Algo-Tec™ 6300

INTERACTIVE DIGITAL

ADDRESSABLE FIRE

CONTROL SYSTEM (1-4 LOOPS)

INSTALLATION MANUAL

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 2 of 20 Copyright Protec Fire Detection PLC

Document Revision Details

Issue Modification Detail Author Date

1 Original Issue - 04/07/01

2 Revised Tables PWD 21/11/02

2a Environment Information, Battery Type

Fuse Ratings & Cable Type PWD 17/12/03

2 Rev 2 Added 6000PLUS devices to table 2

Removed loop device PIDs PWD 14/05/10

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 3 of 20 Copyright Protec Fire Detection PLC

N.................................................................................................................................................. 4

1.1 THE 6300 SYSTEM...................................................................................................................................... 4

1.2 ‘6000 SERIES’ LOOP ................................................................................................................................... 4

1.2.1 LOOP SHORT CIRCUIT OR LOOP INTERRUPTION..................................................................... 5

1.2.2 DELAYS TO OUTPUTS ....................................................................................................................... 5

1.2.3 DOUBLE ADDRESSING..................................................................................................................... 5

G.............................................................................................................................................................. 6

2.1 POWER SUPPLY CABLING (REMOTE CHARGER ONLY) ................................................................... 6

2.2 NETWORK /SERIAL CABLING (RS485).................................................................................................. 6

2.3 LOOP CABLING.......................................................................................................................................... 7

2.3.1 GUIDE TO LOOP CABLE CONDUCTOR SIZES (mm2).................................................................. 7

2.4 ALARM CABLING...................................................................................................................................... 8

TABLE 1-CABLING, NUMBER OF CORES .................................................................................................. 8

N.............................................................................................................................. 9

3.1 PANEL CURRENT....................................................................................................................................... 9

3.2 LOOP CURRENT ......................................................................................................................................... 9

TABLE 2–ADDRESSABLE ‘6000’ LOOP EQUIPMENT CURRENT DETAILS ........................................ 10

TABLE 2B –ADDRESSABLE ‘6000’ LOOP EQUIPMENT CURRENT DETAILS CONTINUED................... 11

TABLE 2C –ADDRESSABLE ‘6000’ LOOP EQUIPMENT CURRENT DETAILS CONTINUED................... 12

TABLE 3–ADDRESSABLE LOOP EQUIPMENT WITH AUXILIARY SUPPLY ...................................... 13

CURRENT DETAILS....................................................................................................................................... 13

TABLE 4–NON-ADDRESSABLE LOOP EQUIPMENT CURRENT DETAILS ......................................... 13

E....................................................................................................................... 14

4.1 CONTROL PANEL .................................................................................................................................... 14

4.2 FIELD EQUIPMENT.................................................................................................................................. 15

T...................................................................................................................................................... 16

.................................................................................................................................................... 17

6.1 CONTROL EQUIPMENT .......................................................................................................................... 17

6.2 FIELD EQUIPMENT.................................................................................................................................. 17

6.3 ALARM CIRCUITS ................................................................................................................................... 17

6.4 FIRE STATION OUTPUT.......................................................................................................................... 17

S............................................................................................................ 18

N...................................................................................................................................... 19

A...................................................................................................................................................... 20

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 4 of 20 Copyright Protec Fire Detection PLC

This document describes the methods to be employed when installing and connecting equipment associated with

the PROTEC 6300 FIRE ALARM CONTROL PANEL. The 6300 panel is produced with 1, 2 or 4 loops and this

manual is suitable for all versions.

1.1 THE 6300 SYSTEM

(REFER TO PID 203 – 6300 Example System Diagram)

Each addressable loop device has a unique Serial Number. The 6300 panel communicates with each device by

this Serial Number, and the device replies with an analogue value. This analogue value is interpreted by the

panel to determine the state of the device. The panel is therefore able to track accurately any changes in device

reply values and initiate any necessary actions.

The 6300 panel can drive up to 4 loops, each containing a maximum of 191 devices. No more than 512 detectors

and manual call points, spread across all four loops, may be fitted in order to comply with En54. Each device can

actuate an on-site-programmable set of outputs. 8 internal outputs are available (4 monitored, 2 non monitored

changeover contacts, a monitored 24V fire station output and a non-monitored fault changeover contact). It is

also possible to have an output on any address point using ZONE/ALARM interface units and 16 Way I/O

Boards.

It is possible to network up to 31 panels/repeaters. Networked panels/repeaters use a separate network card

mounted on top of the terminal board. They are connected together using an RS485 loop (refer to PID 194).

If networking is not used then a 4 core communication link (2 data + 2 power) can be used to provide an RS485

serial link to a maximum of 4 repeat panels.

1.2 ‘6000 SERIES’ LOOP

Each 6300 has the capability to communicate with Protec ‘6000 Series’ loops.

Each addressable loop device has a unique Serial Number. The 6300 panel communicates with each device by

this Serial Number and the device replies with an analogue value. This analogue value is interpreted by the panel

to determine the state of the device. The panel is therefore able to track accurately any changes in device reply

values and initiate any necessary actions.

The installer must mark up on the ‘as fit’ drawings the panel number (if more than one), loop number and

address of each device. This information will be required in section 6.2.

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 5 of 20 Copyright Protec Fire Detection PLC

1.2.1 LOOP SHORT CIRCUIT OR LOOP INTERRUPTION

It must not be possible to have a short circuit or interruption in the loop that prevents the indication of a fire

alarm from more than one zone. To comply with this instruction, the installer must fit at least one isolator per

zone. The 6000 series loop has been designed with this in mind and so all addressable sounder bases,

6000/MICCO and 6000/MCP devices have a built-in isolator. Check device literature for other devices with an

isolator. If further isolators are required then loop isolator bases and loop isolation units are available (see table

4).

1.2.2 DELAYS TO OUTPUTS

En54-2:1997 + A1:2006 clause 7.11d states that it must be possible to override the delays and immediately

action the delayed outputs at access level one. Since access level one means that the outer panel door is locked

then if delays are to be used this clause can be met in several ways. If option (3) is chosen then this will affect

the installation.

1. No delays are programmed for manual call points.

2. System programming permits a second activation to cancel delays and immediately activate outputs thus

allowing any manual call point to be pressed upon confirmation of a fire.

3. Programming at least one manual call point to activate all delayed outputs. This should be placed adjacent to

each 6300 panel and its purpose clearly labelled.

1.2.3 DOUBLE ADDRESSING

‘Double Addressing’, where a detection device and a sounder are assigned to the same address, is not supported

by the 6300 panel.

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 6 of 20 Copyright Protec Fire Detection PLC

All external wiring associated with the system must conform to the current I.E.E Regulations and cabling must

conform to the relevant BS specifications. ECA recommended Cable Separation for Electromagnetic

Compatibility in Buildings, must be followed.

All cabling must be fully phased (Identify and mark ends of cables).

Although no connections are to be made to the 6300 panel until the commissioning stage it is important that

cables are left long enough to connect directly to the relevant terminals. To ensure that cable tails are left with

sufficient length all cable tails must be a minimum of 500mm. Locate the termination positions using Product

Information Drawings: -

PID 201 - 6300 TERMINAL BOARD CONNECTIONS

PID 202 - 6300 REPEAT TERMINAL BOARD CONNECTIONS

2.1 POWER SUPPLY CABLING (REMOTE CHARGER ONLY)

If the 6300 panel has an external charger then it will require two separate +24V supplies. This is a requirement of

En54-4 clause 6.4. These two supplies must not be wired in the same fire rated cable. In addition there is a fault

signal ‘SF’ from the charger to the panel and a charger inhibit signal ‘CI’ from the panel to the charger. These

two signals can be combined with one of the +24V supplies into a 4-core fire rated cable.

The maximum length of cable between the charger and the 6300 panel will depend upon the volt drop along the

cable. No more than 3A must be supplied to a panel and no more than two panels must be fed from the same

charger.

2.2 NETWORK / SERIAL CABLING (RS485)

A 6300 panel requires the RS485 network to be wired as a loop. This is because the RS485 network is wired as a

loop in order to continue to indicate a fire alarm from any device on the system should a single break or short

circuit occur in one of the RS485 circuits.

The maximum length of cable between any two 6300 panels on the RS485 network is 1km using a minimum

standard of 1.5mm2fire rated cable. The maximum length of the whole RS485 network loop is 5km.

The maximum length of cable from the 6300 panel to all of the RS485 serial repeat panels is 1km using a

minimum standard of 1.5mm2fire rated cable.

In countries where local standards permit, the network can be wired in ‘Twin Figure 8’ cable but the cable length

will have to be reduced in accordance with the lower conductor size.

EACH OF THE RS485 CIRCUITS MUST BE WIRED IN A SEPARATE PAIR. WHEN THE CABLE HAS A

SCREEN THEN THE SCREEN MUST BE EARTHED AND CONTINUOUS OVER THE CABLE RUN.

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 7 of 20 Copyright Protec Fire Detection PLC

2.3 LOOP CABLING

The main consideration for the loop cable is the loop length. This length must include all sub-loops and spurs.

For example, a loop of 800m with three spurs of 150m must be considered as being 1250m in length.

Notes :- 1. The loop cabling must be wired in fire rated cable. The minimum conductor size is shown

in the tables of section 2.3.1. In countries where local standards permit, the loops can be wired

in ‘Twin Figure 8’ cable but the loop length and load will have to be reduced in accordance

with the lower conductor size.

2. Maximum loop resistance = 16Ωper conductor.

3. It is assumed that devices are evenly spread on the loop. If a large load, eg a number of

sounders, is located at the end of the loop then the volt drop along the cable must be calculated

to ensure that the input voltage to the loop devices remains within the range of 16 to 30V

(peak).

Each address point must be numbered. Sequential address allocation of devices on the loops is not necessary

with a 6300 system but it may prove advantageous for fault finding.

EACH OF THE LOOPS MUST BE WIRED IN A SEPARATE PAIR. WHEN THE CABLE HAS A SCREEN THEN

THE SCREEN MUST BE EARTHED AND CONTINUOUS OVER THE CABLE RUN.

2.3.1 GUIDE TO LOOP CABLE CONDUCTOR SIZES (mm2)

Loop Length (metres)

500 550 600 650 700 750 800 850 900 950 1000

Total

Loop

Load

Alarm

(mA)

50 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

100 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

150 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

200 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

250 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

300 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

350 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

400 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5

450 1.0 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5 1.5 1.5

500 1.0 1.0 1.0 1.0 1.5 1.5 1.5 1.5 1.5 1.5 2.5

550 1.0 1.0 1.0 1.5 1.5 1.5 1.5 1.5 1.5 2.5 2.5

600 1.0 1.0 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5

Loop Length (metres)

1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500

Total

Loop

Load

Alarm

(mA)

50 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

100 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

150 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

200 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

250 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

300 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

350 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

400 1.5 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5

450 1.5 1.5 1.5 1.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5

500 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 N/A

550 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 N/A

600 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 N/A N/A N/A

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 8 of 20 Copyright Protec Fire Detection PLC

2.4 ALARM CABLING

The main consideration for the alarm cable is the length. This length must include all spurs. For example, an

alarm circuit of 800m with three spurs of 150m must be considered as being 1250m in length.

Notes :- 1. The alarm cabling must be wired in a minimum standard of 2.5mm2fire rated cable.

2. If however, the total alarm cabling length is less than 1km, then the alarm circuit may be

wired in a minimum standard of 1.5mm2fire rated cable. In countries where local standards

permit, the alarm circuit can be wired in ‘Twin Figure 8’ cable but the cable length and load

will have to be reduced in accordance with the lower conductor size.

3. The maximum permissible alarm circuit length is limited by volt drop.

EACH OF THE ALARM CIRCUITS MUST BE WIRED IN A SEPARATE PAIR. WHEN THE CABLE HAS A

SCREEN THEN THE SCREEN MUST BE EARTHED AND CONTINUOUS OVER THE CABLE RUN.

TABLE 1 - CABLING, NUMBER OF CORES

CABLE Number of Cores

1. Supply 230 volts 50Hz

2. Network Data

Repeat Panel Data

3. Loop Circuit

Alarm Circuit

4. Power Pair For: -

Zone/Alarm Interface Units

I/O Interface Units

Repeat Panel Power Supply

Remote Chargers Only

5. 24V Supply circuit 1

24V Supply circuit 2

SF & CI Signals

2 (per loop)

2 (per circuit)

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 9 of 20 Copyright Protec Fire Detection PLC

It is necessary to calculate current consumption figures for the system in standby (mains fail) and alarm

conditions in order to select the correct battery capacity.

3.1 PANEL CURRENT

Details of panel currents for standby and alarm are shown in the 6300 specification later in this manual.

3.2 LOOP CURRENT

Figures for the loop device current for battery capacity calculations are contained in tables 2, 3 and 4. These

provide details of the quiescent and alarm currents of both the addressable and non-addressable loop devices.

Note: -

1. Loop isolators, devices that isolate sections of the loop if short circuit wiring faults occur, are available

as separate units. Some ‘6000 series’ devices contain an isolator. Check device literature.

2. When using Zone interfaces the current per detector / sounder must be added to the current requirement

of the Interface Units (refer to note 2 of table 3).

3. The alarm loop current figures may differ from the figures quoted in other Protec literature. The figures

here assume a limit on the number of devices lighting their fire led so this reduced led current is

averaged across all the loop devices.

www.acornfiresecurity.com

93-509-09 - Issue 2 Rev 2 Page 10 of 20 Copyright Protec Fire Detection PLC

TABLE 2 – ADDRESSABLE ‘6000’ LOOP EQUIPMENT CURRENT DETAILS

ADDRESSABLE DEVICES QUIESCENT

LOOP CURRENT

(mA)

ALARM

LOOP CURRENT

(mA)

OPTICAL SMOKE DETECTOR

6000/OP 0.35 0.55

OPTICAL HEAT SMOKE DETECTOR

6000/OPHT 0.35 0.55

TEMPERATURE DETECTOR

6000/TEMP 0.35 0.55

OPTICAL HEAT CO SMOKE DETECTOR

6000/OP/HT/CO 0.45 0.65

CO HEAT DETECTOR

6000/HT/CO 0.35 0.55

IONISATION SMOKE DETECTOR

6000/ION

0.52 0.82

BREAK GLASS

6000/MCP 0.5 0.85

SOUNDER BASE

6000/ASB2 0.6 6

SOUNDER BASE WITH FLASHING

XENON BEACON - 6000/ASBEA2 0.6 10

RED SYMPHONY SOUNDER

6000/SYM2R 0.5 5

SOUNDER

6000/SSR2 0.65 5

SOUNDER

6000/SRZ2 0.5 20

BEACON

6000/PVR2 0.5 45 (Xenon)

5 Av / 12 pk (LED)

SOUNDER XENON BEACON

6000/SRZ2/PVR 0.5 75

MONITORED INPUT CLEAN CONTACT

OUTPUT BOARD - 6000/MICCO 1.3 5

CLEAN CONTACT OUTPUT BOARD

6000/CCO 0.6 10

MONITORED INPUT BOARD

6000/MIP 0.65 4

MONITORED INPUT WITH CLEAN

CONTACT OUTPUT - 6000/MIPCCO 0.7 15

www.acornfiresecurity.com

Altri manuali per Algo-Tec 6300

Indice

Altri manuali Pro-tec Sistema di controllo

Pro-tec

Pro-tec Algo-Tec 6500 Manuale utente

Pro-tec

Pro-tec Algo-Tec 6500 Guida rapida

Pro-tec

Pro-tec Algo-Tec 6500 Guida rapida

Pro-tec

Pro-tec Algo-Tec 6400 Manuale dell'operatore

Manuali Sistema di controllo popolari di altre marche

Pentair Pool Products

Pentair Pool Products Compool Manuale utente

ComfortNET

ComfortNET CTK04 Manuale utente

Fireye

Fireye InSight II 95DSS3 Manuale utente

CAME

CAME G3000 Manuale utente

Idemia

Idemia MorphoAccess VP MD Manuale utente

Axis

Axis P1445-LE-3 Manuale utente

HEIDENHAIN

HEIDENHAIN TNC 150 B Manuale utente

CNC-Step

CNC-Step High-Z T-Series Manuale utente

Doosan

Doosan DVF Series Manuale utente

Honeywell

Honeywell KAP 140 Manuale utente

Honeywell

Honeywell vk41 series Manuale utente

AirBench

AirBench FPW Guida all'installazione

Cypress

Cypress HHR-3160 Manuale utente

CAME

CAME GLT40AOS Manuale utente

Zonex

Zonex GEN II -VVT Guida utente

Altronics

Altronics K 9650 Manuale utente

micro-trak

micro-trak RoadMaster Manuale utente

micro-trak

micro-trak Calc-An-Acre II Manuale utente
