BTP-R580 User’s Manual
- 5 -
2 Main Specification
2.1 Technical Specification
Item Parameter
Print mode Thermal line
Resolution 203DPI
Print speed 230mm/s (Max.)
Print width Max. 80mm
Paper type Continuous paper/Marked paper
Barcode UPC-A, UPC-E, EAN-8, EAN-13 , Coda bar, Code39, ITF , Code128,
Code93, Pdf417
Character Standard ASCII(12×24), compressed ASCII(9×17)
GB2312, GB18030, Korean, Japanese, Traditional Chinese
Character enlargement All fonts can be enlarged vertically and horizontally up to 6 times
Character rotation 0°, 90°, 180°, 270°
Paper near end Photo sensor
Paper end Photo sensor
Printer top cover position Microswitch
Printhead overheating protection Thermal resistor
Download bitmap Direct bitmap print
Graphics 8 figures maximum download to a
total bitmap buffer of 12KB
Support bitmap mode and can realize
fast bitmap printing
Interface Standard parallel, RS232 (25 pins), RS485, USB, Ethernet or WLAN optional
Cash drawer 1-2 cash drawers
Memory RAM: 2MB, FLASH: 2 MB /4MB
Power AC 100-220V, 50/60Hz
Printhead life ≥150Km (with reference paper)
Operating temperature and
humidity 5～45℃, 20% ～90% RH (40°C)
Storage temperature and
humidity -40～55 ,℃20%～93% (40℃)
Dimension 147(W)×205(D)×147(H) mm
2.2 Cutter Specification
Item parameter Note
Cutter type Slide cutter (Guillotine type)
Cutting time 600ms The time that one cut takes
Cutting interval 2s 30 times/min. (Max.)
Paper type 0.06～0.1mm Thermal paper or paper with the
same thickness
Operation voltage 24VDC
Max. dynamic curren 1.2A 24VDC
Cutter lifetime 2,000,000 cuts (reference paper with
thickness of 0.06 mm) Full or partial cuts
zFull cut: Cut off the paper completely；
zPartial cut: 2 mm paper left in middle
