Cross line laser

Translation of the original instructions

Αλφάδι laser σταυρού

Μετάφραση των αυθεντικών οδηγιών

λειτουργία

Kreuzlinienlaser

Originalbetriebsanleitung

Before reading, unfold the page containing the illustrations and familiarise

yourself with all functions of the device.

Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na

osnovu toga sa svim funkcijama uređaja.

Pre čitanja rasklopite stranu sa uređajima i u sledećem koraku upoznajte se sa

svim funkcijama uređaja.

Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate

funcţiile aparatului.

Преди да прочетете отворете страницата с фигурите и след това се

запознайте с всички функции на уреда.

Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα ε τι εικόνε και

εξοικειωθείτε ε όλε τι λειτουργίε τη συσκευή.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen

Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

GB/CY Translation of the original instructions Page 4HR Prijevod originalnih uputa za uporabu Stranica 17RS Prevod originalnog uputstva za upotrebu Strana 31RO Traducerea instrucţiunilor de utilizare originale Pagina 45BG Превод на оригиналното ръководство за експлоатация

Страница 59

GR/CY Μετάφραση των αυθεντικών οδηγιών λειτουργία Σελίδα 76DE/AT/CH Originalbetriebsanleitung Seite 91

GB CY

Content

Introduction...................... 4

Intended purpose.............. 5

General description .......... 5

Extent of the delivery ......5

Functional description.....6

Overview......................6

Technical specications ..... 6

Safety information............ 6

Symbols and icons .........6

General notes on safety .... 7

Safety Instructions for

Handling the Laser .........7

Safety Instructions for

Handling Batteries..........7

Initial Operation ............... 9

Inserting/replacing

batteries........................9

Operation ........................ 9

Working with the

automatic leveller...........9

Working without the

automatic leveller.........10

Introduction

Congratulations on the

purchase of your new

device. With it, you have

chosen a high quality pro-

Translation of the

original EC declaration

of conformity................ 106

Working with

the clamp tripod ..........10

Working with the tripod ..11

Cleaning ........................ 11

Storage.......................... 11

Maintenance .................. 11

Transport ....................... 12

Waste disposal and

environmental protection .. 12

Spare parts/

Accessories..................... 13

Troubleshooting.............. 13

Guarantee...................... 14

Repair Service ................ 16

Service-Center ................ 16

Importer......................... 16

duct. During production, this

equipment has been checked

for quality and subjected to

-

tionality of your equipment is

therefore guaranteed.

GB CY

-

tions constitute part of



important information on sa-

fety, use and disposal.

Before using the product,

familiarise yourself with all

of the operating and safety

instructions. Use the product

only as described and for the



this manual safely and in

the event that the product is

passed on, hand over all do-

cuments to the third party.

Intended purpose

-

le for projecting vertical and

horizontal lines.



for indoor use.



used by do-it-yourselfers. It

was not designed for heavy

commercial use.



adults. Children under the

age of 16 may not use the

device except under super-

vision.

-

ble for damage caused by

improper use or incorrect

operation.

General

description

See the front fold-

out page for

illustrations.

Extent of the

delivery

Carefully unpack the ap-

pliance and check that it is

complete. Dispose of the pa-

ckaging material correctly.

•Cross Line Laser

•Clamp tripod

with clamping jaws

•2 x 1.5 V batteries,

AAA size

•Instruction Manual

GB CY

Functional

description

Refer to the following de-

scriptions for a functional

description of the controls.

Overview

1 On/off switch

2 LED ring

3 Battery compartment

4 Levelling stop / transport

securing device

 -

ning

6 Laser

 

8 Retaining screw

9 Clamping nut

10 Clamping jaw

Technical

specifications

Cross Line Laser....PKLL 7 E4

Working range .......... 7 m*

Weight (incl. batteries)........

...................approx. 245 g

Power supply............3 V

......... (2 x AAA 1.5 V cells)

Protection type............ IP20

Self-levelling range...... ± 4°

Levelling accuracy

at 0° to ± 4°...± 0.8 mm/m

from ± 4°.......± 1.0 mm/m

Laser

Wavelength.......... 635 nm

Laser class......................2

Levelling time.. approx. 6 sec

* The working range may be restric-

ted by environmental conditions

(e.g. bright light).

Safety information

Symbols and icons

Symbols on the device:

LASER CLASS 2

EN 60825-1:2014

λ = 635 nm

P0 < 1 mW

Caution! - Laser beam

Do not look into the beam!

Laser class 2

GB CY

•Check the device each

time before using. If da-

maged, have the device

repaired. Do not use the

device if damaged.

•

not in use. Do not leave the

device unsupervised.

•

medical devices, magnetic

data storage media and

magnetically sensitive de-

vices.

Safety Instructions

for Handling the

Laser

•Caution: Leaser beam

– Do not look into the

beam! Laser class 2

•Do not aim the laser beam

at people.

Safety Instructions

for Handling

Batteries

•Ensure at all times that

the batteries are inserted

with the correct polarity

Electrical machines

do not belong with

domestic waste.

Direct voltage

Symbols used in the

instructions:

Hazard symbols

with information

on prevention of perso-

nal injury and property

damage.

Precaution symbol with

information on preven-

tion of harm / damage

Notice symbol with infor-

mation on how to handle

the device properly.

General notes on

safety

•Observe the information

on operation, cleaning,

storage and disposal in the

operating instructions.

•

the device.

GB CY



battery itself.

•Do not short-circuit the bat-

teries.

•Do not charge non-rechar-

geable batteries.

•Do not overcharge batte-

ries!

•Do not mix old and new

batteries or batteries of a

different type or from diffe-

rent manufacturers! Repla-

ce all batteries of a set at

the same time.

•Remove used batteries im-

mediately from the device

and dispose of them cor-

rectly!

•Do not heat the batteries!

•Do not carry out any wel-

ding or soldering work

directly on the batteries!

•Do not take the batteries

apart!

•Do not deform the batteries!

•Do not throw the batteries



•Store the batteries out of

the reach of children.

•Do not allow children to re-

place the batteries without

supervision!

•Do not store the batteries



other sources of heat. Do

not place the battery in di-

rect sunlight and do not use

or store it in motor vehicles

in hot weather.

•Store used batteries in the

original packaging and

keep them away from

metal objects. Do not mix

(up) unpacked batteries!

Otherwise this may cause

the battery to short-circuit,

resulting in damage, burns



•Remove batteries from the

device if this is not going

to be used for a prolonged

period, unless it is to be

used in emergencies!

•NEVER touch batteries

which have leaked without

appropriate protection. If

the leaked liquid comes

into contact with the skin,

you should rinse off this

area of the skin immedia-

tely under running water.

Make sure at all events that

your eyes and mouth do not

come into contact with the

GB CY

liquid. If they do, seek me-

dical advice immediately.

•Clean the battery contacts

and the equivalent contacts

in the device before inser-

ting the batteries.

Initial Operation

Inserting/replacing

batteries

1. Open the battery com-

partment (3).

2. Insert two AAA batteries.

Ensure you place the bat-

teries into the compart-

ment in accordance with

the illustration.

3. Close the battery com-

partment (3).



red when the battery

charge is low.

Operation

Caution! - Laser beam.

Do not look into the



or close your eyes to prevent

looking into the laser beam.

Danger of eye injury!

Working with the

automatic leveller

1. Place the device on a

horizontal solid surface.



be pointing upwards.

Or fasten the device to a

tripod (see “Working with

the clamp tripod” / “Wor-

king with the tripod”).

2. Align the device so it is



3. Switch the device on by

releasing the levelling

stop: position .

 -

minate:

Green: if automatic le-

velling is possible.

Levelling is complete

once the laser lines no

longer move.

Red: if automatic level-

ling is not possible.



and longer be at exact

right-angles to one

another.

GB CY

4. Switch the device off by

locking the levelling stop:

position .

In the event of vibra-

tions, the laser will level

itself automatically; wait until

the laser lines no longer

move.

Working without the

automatic leveller

Caution! - Laser beam.

Do not look into the



or close your eyes to prevent

looking into the laser beam.

Danger of eye injury!

-

luminate permanently

in red when working without

-

ser lines depicted are not le-

velled.

Switching on:





levelling stop (4) must be in

position .

Switching off:



on/off switch (1).

Working with the

clamp tripod



can be used to attach the de-

vice to various objects.

1. Release the clamping



2. Position the clamping

jaws (10) to the desired

location.

 

until fastened.

4. Place the device with

thread (5) onto the tripod

screw (7) and tighten by

hand.

Do not use excessive

force as this may dama-

ge the device.

 

so, release the retaining

screw (8) and move the

device into the desired

position.

Altri manuali per PKLL 7 E4

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Parkside Strumento di misura

Parkside

Parkside PKLL 8 A1 Manuale utente

Parkside

Parkside PZM 2 A1 Manuale utente

Parkside

Parkside PNM 2 A1 Manuale utente

Parkside

Parkside PKLL 7 C3 Manuale utente

Parkside

Parkside 316730_1904 Manuale utente

Parkside

Parkside PMSHM 2 A1 Manuale utente

Parkside

Parkside HG07773A Manuale utente

Parkside

Parkside PLMB 4 A1 Manuale utente

Parkside

Parkside 353255 2007 Manuale utente

Parkside

Parkside PKLL 7 C3 Manuale utente

Parkside

Parkside PKLL 7 C3 Manuale utente

Parkside

Parkside PKLL 7 A1 Manuale utente

Parkside

Parkside PKLL 7 A1 Manuale utente

Parkside

Parkside PWM A1 Manuale utente

Parkside

Parkside PKLL 8 A1 Manuale utente

Parkside

Parkside PLEM 50 A1 Manuale utente

Parkside

Parkside PLDM A1 Manuale utente

Parkside

Parkside PPHM 14 A1 Manuale utente

Parkside

Parkside PKLL 7 A1 Manuale utente

Parkside

Parkside PKLL 8 A2 Manuale utente

Parkside

Parkside PKLL 7 A1 Manuale utente

Parkside

Parkside PWM 4 A1 Manuale utente

Parkside

Parkside PLEM 50 A1 Manuale utente

Parkside

Parkside PLEM 50 B2 Manuale utente

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente
