USER MANUAL
• Proton Exchange Membrane (PEM) technology.
• State-of-the-art Solid Polymer Electrolysis (SPE) technology.
• Works with filtered water, including distilled and RO.
• Separates and expels harmful byproducts of chlorine, ozone, and oxides.
• Produces therapeutic levels and higher of molecular hydrogen.
• Has the safest, high-quality, platinum-coated titanium electrode plates.
• High-quality portable hydrogen water generator.
• No filters or any expensive parts to replace.
INOVATIVE TECHNOLOGY
• Remove the bottle from the generator. Wash bottle and lid with warm water.
• Twist plastic plug o of the electrode plate.
• Twist bottle onto generator.
• Cap bottle with lid and insert USB-C cable into USB-C port.
• Insert other cable end into the USB-C power adaptor and plug it into the outlet.
• Charge unit for 2 to 3 hours until the green light turns on. Then, take o charger.
• With bottle attached to generator, rinse out generator with warm water.
• Fill bottle to just below the top threads with filtered water.
• Operate generator to make hydrogen-rich water.
QUICK SETUP
• Use filtered water to keep plates clean.
• Never let the generator dry out.
Leave a small amount water in the bottle to keep the electrode plate moist.
• Consume hydrogen water freely.
• Run the self-cleaning cycle once a week. This creates oxygen instead of hydrogen to kill bacteria.
• Do not drink the water from the self-cleaning cycle. Pour it out.
DAILY USE
PRODUCT DIAGRAM
LID
BOTTLE
GENERATOR
ELECTRODE PLATE
USB-C CHARGING PORT
(BACK OF MACHINE)
BUTTON
USB-C POWER
CABLE
CHARGER
PLASTIC PLUG
(PROTECTS THE
ELECTRODE PLATE)
• Never operate generator without water
in the bottle.
• Keep USB-C port sealed by plugging its
cover back in.
• Operate only with filtered water.
• Not for use with hot, carbonated, or
non-water beverages.
• Always keep electrode plate wet and
never store dry.
• Unit will stop charging when LED lights
turn green.
• Do not place generator unit in a
refrigerator or cooler.
• Do not soak or submerge generator unit
under water.
• Drink hydrogenated water within 3 to 5 hours.
• Avoid direct sunlight or heat that can dry
out the electrode plate.
• Use room temperature water. Never freeze
or use ice.
• Never use any chemical cleaners on
generator unit.
• Keep out of reach of children and pets.
• Keep away from heat and flames.
• Unplug by pulling the plug, not the wire.
• Do not unplug device with wet hands.
ADVISORIES
Depending on the mineral oxide content in your
filtered water, clean the electrolysis plates by
descaling once or twice a month.
To descale, add 1 part white vinegar, lemon juice,
or citric acid and 3 parts water in the bottle and
leave generator soaking in mix overnight.
Dump and rinse thoroughly with warm water
before using the next day.
Disclaimer: These products have not been evaluated
and are not intended to diagnose, cure, treat, or
prevent disease. Seek medical advice if seriously ill
or attempting to cure or prevent disease.
OCCASIONAL DESCALING
MAINTENANCE
Keeping your machine plugged in all day during use
may cause your battery to fail prematurely.
Do not keep plugged in past the allotted 2 to 3 hours.
01. Short press the button. The working indicator
light will turn blue, making hydrogen-rich
water for 3 minutes (0.8 ppm). Short pressing
the button twice in a row will turn the working
mode to 10 minutes (up to 1.8 ppm). Run the
10-minute cycle a second time to achieve
hydrogen water with 3.0 ppm. Pressing
the button when the unit is working will
turn the power o.
02. After a 3- or 10-minute cycle, the working
indicator light will turn o, completing the
process.
03. You can drink the hydrogen-rich water
directly out of the bottle or pour it into
another container. It is best to drink the
water within 3 to 5 hours. Hydrogen will
dissipate over time.
04.Self-cleaning: Press and hold the button for
3 seconds. The working indicator light will
turn green, the positive and negative
electrodes will be swapped, and the
machine will enter the self-cleaning mode.
This mode, which takes about 3 minutes,
will create oxygen instead of hydrogen to
kill bacteria. Do not drink the water from
the self-cleaning cycle. Pour it out.
05.Charging: If the working indicator light
flashes blue, this means the battery
power is low and needs to be charged.
The USB-C charging port is located
underneath the rubber cover on the back
of the generator. Plug the USB-C power
cable into the USB-C power adapter and
plug the adapter into the wall. The LED
light will turn red when it is charging.
When charging is complete, the LED light
will turn green. Unplug the device and
make certain the rubber cover is inserted
into the USB-C port. This will keep water
from entering the generator.
OPERATION
TROUBLESHOOTING
PROBLEM SOLUTION
No visible
bubbles
No light when
operating unit
Low ppm levels
when tested with
H2 Blue Reagent
Battery not
charging
Machine is
leaking water
Bottle has odor
or unit produces
less gas
Check power source
Low battery
Charge unit
Operate the unit
more times to
activate PEM
Check for defective
plug or cable
Check all seals and
tighten lid
Clean as needed
Use filtered water
Warranty: 1-year warranty that covers
parts and labor.
For all other issues or unsolved problems,
contact customer support: 1 (800) 337-7017
PRODUCT SPECIFICATIONS
Power
Bottle Max
Capacity
Water Type
Required
Water
Temperature
Range
Unit Dimensions
Unit Net Weight
Hydrogen
Generation Range
Bottle Material
USB-C 5V / 2A Output:
<10W
10 oz. / 296 mL
Filtered Water
32o-140oF / 0o-60oC
60 mm (diameter)
x 203 mm (height)
(2 3/8 x 8 in.)
204 g (0.45 lbs.)
0.8 to 3.0 ppm
Tritan Plastic
SYNERGY SCIENCE, INC.™
