Rexing V1P Manuale utente
V1P
Quick Start Guide
V1P クイックスタートガイド
Guide de démarrage rapide de la V1P
Guida di avvio rapido V1P
Guía de inicio rápido V1P
V1P Schnellstartanleitung
FR
IT
DE
SP
JP
2
Table of Contents
English
Overview
What’s in the Box
Camera Overview
Installation
Basic Operation
日本語
概説
本製品の同梱物
カメラの概説
画面のアイコン
基本操作
Français
Aperçu
Que contient la Boîte
Aperçu de la Caméra
Installation
Opération de Base
Italiano
Descrizione
Nella Confezione
Descrizione Telecamera
Installazione
Funzionamento Base
page
4
5
6
8
13
20
21
22
24
29
36
37
38
40
45
52
53
54
56
61
3
Español
Visión General
Qué hay en la Caja
Resumen de la Cámara
Instalación
Operación Básica
Deutsch
Übersicht
Verpackungsinhalt
Kamera übersicht
Installation
Grundbedienung
68
69
70
72
77
84
85
86
88
93
page
4
1. Overview
Thank you for choosing REXING! We hope you love your new
product as much as we do.
If you need assistance, or have any suggestions to improve it,
call us at (203) 800-4466. Our support team will respond you as
soon as possible.
Always a surprise in Rexing. Check us out here.
https://www.facebook.com/rexingusa/
https://www.instagram.com/rexingdashcam/
https://www.rexingusa.com/support/registration/
Facebook Instagram Site
5
1. Overview
1. Rexing V1P Dash Cam
2. Car Charger
3. Mount Plate & 3M Adhesive
4. Mini-USB Cable
5. Rear Camera
6. Cable Management Tool
7. Cable Clips©
8. V1P Quick Start Guide
9. Safety Guide
1.
6.
7. 8. 9.
2. 3. 4.
2. What’s in the box
5.
6
3. Camera Overview
1. Micro SD Card Slot
2. Power Button
3. Reset Button
4. Menu Button
5. Mode Button
6. REC (Record) Button *
7. OK (Con irm) Button **
8. MIC (Microphone) Button ***
9. Screen Button
10. Mini-USB Port
11. GPS Logger Port
12. Rear Camera Port
13. Lens Angle Adjustment
* The Camera is recording when the LED is ashing red.
** The Camera is recording when the LED is ashing red. The device charging
or powered on when the LED is solid blue.
*** The device is charging or powered on when the LED is solid blue.
1.
10.
11.
5. 6. 8.
7.
9.
2.
3.
4.
12.
13.
7
Screen Icons
GPS Signal (not connected)
GPS Signal (locked)
Recording Time
(Current Clip)
Video Resolution
Parking Mode
(On)
G-Sensor
Sensitivity Level
Memory Card
(Inserted)
Battery Charging
WDR Mode (On)
Recording (On)
Recording
Standby Status
Loop Recording
Time
Exposure Value
MIC (O)
MIC (On)
Current Date
(DD/MM/YYY)
Time
(24H)
Plate Number
8
4. Installation
Step 1: Install the Dash Cam
Place the 3M tape on the Mount and properly orient the
Mount square to the roof and hood line of the vehicle.
Important! Ensure the T-interlock on the Mount is oriented in
the correct direction.
Firmly press the Mount onto the windshield. Wait at least 20
minutes before mounting the camera.
Orientation mount as shown
Step 2: Insert the Memory Card
The Rexing V1P accepts [Class 10/ UHS-1 or higher] Micro
SD memory cards up to 256GB. You will need to insert a
memory card before you can begin recording. Before
inserting or removing a memory card, first ensure
you’ve powered down the device.
Gently push the memory card in until you hear a click, and allow
the spring release to push the card out.
9
Step 3: Power the Camera and Format the
Memory Card
Power the camera by connecting the charger to the car
cigarette lighter and camera.
To ensure the V1P records to your memory card properly
and without error. Before you start using a new memory
card, you must format the card within the camera
using the format function. Always backup important data
stored on the memory card before formatting.
To format the memory card, make sure you have inserted
your memory card, then turn on the device by connecting
to a power source. Press REC to stop recording. Then press
the MENU button twice to enter the System Setup Menu.
Use the REC and MIC buttons and go to the Format setting.
Press the OK Button to con irm the selection.
Press the Power button
to turn the power o
10
Press the Menu button twice
Press the OK button to
conrm formatting
the card
Connect Mini-
USB to the
camera
Blue LED
lights indicate
the device is
charging or powered
You may now disconnect from power. The camera will shut
down after 3 seconds. The camera should begin recording
automatically the next time it is powered on.
