SCHUBERTH SC2 Manuale utente

SC2

MOTORCYCLE BLUETOOTH®

COMMUNICATION SYSTEM

WITH MESH INTERCOM™

USER’S GUIDE

ENGLISH

Version 1.0.1

TABLE OF CONTENTS

1. ABOUT THE SC2 6

1.1 Product Details 6

1.1.1 SC2 6

1.1.2 SC2 Remote Control 6

1.2 Package Contents 7

1.3 Optional Accessories 7

2. INSTALLING THE HEADSET ON YOUR HELMET 8

2.1 Installing the SC2 Remote Control 8

2.2 Installing the SC2 8

2.3 Removing the SC2 10

2.4 Installing the Microphone 11

3. GETTING STARTED 12

3.1 Legend 12

3.2 Downloadable Software 12

3.2.1 SCHUBERTH SC2 App 12

3.2.2 SCHUBERTH Device Manager 12

3.3 Powering On and O 13

3.3.1 SC2 Powering On and O 13

3.3.2 SC2 Remote Control Powering On and O 13

3.4 Charging the SC2 14

3.5 Replacing the Battery 14

3.6 Checking the Battery Level 15

3.7 Volume Adjustment 15

4. PAIRING THE HEADSET WITH OTHER

BLUETOOTH DEVICES 16

4.1 Phone Pairing 16

4.2 Second Mobile Phone Pairing - Second Mobile

Phone, GPS, and SR10 17

TABLE OF CONTENTS CONTINUED

4.3 Advanced Selective Pairing: Hands-Free or

A2DP Stereo 18

4.3.1 Phone Selective Pairing - Hands-Free Prole 18

4.3.2 Media Selective Pairing - A2DP Prole 18

4.4 GPS Pairing 19

5. MOBILE PHONE USAGE 20

5.1 Making and Answering Calls 20

5.2 Siri and Google Assistant 20

5.3 Speed Dialing 21

5.3.1 Assigning Speed Dial Presets 21

5.3.2 Using Speed Dial Presets 21

6. STEREO MUSIC 22

6.1 Bluetooth Stereo Music 22

6.2 Music Sharing 22

6.2.1 Bluetooth Intercom Music Sharing 23

6.2.2 Mesh Intercom Music Sharing 23

7. MESH INTERCOM 24

7.1 What is Mesh Intercom? 24

7.1.1 Open Mesh 25

7.1.2 Group Mesh 26

7.2 Starting Mesh Intercom 26

7.3 Using the Mesh in Open Mesh 27

7.3.1 Channel Setting (Default: Channel 1) 27

7.4 Using Mesh in Group Mesh 28

7.4.1 Creating a Group Mesh 28

7.4.2 Joining an Existing Group Mesh 29

7.5 Enable/Disable Mic (Default: Enable) 30

7.6 Toggling Open Mesh/Group Mesh 30

7.7 Reset Mesh 30

TABLE OF CONTENTS CONTINUED

8. BLUETOOTH INTERCOM 31

8.1 Intercom Pairing 31

8.1.1 Using the Smart Intercom Pairing (SIP) 31

8.1.2 Using the Button 32

8.2 Last-Come, First-Served 32

8.3 Two-Way Intercom 33

8.4 Multi-Way Intercom 34

8.4.1 Starting a Three-Way Intercom Conference 34

8.4.2 Starting a Four-Way Intercom Conference 35

8.4.3 Ending Multi-Way Intercom 35

8.5 Three-Way Conference Phone Call with

Intercom Users 36

8.6 Group Intercom 37

8.7 Mesh Intercom Conference with Bluetooth

Intercom Participant 37

8.8 Universal Intercom 39

8.9 Mesh Intercom Conference with Two-way

Universal Intercom Participant 40

9. USING THE FM RADIO 41

9.1 FM Radio On/O 41

9.2 Seek and Save Radio Stations 41

9.3 Scan and Save Radio Stations 42

9.4 Navigating Preset Stations 43

9.5 Temporary Station Preset 43

9.6 Region Selection 43

10. VOICE COMMAND 44

11. FUNCTION PRIORITY 46

11.1 Function Priority 46

TABLE OF CONTENTS CONTINUED

12. CONFIGURATION SETTING 47

12.1 Headset Conguration Setting 47

12.1.1 Delete All Pairings 47

12.2 Software Conguration Setting 48

12.2.1 Speed Dial 48

12.2.2 Headset Language 48

12.2.3 Audio Equalizer (Default: O) 48

12.2.4 VOX Phone (Default: Enable) 48

12.2.5 VOX Intercom (Default: Disable) 48

12.2.6 VOX Sensitivity (Default: 3) 49

12.2.7 Bluetooth Intercom Audio Multitasking

(Default: Disabled) 49

12.2.8 Intercom-Audio Overlay Sensitivity (Default: 3) 49

12.2.9 Audio Overlay Volume Management

(Default: Disable) 49

12.2.10 HD Intercom (Default: Enable) 50

12.2.11 HD Voice (Default: Enable) 50

12.2.12 Smart Volume Control (Default: Disable) 50

12.2.13 Sidetone (Default: Disable) 50

12.2.14 Voice Prompt (Default: Enable) 51

12.2.15 RDS AF Setting (Default: Disable) 51

12.2.16 FM Station Guide (Default: Enable) 51

12.2.17 Advanced Noise Control™ (Default: Enable) 51

13. TROUBLESHOOTING 52

13.1 SC2 Factory Reset 52

13.2 SC2 Remote Control Factory Reset 52

13.3 Remote Control Pairing 52

13.4 SC2 Fault Reset 53

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 6

1. ABOUT THE SC2

1.1 Product Details

1.1.1 SC2

DC Power Charging &

Firmware Upgrade Port

Multi-function Button

Status LED

1.1.2 SC2 Remote Control

(+) Button

(-) Button

Center Button

Mesh Intercom Button

Battery Slot

Battery Release Hole

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 7

1 ABOUT THE SC2

1.2 Package Contents

SC2 SC2 Remote Control SC2 HD Boom

Microphone

USB-C Power &

Data Cable Coin Battery Foam cover for SC2 HD

Boom Microphone (2)

1.3 Optional Accessories

Contact SCHUBERTH or your authorized dealer for accessories.

Part Number Spare Part

9049100370

SC2 HD Boom Microphone with foam cover

9049100372

Foam cover for SC2 HD Boom Microphone

9049100374

Remote Control for SC2

9049100375

USB-C Power & Data Cable

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 8

2. INSTALLING THE HEADSET ON

YOUR HELMET

2.1 Installing the SC2 Remote Control

1. Remove the cover for the SC2 Remote Control from your helmet.

Cover for the SC2 Remote Control

2. Slide and insert the SC2 Remote Control onto your helmet.

2.2 Installing the SC2

1. Remove the SC2 cover from the helmet by lifting it up with the SC2

Remote Control cover.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 9

2 INSTALLING THE HEADSET ON YOUR HELMET

2. Pull out the antenna cable retainer from its original position, and pull out the

antenna cables from the upper gap in the space. Then, connect the SC2’s

antenna cables and the helmet’s antenna cables correctly.

Click

Antenna

cable

retainer

3. Put the antenna cable retainer back into its original position, and put the

connected cables into the upper gap in the space.

Note: Make sure that the antenna cable retainer and the connected cables

are positioned correctly before installing the SC2. If not, the cables may be

damaged or interference may occur.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 10

2 INSTALLING THE HEADSET ON YOUR HELMET

4. Install the SC2 into the helmet.

Click

2.3 Removing the SC2

1. Remove the installed SC2 from the helmet by lifting it up with the SC2

Remote Control cover.

2. Pull the antenna cable retainer out from its original position, and pull out the

connected cables from the upper gap in the space. Then, disconnect the

cables correctly.

Note: When you need to un-plug the connectors, please wiggle and pull

them. It will help the connector connection be released more easily.
