Sonos Five Manuale utente

Five

Overview The high-fidelity speaker for superior

sound—

Versatile design with smart orientation sensing. Pair two

speakers horizontally and Five automatically separates

the left and right channels for impressive stereo sound.

When paired vertically, each smartly adjusts to mono for

more detailed stereo separation and an even wider

soundstage.

Touch controls on the speaker let you adjust volume, play

and pause, or skip through songs.

Use the line-in port to connect your turntable or another

device—simple control with the Sonos app or Apple

AirPlay 2.

Pair two Fives for left-right stereo sound or use two Fives

as rear surrounds for your home theater.

Control your Sonos system with the Sonos app (for

Android and iOS).

See Setup when you’re ready to add Five to your Sonos

system.

Controls and lights

Button Control Description

Volume control Touch and hold to quickly

change the volume.

Note: You can also use

the Sonos app to adjust

volume.

Play/Pause

Next/Previous song

Note: You can’t skip

forward or go back when

listening to a radio station.

Volume up (right)

Volume down (left)

Press once to play or

pause audio.

Press and hold to add

the audio that's playing

in another room.

Swipe right to skip to

the next song.

Swipe left to go to the

previous song.

Button Control Description

Status light

Displays the product's

connection to WiFi,

indicates when the volume

is muted, and signals

errors. Learn more

Note: If you don’t want to allow playback or volume adjustments using the speaker touch

controls, you can disable them in the room’s settings.

Connector panel

1Ethernet port Use an Ethernet cable if you want to

connect to a router, computer, or

network-attached storage (NAS)

device (optional).

2Stereo audio in (3.5mm / 1/8") Use to connect an external audio

device, like a turntable or CD player.

3Join button Press to connect to your Sonos

system during setup.

4AC power (mains) input Use only the supplied power cord

(using a third-party power cord will

void your warranty).

Note: Insert the power cord firmly

until it is flush with the bottom of the

speaker.

Select a location

You can put your speaker just about anywhere. For maximum performance, here's a few

guidelines:

Set up stereo pair

Pair two Sonos speakers in the same room for an even wider, stereo experience. One

speaker serves as the left channel and one serves as the right channel.

Note: The Sonos speakers in a stereo pair must be the same type.

1. Place the speakers 8 to 10 feet apart. Your favorite listening position should be 8 to 12

feet from the paired speakers—less distance increases bass, more distance improves

stereo imaging.

2. Go to > System.

3. Select one of the speakers you want to use in the stereo pair, then choose Set Up Stereo

Pair to get started.

Learn more

Five is a substantial and powerful speaker and should be placed on a flat surface that is

robust and durable enough to properly support it. Make sure Five’s rubber feet sit

completely on the flat surface.

Allow at least 2" perimeter all around Five, including its power cord.

For a single Five speaker, we recommend positioning the speaker horizontally to enable

stereo sound.

Place Five across the room from where you’ll be listening (at or close to your ear height

for best results).

For stereo pair placement information, see Set up stereo pair.

Five is humidity resistant so you can use it in the bathroom; however it is not water

resistant, so don’t position it near water or leave it outside during a rain storm.

Set up surrounds

It’s easy to turn two Sonos speakers (same model), or a Sonos Amp and your favorite non-

Sonos speakers, into separate right and left channels for your home theater.

1. Place each surround speaker about 10 ft from your favorite listening position, angling

them toward the seating area.

2. Go to > System.

3. Select a room with a soundbar and choose Add Surrounds to get started.

Note: If you group the rooms or create a stereo pair instead, you won't have surround sound.

Learn more

Surround audio settings

During setup, surround sound is optimized for your room. These settings are adjustable:

Surrounds Turn surround sound On or Off.

TV Level Adjust surround volume for TV audio.

Music Level Adjust surround volume for music.

Music Playback

Ambient (subtle) or Full (louder, full

range). Doesn't apply to Dolby Atmos

Music playback.

Line-in

Connect an audio device, like a projector, CD player, or turntable (with a built-in phono

preamp), to any Sonos product that has a line-in port (Era 300, Era 100, Amp, Port, or Five).

Then go to > Line-In to select the source and start playback.

Note: Era 300 and Era 100 require a Sonos Line-In or Combo Adapter (sold separately).

Other products may require a different type of line-in adapter depending on your audio source.

Learn more

Product settings

You can customize Sonos products for your surroundings. Go to > System and select a

product.

Room Name If you move your speaker to a new room,

you can change its name in Settings.

Turn off WiFi

(not available for Sonos Era 100, Era 300, or

portable products)

You can turn off your speaker’s WiFi when

it’s connected to your network with an

Ethernet cable. This reduces power

consumption and can improve

connectivity for wired speakers.

For products like Amp and Port, turning off

WiFi can reduce the internal temperature

when they’re placed in a rack or stacked.

Learn more

Note: WiFi is turned off for Era 100 and

Era 300 when you connect a Sonos

Combo Adapter using the Ethernet cable.

Sonos products ship with preset

equalization settings. You can change the

sound settings (bass, treble, or loudness)

to suit your personal preferences. Learn

Trueplay

Trueplay adapts the sound for your

surroundings and content. Portable

products can tune themselves

automatically. Learn more

Volume Limit You can set a maximum volume for each

room. Learn more

Status Light

Displays the speaker’s connection to WiFi,

indicates when the volume is muted, and

signals errors. Learn more

Note: If the light is distracting, you can

turn it off in Settings.

Touch Controls

You can disable the touch control on your

speaker. You may want to do this to

prevent a child or curious pet from

accidentally adjusting playback or volume.

Learn more

Battery Saver

(portable products only)

To save battery life, you can set your

portable speaker to power off

automatically instead of going to sleep. It

won't appear in the Sonos app until it’s

powered back on.
