SP-5 Service Manual 3
Display
Window
Set
Temperature
Control
Resets Timer
to change
cook time
OFF
Bird
Symbol
Program
Selector
Switch
JOG POSITION
(for wheel rotation
to load and
unload)
Starts Timer
after switching
to Cook
Set Cooking
Time Control
OPERATING INSTRUCTIONS
For units manufactured before Serial Number
SP0002237
1. For initial start-up, set clock for proper time of day.
(Press F while turning G)
2. Load rotisserie with product.
3. Set required cooking temperature (Press B while
turning G). When B is released, actual oven
temperature will appear briefly until set temperature
is reached.
4. FOR AUTOMATIC COOKING CYCLE: Set required
cooking time. Allow approximately 20 minutes
preheat time (Press C while turning G). Start
cooking cycle by turning SELECTOR A to “Bird
Symbol.” Press D to display the hour that cooking
will be completed. At that time, the buzzer will
sound and the rotisserie will shut off.
FOR MANUAL COOKING CYCLE: Set required
cooking time. Allow approximately 20 minutes
preheat time (Preheat E while turning G). Start
cooking time is completed, buzzer will sound and the
rotisserie must be manually turned off.
5. Once cooking time is completed, turn SELECTOR A
to “Jog Mode” for holding.
6. The buzzer can be turned off by pressing E.
7. To stop unit at any time, turn SELECTOR A to “Off
Mode.”
OPERATING INSTRUCTIONS
For units manufactured after Serial Number SP0002236
1. Load rotisserie with product. Set selector switch to
“Off Mode.
2. Set required cooking temperature by turning the
TEMP ADJUST knob to the right to raise
temperature or left to lower it (the temperature
setting will appear on the right side of the display
window and will flash on and off until the oven
reaches the set point).
3. Set required cooking time by turning the TIME
ADJUST know to the right to increase time or to the
left to lower it. Allow approximately 20 minutes
preheat time (the time setting will appear as minutes
and hours on the display).
4. Start cooking by turning selector switch to the “Bird
Symbol” and press TIMER START (the two dots
between hours and minutes will flash on and off
when timer is running). When cooking time is
completed, buzzer will sound.
5. After cooking is completed, turn the selector to “Off
Mode” to stop the rotisserie, or to “Jog Mode” for
holding the product.
6. The buzzer can be turned off by pressing TIMER
RESET.
7. To stop unit at any time, turn selector switch to
“Off mode.”
