SY-V6BE+

Quick Start Guide

Introduction

Congratulationsonyourpurchaseofthe

SY-V6BE+

Mainboard.ThisQuickStartGuide

describesthestepsforinstallingandsettingupyournewmainboard.

Thisguideisdesignedforalluserstoprovidethebasicstepsofmainboardsettingand

operation.Forfurtherinformation, pleasereferto SY-V6BE+MainboardUser'sGuide and

TechnicalReferenceonlinemanualincludedontheCD-ROMpackedwithyourmainboard.

Unpacking

*Ifyourboardcomeswithadriverdiscandapapermanual,theQuickStartGuideandtheCD-ROMarenotincludedinthepackage.

Whenunpackingthemainboard,checkforthefollowingitems:

TheSY-V6BE+AGP/PCIMainboard

ThisQuickStartGuide

TheInstallation CD-ROM

TheCPURetentionSet

OneIDEDeviceFlatCable

OneFloppyDiskDriveFlatCable

SY-V6BE+ Quick Start Guide

Introduction

SY-V6BE+ Mainboard Layout

Key Features

SupportsIntelPentium

II processor (233-

500MHz) & Celeron

processors(266-

400MHz)

Auto-detect CPU voltage

PC98,ACPI, Ultra DMA/33MHz

Power-on by modem, alarm or keyboard

SOYO COMBO Setup

SupportsWake-On-LAN(WOL)

Supports onboard hardware monitoring

and includes Hardware Doctor™utility

(optional)

S1x32-bitAGP slot

4 x 32-bit bus mastering PCI slots

2 x USB ports onboard

1 x IrDA port

Supportsmultiple-bootfunction

DMI utility

COM 1

COM 2

PRT

USB 1USB 2

PS/2 KB

Connector

PS/2 Mouse

Connector JP10

PCI Slot #1

PCI Slot #2

PCI Slot #3

PCI Slot #4

ISA Slot #2

ISA Slot #1

ISA Slot #3

JP5

JP44

IR1

CPUFAN

Ultra

I/O Chipset

CHAFAN

IDE 1

IDE 2

FDC

Slot 1 for

Pentium

IIProcessor

AGP Slot

ATX

Power

DIMM 1

DIMM 2

DIMM 3

Speaker

Keylock

Power

LED

Reset

PWRBT

Turbo

LED

HDD LED

Wake on

LAN

Hardware

Monitoring

Winbond

W83781D

SW1

3V Lithium

Battery

BIOS Flash

SY-V6BE+

Quick Start Guide

Hardware

Installation

Toavoiddamagetoyourmainboard,followthesesimpleruleswhile

handlingthisequipment:

Beforehandlingthemainboard,groundyourselfbygraspinganunpaintedportionof

thesystem'smetalchassis.

Removethemainboardfromitsanti-staticpackaging.Holditbytheedgesandavoid

touchingitscomponents.

Checkthemainboardfordamage.Ifanychipappearsloose,presscarefullytoseatit

firmlyinitssocket.

Followthedirectionsinthissectiondesignedtoguideyouthroughaquickandcorrect

installationofyournew

SY-V6BE+

Mainboard.Fordetailedinformation,pleasereferto SY-

V6BE+MainboardUser'sguideandTechnicalReferenceonlinemanualincludedonthe

CD-ROMpackedwithyourmainboard.

PREPARATIONS

Gatherandprepareallthenecessaryhardwareequipmenttocompletetheinstallation

successfully:

Pentium

processorwithbuilt-inCPUcoolingfan(boxedtype)

SDRAMmodule

Computercaseandchassiswithadequatepowersupplyunit

Monitor

PS/2Keyboard

PointingDevice(PS/2mouse)

VGACard

SoundCard(optional)

Speaker(s)(optional)

DiskDrives:HDD,CD-ROM,Floppydrive…

ExternalPeripherals:Printer,Plotter,andModem-(optional)

InternalPeripherals:ModemandLANcards(optional)

SY-V6BE+ Quick Start Guide

Hardware

Installation

Install the Mainboard

Followthestepsbelowinordertoperformtheinstallationofyournew

SY-V6BE+

Mainboard.

Step 1. Install the CPU

Mark your CPU Frequency:

RecordtheworkingfrequencyofyourCPU

thatshouldbeclearlymarkedontheCPUcover.

233MHz(66 x3.5) 300MHz(66 x4.5) 350MHz (100 x3.5) 450MHz (100 x4.5)

266MHz(66 x4.0) 333MHz(66 x5.0) 400MHz (100 x4.0) 500MHz (100 x5.0)

CPU Mount Procedure:

TomountthePentium

IIprocessorthatyouhave

purchasedseparately,followtheseinstructions.

Unpack the Retention Kit 2

Position the Mainboard 3

Insert the Screws

Install the Supporting Base

Install the Retention Clip 6

Install the CPU

Install the Support Clip 8

Insert the Latches 9

Remember to connect the CPU

Cooling Fan to the CPUFAN

power connector on the

mainboard.

Supporting Base

Support Clip

Screws (x2)

Retention Clip

Latches (x2)

ATX Power

Heat Sink

Slot 1

CPUFAN Power Larger Pinhole

SY-V6BE+

Quick Start Guide

Hardware

Installation

Step 2. Make Connections to the Mainboard

Thissectiontellshowtoconnectinternalperipheralsandpowersupplytothemainboard.

InternalperipheralsincludeIDEdevices(HDD,CD-ROM),FloppyDiskDrive,ChassisFan,

FrontPanelDevices(TurboLED,InternalSpeaker,ResetButton,IDELED,and KeyLock

Switch.),Wake-On-LANcard,VGAcard,SoundCard,andotherdevices.

FormoredetailsonhowtoconnectinternalandexternalperipheralstoyournewSY-V6BE+

Mainboard,pleasereferto SY-V6BE+MainboardUser'sGuideandTechnicalReference

onlinemanualonCD-ROM.

Connectors and Plug-ins

IrDA (Infrared Device Header): IR1 Wake-On-LAN Header: JP44

Pin1 Pin2 Pin3 Pin4 Pin5 Pin1 Pin2 Pin3

VCC None IRRX GND IRTX 5VSB GND MP-Wakeup

CPU Cooling Fan: CPUFAN Chassis Fan: CHAFAN

Pin1 Pin2 Pin3 Pin1 Pin2 Pin3

GND 12V SENSOR GND 12V SENSOR

Power LED Keylock

Pin1 Pin2 Pin3

Pin1 Pin2

5V NC GND

ControlPin GND

Speaker

Pin1 Pin2 Pin3 Pin4

5V NC NC Speakerout

HDD LED Turbo LED PWRBT RESET

Pine1 Pin2 Pin1 Pin2 Pin1 Pin2 Pin1 Pin2

LEDAnode LED

Cathode LED

Cathode GND PowerGood GND Power

On/Off GND

ATX Power On/Off: PWRBT ATX Power Supply: ATX PW

Connect your power switch to this

header (momentary switch type).

To turn off the system, please

press this switch and hold down

for longer than 4 seconds.

Attach the ATX Power cable to this connector.

When using the Power-On by PS/2 Keyboard

function, please make sure the ATX power

supply can take at least 720mA load on the

5V Standby lead (5VSB) to meet the standard

ATX specifications.

Power LED

Key Lock

Speaker

Reset

PWRBT

Turbo LED

HDD LED

SY-V6BE+ Quick Start Guide

Hardware

Installation

Step 3. Configure Memory

YourboardcomeswiththreeDIMMsockets,providingsupportforupto768MBofmain

memoryusingDIMMmodulesfrom8MBto256MB.For66MHzfrontsidebusCPUsuse

12nsorfastermemory;for100MHzfrontsidebusCPUsuse8ns(100MHz,PC100

compliant)memory.

Memory Configuration Table

Number of Memory Modules DIMM 1 DIMM 2 DIMM 3

11st

22nd 1st

33rd 2nd 1st

RAM Type SDRAM

Memory Module Size (MB) 8/16/32/64/128/256 Mbytes

Note:(1) 256 MB memory modules only available on PC registered DIMM.

(2) Always install memory modules in the order prescribed in this table.

(3) Do not install unbuffered and registered memory modules together.

Important:

ItisofprimeimportancethatyouinstallDIMMmodulesasoutlinedinthetable

aboveinordertopreservesignalintegrityon100MHzfrontsidebussystems.

Step 4. Set SW1 for power up FSB clock and AGP bus clock.

SW1isusedtoadjustAGPbusclockfrequencydependingonthevalueofthefrontsidebus

(FSB)clock,alsothesettingoftheSW1determinesthepowerupFSBclockwhichwill

remaineffectiveuntiltheBIOSsettheFSBclocktotheCMOSsetting.

SW1 Setting Power up FSB Clock AGP Clock

66MHz AGP Clock

= FSB Clock ÷1

100MHz AGP Clock

= FSB Clock ÷1.5

Note: The specification of maximum AGP bus Clock frequency

is 66.6MHz.

∗

SetSW1toopenwhenyouuseaFSB100MHzCPUsuchas350MHz,400MHz,

450MHz,or500MHz.

∗

SetSW1toclosewhenyouuseaFSB66MHzCPUsuchas233MHz,266MHz,

300MHz,333MHz,or366Mhzonlyfor Celeron.

∗

SetSW1toopenwhenyouuseaFSB66MHzbutwanttooverclocktheFSBclockto

100MHzviatheBIOSsetting.

SY-V6BE+

Quick Start Guide

Hardware

Installation

Step 5. Set the CPU Frequency

ThismainboarddoesnotuseanyjumperstosettheCPUfrequency,CPUsettingare

changedthroughtheBIOS[SOYOCOMBOSETUP].RefertoChapter3 “QuickBIOS

Setup”fordetailsonhowtosetthePentium



IIprocessorfrequency.

Step 6. Enable/Disable Power-On by Keyboard (JP10)

YoucanchoosetoenablethePower-OnbyKeyboardfunctionbyshortingpin1-2onjumper

JP10,otherwise,shortpin2-3todisablethisfunction.

Power-On by

Keyboard Enable Disable

JP10 Setting Short pin 1-2 to enable the

Power-On by Keyboard function. Short pin 2-3 to disable the

Power-On by Keyboard function.

Important: When using the Power-On by Keyboard function, please make sure the

ATX power supply can take at least take 720mA load on the 5V standby lead (5VSB) to

meet the standard ATX specification. Apart from the jumper setting, you have to enter

the CMOS setup and set the “Power-On by Keyboard”item in the SOYO COMBO

Setupto“Password”or function key.

Step 7. Clear CMOS Data (JP5)

CleartheCMOSmemorybymomentarilyshortingpin2-3onjumperJP5foratleast5

seconds,andthenbyshortingpin1-2toretainnewsettings. Thisjumpercanbeeasily

identifiedbyitswhitecoloredcap.

CMOS Clearing Clear CMOS Data Retain CMOS Data

JP5 Setting Short pin 2-3 for

at least 5 seconds

to clear the CMOS.

Short pin 1-2

to retain the

new settings.

Note: You must unplug the ATX power cable from the ATX power connector when

performing the CMOS Clear operation.

You MUST enter the CMOS SETUP and SAVE CMOS

setting twice after clearing CMOS data.

If you fail to do this

your new setting would NOT be Saved.

SY-V6BE+ Quick Start Guide

Hardware

Installation

Note on Over-clocking Capability

TheSY-V6BE+mainboardprovidesover-clockingcapability.Duetotheover-clocking

settingyoursystemmayfailtobootuporhangduringruntime.Ifthisoccurs,pleaseperform

thefollowingstepstorecoveryoursystemfromtheabnormalsituation:

Turnoffsystempower(IfyouuseaATXpowersupply,sometimesyouhavetopress

thepowerbuttonformorethen4secondstoshutdownthesystem)

SettheSW1toshortifyouuseaFSB66MHzCPU,SettheSW1toopenifyouusea

FSB100MHzCPU

Pressandholddownthe<Insert>keywhileturningonthesystempower.Keep

holdingdownthe<Insert>keyuntilyouseethemessageoftheCPUtypeand

frequency(133MHzor200MHz)appearonscreen

Pressthe<Del>keyduringthesystemdiagnosticcheckstoentertheAwardBIOS

Setupprogram

FromtheBIOSmainmenu,select[SOYOCOMBO]andmovethecursortothe[CPU

Frequency]fieldtosettheproperworkingfrequency

Select[Save&ExitSETUP]andpress<Enter>tosavetheconfigurationtothe

CMOSmemory,andcontinuethebootsequence

Note: SOYOdoesnotguaranteesystemstabilityiftheuseroverclocksthesystem.

Anymalfunctions dueto over-clocking arenot coveredbythewarranty.

Altri manuali per SY-V6BE+

Indice

Altri manuali SOYO Scheda madre

SOYO

SOYO SY-6BB V1.0 Manuale utente

SOYO

SOYO SY-6BA+ Manuale utente

SOYO

SOYO SY-7IWB V1.0 Manuale utente

SOYO

SOYO SY-7VEM Manuale utente

SOYO

SOYO SY-P4S DRAGON Ultra Manuale utente

SOYO

SOYO SY-5EMM Manuale per l'uso e la cura

SOYO

SOYO SY-6BE+ Manuale utente

SOYO

SOYO SY-D6IBA Manuale utente

SOYO

SOYO SY-KT333 DRAGON Plus Manuale utente

SOYO

SOYO SY-K7VIA Manuale utente

SOYO

SOYO 6KF Manuale per l'uso e la cura

SOYO

SOYO SY-6IZA Manuale per l'uso e la cura

SOYO

SOYO SY-7IWB Manuale utente

SOYO

SOYO SY-7VBA 133 Manuale utente

SOYO

SOYO SY-6VZA Manuale utente

SOYO

SOYO SY-7VMA-B Manuale utente

SOYO

SOYO 82430 HX / P54C Manuale per l'uso e la cura

SOYO

SOYO Pentium SiS 551x Manuale per l'uso e la cura

SOYO

SOYO 82430 HX/P54C Manuale per l'uso e la cura

SOYO

SOYO SY-7VCA Manuale utente

SOYO

SOYO DRAGON 2 Motherboard 2 Manuale utente

SOYO

SOYO SY-6IWM/L Manuale utente

SOYO

SOYO SY-K7VEMPRO Manuale utente

SOYO

SOYO 80486 Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
