Terex Genie S-100 Manuale utente
Operator's Manual Fifth Edition • Second Printing
S-100 • S-105 • S-120 • S-125 Part No. T113597
Copyright © 2000 by Genie Industries
Fifth Edition: Second Printing, January 2012
"Genie" is a registered trademark of
Genie Industries in the U.S.A. and many other
countries. "S" is a trademark of Genie Industries.
Complies with EC Directive 2006/42/EC
See EC Declaration of Conformity
Printed on recycled paper
Printed in U.S.A.
Important
Read, understand and obey these safety rules and
operating instructions before operating this machine.
Only trained and authorized personnel shall be
permitted to operate this machine. This manual should
be considered a permanent part of your machine and
should remain with the machine at all times. If you
have any questions, call Genie Industries.
Contents
Page
Introduction ............................................................... 1
Symbol and Hazard Pictorials Definitions .................. 3
General Safety .......................................................... 5
Personal Safety ........................................................ 8
Work Area Safety...................................................... 9
Legend .....................................................................19
Controls ................................................................... 20
Inspections ..............................................................28
Operating Instructions .............................................. 42
Transport and Lifting Instructions .............................54
Maintenance ............................................................57
Specifications .......................................................... 60
Contact us:
Internet: http://www.genielift.com
E-mail: [email protected]
Operator's ManualFifth Edition • Second Printing
PartNo.T113597 S-100 • S-105 • S-120 • S-125 1
Danger
Failure to obey the instructions and
safety rules in this manual will result
in death or serious injury.
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator's
manual.
1 Avoid hazardous situations.
Know and understand the above principle
before going on to the next section.
2 Always perform a pre-operation inspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Youread,understandandobeythe
manufacturer'sinstructionsand safety rules—
safetyandoperator'smanualsandmachine
decals.
Youread,understandandobeyemployer's
safety rules and worksite regulations.
Youread,understandandobeyallapplicable
governmentalregulations.
Youare properlytrained to safely operate the
machine.
Owners, Users and Operators:
Genieappreciates your choice of ourmachine for
yourapplication. Ournumber one priority is user
safety, which is best achieved by our joint efforts.
We feel that you make a major contribution to
safety if you, as the equipment users and
operators:
1 Comply with employer, job site and
governmentalrules.
2 Read, understand and follow the instructions
in this and other manuals supplied with this
machine.
3 Use goodsafe work practices ina
commonsenseway.
4 Onlyhavetrained/certifiedoperators,directed
byinformedandknowledgeablesupervision,
runningthemachine.
If there is anything in this manual that is not clear
orwhich youbelieve shouldbe added, please
contact us.
Internet:www.genielift.com
E-mail:[email protected]
Introduction
Operator's Manual Fifth Edition • Second Printing
2 S-100 • S-105 • S-120 • S-125 PartNo.T113597
Intended Use
This machine is intended to be used only to lift
personnel, along with their tools and materials to an
aerial work site.
Introduction
Safety Sign Maintenance
Replace any missing or damaged safety signs.
Keep operator safety in mind at all times. Use mild
soap and water to clean safety signs. Do not use
solvent-basedcleanersbecause theymaydamage
the safety sign material.
Hazard Classification
Genie uses symbols, color coding and signal
words to identify the following:
Safety alert symbol—used to alert
youto potentialpersonal injury
hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicatesa hazardoussituation
which, if not avoided, will result in
deathor serious injury.
Indicatesa hazardoussituation
which, if not avoided, could result
in death or serious injury.
Indicatesa hazardoussituation
which, if not avoided, could result
inminorormoderateinjury.
Indicatesapropertydamage
message.
Red
Orange
Yellow
Blue
Operator's ManualFifth Edition • Second Printing
PartNo.T113597 S-100 • S-105 • S-120 • S-125 3
Symbol and Hazard Pictorials Definitions
CrushHazard ExplosionHazard
FallHazard
CrushHazard
Tip-over Hazard
Electrocution
Hazard
Keep off this
surface.
Keepawayfrom
movingparts.
Maintainrequired
clearance. Keepawayfrom
path of moving
platform.
Nosmoking.
Noflame.
Stopengine.
Do not overload
platform.Welder
powersupply
weighs
75 lbs / 34 kg
Tip-over Hazard
Onlytrained
maintenance
personnelshould
access
compartments.
Readthe
operator’s
manual.
Platformdownhill:
1. Retract boom.
2. Lowerboom.
Platformuphill:
1. Lowerboom.
2. Retract boom.
Tip-over Hazard
Recoveryprocedure if tilt alarm
soundswhileelevated.
No Step
Fall Hazard
Operator's Manual Fifth Edition • Second Printing
4 S-100 • S-105 • S-120 • S-125 PartNo.T113597
Lanyard
attachmentpoint
Symbol and Hazard Pictorials Definitions
Wheel load
Avoid contact.
Havefire
extinguisher near.
Tie-down
instructions Tie-down
instructions
Electrocution
Hazard
ExplosionHazard Do not use ether
orotherhigh
energystarting
aids on machines
equippedwith
glowplugs.
FireHazard
Explosion / Burn
Hazard Keepallopen
flamesand
sparks away.
Pressure rating for
air line to platform
Read service
manual.
Voltage rating for
power to platform
Replace tires with
same tire.
Replace
extension cylinder
cover before
operating
machine.
Operator's ManualFifth Edition • Second Printing
PartNo.T113597 S-100 • S-105 • S-120 • S-125 5
General Safety
Operator's Manual Fifth Edition • Second Printing
6 S-100 • S-105 • S-120 • S-125 PartNo.T113597
General Safety
Operator's ManualFifth Edition • Second Printing
PartNo.T113597 S-100 • S-105 • S-120 • S-125 7
General Safety
Operator's Manual Fifth Edition • Second Printing
8 S-100 • S-105 • S-120 • S-125 PartNo.T113597
Personal Safety
Fall Protection
Personal fall protection equipment (PFPE) is
requiredwhenoperatingthismachine.
Occupants must wear a safety belt or harness in
accordancewithgovernmentalregulations.Attach
the lanyard to the anchor provided in the platform.
Operators must comply with employer, job site and
governmentalrulesregardingtheuseofpersonal
protectiveequipment.
All PFPE must comply with applicable
governmentalregulations,andmustbeinspected
and used in accordance with the PFPE
manufacturer’sinstructions.
