Topfield CRC-2400 Manuale utente

TOPFIELD

CRC-2400

User Guide

High Deﬁnition

Digital Cable Receiver

Personal Video Recorder

CONAX Embedded

ii CONTENTS

Contents

Contents ii

1 Introduction 1

1.1 Features .............................. 1

1.2 Controlling the digital receiver .................. 2

1.2.1 Front panel ........................ 3

1.2.2 Remote control ...................... 4

1.3 Subscription card information .................. 6

2 Setup 7

2.1 Unpacking ............................. 7

2.2 Safety precautions ......................... 7

2.3 Rear panel connections ...................... 9

2.4 Connecting up your digital receiver ............... 10

2.4.1 Connecting to the broadcasting cable .......... 11

2.4.2 Connecting to your television set ............ 11

2.4.3 Connecting to your video recorder ........... 13

2.5 Switching on for the ﬁrst time .................. 13

3 Service Search 16

3.1 Searching for broadcasting services ............... 16

3.2 Resetting to factory settings ................... 17

3.3 Resetting to user settings ..................... 18

3.4 Clearing the services list ..................... 18

CONTENTS iii

4 Preference Settings 19

4.1 Language settings ......................... 19

4.1.1 Menu language ...................... 19

4.1.2 Subtitle language ..................... 20

4.1.3 Hard of Hearing ..................... 20

4.1.4 Audio language ...................... 20

4.2 Video and audio settings ..................... 21

4.2.1 High deﬁnition television ................ 21

4.2.2 Television aspect ratio .................. 22

4.2.3 Colour format ....................... 23

4.2.4 Another video device ................... 23

4.2.5 Audio mode ........................ 24

4.3 Local time setting ......................... 24

4.4 Parental control .......................... 26

4.5 Options for recording ....................... 28

4.6 Options for playback ....................... 29

4.7 Options for on-screen display .................. 30

4.8 Options for the front display ................... 31

4.9 Options for Photo Album ..................... 31

4.10 Options for standby mode .................... 32

5 Every Day Use 33

5.1 Volume control .......................... 33

5.2 Watching television ........................ 33

5.2.1 The services list ...................... 33

5.2.2 The favourite service lists ................ 34

5.2.3 Viewing programme information ............ 35

5.2.4 Selecting audio tracks .................. 36

5.2.5 Selecting subtitle tracks ................. 37

5.2.6 Viewing teletext ...................... 37

5.3 Viewing electronic programme guide .............. 37

5.4 Using time-shift .......................... 38

6 Organising Services 41

6.1 Editing the favourite lists ..................... 41

6.2 How to use on-screen keyboard ................. 43

iv CONTENTS

7 Recording and Playback 44

7.1 Recording a programme ..................... 45

7.1.1 Instant recording ..................... 45

7.1.2 Timer recording ...................... 47

7.1.3 Scheduling recordings using the programme guide . . 49

7.1.4 Recording a time-shifted programme .......... 49

7.1.5 Recording a pay service programme .......... 50

7.2 File archive ............................. 51

7.2.1 To delete a recording ................... 51

7.2.2 To sort recordings ..................... 51

7.2.3 To lock a recording .................... 52

7.2.4 To rename a recording .................. 52

7.2.5 To make a new folder ................... 52

7.2.6 To move a recording to another folder ......... 52

7.3 Playing back a recording ..................... 53

7.3.1 To navigate using the progress bar ........... 53

7.3.2 To play in slow motion .................. 54

7.3.3 To play in fast motion ................... 54

7.3.4 To make a bookmark ................... 55

7.3.5 To play back recordings in sequence .......... 55

7.3.6 To play back a scrambled recording ........... 56

7.4 Copying a recording ....................... 56

7.5 Formatting the hard disk ..................... 57

8 Entertainment 58

8.1 Conﬁguring the network setting ................. 58

8.2 Copying ﬁles ............................ 59

8.3 Playing back MP3 ﬁles ...................... 60

8.4 Viewing image ﬁles ........................ 61

8.5 Playing back a video ﬁle ..................... 61

8.6 Playing back YouTube contents ................. 62

8.7 Sharing image ﬁles by Yahoo Flickr ............... 63

8.8 SHOUTcast Internet radio .................... 65

8.9 Google weather forecast ..................... 66

9 Firmware Update 67

CONTENTS v

9.1 From a memory stick ....................... 67

9.2 Over the air ............................ 68

A Universal Remote Control 69

A.1 Code list for television sets .................... 72

A.2 Code list for DVD players ..................... 86

A.3 Code list for audio-video receivers ............... 88

Chapter 1

Introduction

The CRC-2400 digital receiver is fully compliant with the inter-

national Digital Video Broadcasting (DVB) standard, and thus

is able to receive digital broadcasts of that standard.

NOTE

In general we equate a channel with a frequency. However,

unlike analogue broadcasts, digital broadcasts are not all

assigned to their own frequencies; instead, multiple televi-

sion broadcasts are transmitted through a single frequency.

The frequency in digital broadcasting is usually called trans-

ponder or multiplex. To reduce confusion in this manual,

the word service is preferably used than channel as a term

to indicate one television or radio broadcast.

1.1 Features

This digital receiver has the following features:

• Can store up to 2,000 television and radio services.

• Can create lists of your favourite services.

2 Introduction

• Can view information about the current television or ra-

dio programme.

• Has an electronic programme guide that provides an

overview of scheduled programmes.

• You can record one service while you are currently

watching another.

• You can record many programmes using a built-in hard

drive with large storage capacity.

• Time-shift is a special technical feature available on this

digital receiver. You can pause a programme you are

watching and resume it again at a later time. Then you

can quickly go to any part of the current programme by

fast forward or rewind search.

• If you have an external hard drive connected to the dig-

ital receiver via the USB port, you can record television

programmes into it.

• You can play back video ﬁles of various formats includ-

ing DivX.

• You can use various Web services including YouTube.

1.2 Controlling the digital receiver

You can operate the digital receiver with the remote control or

the buttons on the front panel.

NOTE

When the digital receiver is oﬀ but plugged into a wall

socket, we say that it is in standby mode; on the other hand,

when it is on, it is in active mode. Even when you are not

using the digital receiver, you should keep it plugged into

a wall socket to be in standby mode so that it can run timer

events at any time.

1.2 Controlling the digital receiver 3

1.2.1 Front panel

The front panel of the digital receiver has buttons to control

the digital receiver, speciﬁc lights and a display to indicate its

status. The following indicates what they mean.

button switches the digital receiver between standby mode

and active mode.

Front display shows the current time in standby mode, and

displays the current service in active mode.

MENU button displays the main menu. It is also used to return

to the previous menu from a submenu.

OK button displays the services list. See §5.2.1 for more de-

tails. It is also used to select a menu item.

CHANNEL

buttons switch to the previous or next ser-

vice.

VOLUME

buttons decrease or increase the volume.

You have to insert your subscription

card into the front slot to watch pay

services. When you insert the subscrip-

tion card, the side on which the chip is

mounted must face upward.

4 Introduction

1.2.2 Remote control

.1button switches the

digital receiver between

standby mode and active

mode.

.2mutes the sound. Press

again to switch it back on.

.3







TV switches the remote

control to television mode

to operate your television.

.4







PVR switches the remote

control to receiver mode to

operate the digital receiver.

.5







AUX switches the remote

control to operate your

audio-video receiver.

.6







DVD switches the remote

control to DVD mode to op-

erate your DVD player.

.7Numeric buttons are used

to enter a service number

for service change or to

specify values for menu op-

tions.

.8switches over between

the current service and the

previously viewed one.

.9displays the service information box. It is also used

to display more information about a programme.

10 







VOLUME−,







VOLUME+buttons decrease or increase the

volume.

11 







CHANNEL−,







CHANNEL+buttons switch to the previous or
