Rexing M2 Manuale utente

User Manual

BestBuy Edition

The information in this manual is subject to change without notice.

www.rexingusa.com

082023REV2

& Choose Your

FREE Gift!

Scan The QR To Activate &

Select Your Free Gift

Activate within 30 days of purchase to

claim your free gift and extend your

limited 12-month warranty to 18 months.

Activate Your

18-Month

Warranty

https://www.rexingusa.com/productreg/

Notice

The user menu is to be set up in non-video mode. If the device is in

video mode, please proceed only after stopping the video recording.

Memory Card: Using a new MicroSD card always requires formatting it

to your device. Regularly clear the memory card, as continuous video

recording for an extended period of time may produce some

protected files that are not subject to long-term protection (these files

may not be overwritten during loop recording) and some storage

fragments, which must be cleared regularly in order to save usable

storage space.

On-board Charger: The standard input voltage is configured to 12V. If a

voltage greater than 12V, contact your dealer or our customer care via

[email protected] to replace it with a replacement charger.

The features described in this operation manual are available for all

products of the same type. The device you buy may be a model with

optional or additional functions. Menu operations may vary. Please refer

to your actual product.

Pay attention to the mounting position, which must not interfere with

driving or lead to unsafe driving operation. Make sure it is safely

secured.

A standard 6-meter cable is provided for the rearview camera. It is not

recommended to install this type of dash cam if your car is beyond the

connection cable range.

The battery (module or pack) must not be expose to an

overheat environment such as direct sunlight or flame.

Never remove, strike, or squeeze the battery or put it in fire.

Stop using the battery if it is ballooned, warped, leaking, or

shows any other visible signs of damage.

Warning

We hope you love your new products as much as we do. If you need

assistance, or have any suggestions to improve it, please contact us.

Our support team will respond you as soon as possible.

Always a surprise in Rexing.

• https://www.facebook.com/rexingusa/

• https://www.instagram.com/rexingdashcam/

• https://www.rexingusa.com/support/registration/

Overview

Thank you for choosing REXING!

Check us out here.

Facebook Instagram Site Product Support

[email protected]

(877) 740-8004

What’s in the box?

1234

9 10

6 7 8

1. Rexing M2 Smart Mirror Dash camera

2. Rexing rear camera

3. GPS Logger

4. Cable Management Tool

5. In-car power cable (12ft)

6. Rear camera cable

7. User Manual

8. Hardwire Kit

9. Warning sticker

10. 2 Sets of Rubber Mounting Strap

User Manual

Theinformation in this manual is subject to change without notice.

www.rexingusa.com

082023REV2

USB Port

Rubber Mounting Strap

Rearview Camera Port

MicroSD Card Slot

GPS Port

Display/TouchScreen

Front Camera

Reset Key Pinhole

Speaker

MIC Pinhole

Power Key

Camera Overview

Designation

Power Button

Display /

Touch Screen

Reset Key

Front Camera

Rear camera plug-in port.

Charging port

USB Port

GPS Logger is included in the package.

GPS Port

A slot for inserting a MicroSD card

Micro SD Card Slot

Description of Functions

This button controls the device's power. With the

device connected to an external power source,

pressing this button will turn it on or off. Additionally,

a quick press will toggle the screen's backlight.

The touch screen is your main interface for

accessing the device's features. Tap on the

corresponding icons for functions, and perform

swipes for certain actions.

Use this key if the device becomes unresponsive. A

quick press will reset the device and restore normal

operations.

This camera records what's happening in front of

your vehicle.

• Press the Power Button to turn On or Off the screen

• Press and hold the Power Button for 3 seconds to

turn the device on or off

Rear Camera Port

NOTE

Screen Icons

12 3

13 1215 14 11 10 9

4 5 6 7 8

Note

• If the screen is off, tap the screen to turn it back on.

• If the icons on the screen are hidden, tap the screen to display the icons.

15:58

08-04-2023Fri

00:29

Recording Time

Screen Brightness

Video Mode

G Sensor On

Memory Card Inserted

Battery Charging

GPS Signal

Parking Monitor

Toggle Front/Rear Camera

10.

11.

12.

13.

14.

15.

Mic on/off

Lock/Unlock a Video

Take a Photo

Video Recording

Back Button

Home Button

Get Started

Memory Card Installation

Note

Step 1. Insert a Memory Card

You will need to insert amemory card beforebeginning recording. Pushthe

memory card into the slot until it locks in place.

The M2 dash cam accepts memory cards withamaximum capacity of

256GB. Dependingon the memory card’s manufacturer and type, some

cards may not be compatible withthe dash cam.Using an incompatiblecard

may damage the device, the memory card, or corrupt the data stored on it.

For reliableoperation, use a Class 10 memory card withacapacity of at least

32GB.

DO NOT insert or remove a memory card while the device is in operation.

It is recommended that you reformat the memory card every timeimages

are transferred to the computer, or at least once a month.

Reformattingamemory card keeps important elements of data and also a

cleaned file structure which helps to prevent error messages and missing

images. Reformatting also restores the memory card, whichcan help prevent

it from becomingcorrupted.
