life

JS-950WS Module Structure

Display Size Option

Adjustable display orientation (15” LCD Only)

Landscape (Standard)

Portrait (Option)

15” LCD 12.1” LCD

Main Block Storage Block

Display Block Mainboard

Expansion

Power Supply

LCD Touch Display

Storage

Connectivity

l Processor Intel(R) Celeron D 3.2GHz

l Memory Standard 512MB

Maximum 2GB

l LAN Ethernet 10BASE-T/100BASE-TX

l Mini PCI 1 (Type 3)

l DVD / CD-ROM / FDD Option (USB Interface)

l Built-in Power Supply AC100V-240V, 50/60Hz

l LCD Size 12.1” LCD 800 x 600 (SVGA)

15” LCD 1024 x 768 (XGA)

l LCD Type TFT (Dual Back Light)

l Touch Panel 5-wire Resistive / Capacitive

l Tilt Angle 10 – 80 Degrees

l Storage Type ①3.5” HDD 80GB or more

②2 x Compact Flash Slot

l Interface HDD SATA

Compact Flash 44 pin IDE

l Powered USB (12V) 1

l Powered USB (24V) 1

l Standard USB 4 2 x I/O Panel : 1x Front : 1 x LCD unit

l RS-232 4 2 x Powered : 2 x Standard

l Parallel 1

l Video 1

l LAN 1 RJ45

l Audio 1 x Line-out : 1 x MIC-in

l Cash Drawer 2 1 x 6 pin DIN : 1 x 6 pin Modular

JS-950WS POS Workstation Technical Speciﬁcations

thepowertochange Panasonic ideas for life

Customer Display Option Optional 2nd LCD

POP Display Space

VFD Customer Display

ID Device Option

ID Device Position

MSR Fingerprint

Scanner

Dallas Key

Customer Display Option

ID Device Option

Operating System

Dimensions

l VFD 2 Lines 20 Characters

4 Lines 20 Characters

l LCD 8.4” TFT LCD 800 x 600

l MSR Track 1/2/3 USB Interface

l Fingerprint Scanner USB Interface

l Dallas Key Reader USB Interface

l Windows 2000

l Windows XP

l Windows XP Embedded

l WEPOS

l Windows Vista

l MS-DOS 6.22 English

l Linux

l W Main Body 250 mm / 10”

w/ LCD (12.1”) 320 mm / 12.8” w/o ID Device

w/ LCD (15”) 364 mm / 14.56” w/o ID Device

l D Main Body 282 mm / 11.28”

w/ LCD (12.1”) 317-366 mm / 12.68”-14.64”

w/ LCD (15”) 321-388 mm / 12.84”-15.52”

l H Main Body 351 mm / 14.04”

w/ LCD (12.1”) 387 mm / 15.48”

w/ LCD (15”) 401 mm / 16.04”

Weights

l 12.1” LCD + 3.5” HDD 11.16 Kg / 24.55 lbs

l 15” LCD + 3.5” HDD 12.06 Kg / 26.53 lbs

- Microsoft and Windows are registered trademarks of Microsoft Corporation in the US and other countries.

- Intel and Celeron are trademarks of Intel Corporation.

- All display menus are simulated.

- Weights and dimensions are approximate.

- Speciﬁcations are subject to change without notice.

ID Device can be mounted in two different positions
