TRENDnet TV-IP600 Manuale utente
TV-IP600
rev: 08.11.2009
Features
The ProView Pan/Tilt/Zoom Internet Camera provides real-time security
surveillance over a large viewing area. Monitor people in your camera's viewing
field from any Internet connection. See more with one Internet
camera—remotely pan the camera side-to-side a remarkable 312 degrees and
tilt up-and-down 115 degrees.
Manage up to 32 TRENDnet cameras with the included complimentary camera
management software. Advanced features include motion detection recording,
email alerts, scheduled recording sessions, auto-patrol pan/tilt and digital
zoom. This camera's brilliant image quality, pan and tilt functionality and
recording capabilities make it ideal for home, small office and business use.
TV-IP600 (v1.0R)
ProView Pan/Tilt/Zoom Internet Camera
internet
cameras
•1x 10/100Mbps Fast Ethernet port
•MJPEG video compression at up to 30 frames per second
•Resolution up to VGA: 640 x 480 pixels
•Pan: -156° ~ +156° and tilt: -45° ~ +70°
•Define up to 24 preset viewing points
•4x digital zoom
•Create up to 64 user accounts
•Full image color, saturation and contrast controls
•Exposure/white balance controls
•Flip-Image feature adjusts image when camera is mounted upside down
•Included wall and ceiling mounting hardware
•Supports TCP/IP networking, SMTP Email*, HTTP and other Internet protocols
•Record streaming video to your computer or network storage devices (after mapping)
•Motion detection email alerts, ftp uploads and recording from complimentary software
•Quick Universal Plug and Play (UPnP) installation
•Complimentary IPView Pro 2.0 software: manage up of up to 32 cameras **
•3-year limited warranty
!Does not support SSL
!** Monitoring multiple cameras may require a high performance CPU
LED
General
Pan/Tilt
Image & Video
Reset Button
• Sensor: 1/4” color CMOS SOC image sensor
Network
Camera
SPECIFICATIONS
Power Consumption
Power
Dimension
Weight
To Run Software
Temperature
IPView Pro 2.0
Certification
To View
Network Protocols
• Encoding type: MJPEG
• Brightness, contrast, noise reduction, saturation, sharpness, white balance, flip, mirror (horizontal/vertical), black/white mode
Video
Recording
• Resolution: 640 x 480, 320 x 240, 160 x 120
• Recording type: continuous, schedule or motion detection with software
Port Settings • HTTP port: 80 (default)
Hardware
Requirement
Setting
• Yes
• 4x
Digital Zoom
Dynamic DNS
Time • Synchronize with NTP server or set time/date manually
• Remote management supported
• Up to 64 user accounts*
Account
Remote
Backup / Restore • Save/retrieve configuration files
Management
• Resolution: 640 x 480 pixels • Board Lens
• F/No: F1.9
• Focal Length: 4.57mm
• Minimum illumination: 1 Lux @ F1.9 • Focus depth: 20cm ~ infinity
• View angle: horizontal: 45 degree, vertical: 34 degree
• Compression: MJPEG • Exposure/white balance control: automatic
• Resolution: up to 15fps for VGA (640x480), 30fps for QVGA (320x240), 30fps for QQVGA (160x120)
• Pan: -156° ~ +156°
• IEEE 802.3u 10/100Mbps Fast Ethernet, Auto-MDIX
• Power, Link
• Reset settings
• 8 Watts
• 112 x 112 x 110mm (4.4 x 4.4 x 4.3 in.)
• 5V, 2.5A external power adapter
• 450g (1 lb)
• Internet Explorer 6.0 or above, Safari 2.0 or above, Firefox 2.0 or above, Opera, Netscape, and Google Chrome
• IP, ARP, TCP, UDP, ICMP
• CE, FCC
• Operating: 5ºC ~ 40ºC (41ºF ~ 104ºF)
• Windows XP, Vista
• Channel: supports up to 32 cameras
• Frame rate: 1, 5, 7, 15, 20, Auto
TV-IP600 (v1.0R)
ProView Pan/Tilt/Zoom Internet Camera
• Tilt: -45° ~ +70° • Preset position: 24 positions
• Storage: -25ºC ~ 50ºC (13ºF ~ 122ºF)
• Record/Playback/Motion Detection
• HTTP Server • PPPoE
• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client
• UPnP
SMTP • Support SMTP mail
• Compression: 5 levels
* Up to 8~10 users is recommended to view the camera simultaneously
TV-IP600
rev: 08.11.2009
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
TS-S402
TWG-BRF114 4-Port Firewall Router
• CD-ROM (Utility & User’s Guide)
2-Bay SATA I/II Network Storage Enclosure
• TV-IP600
• Multi-Language Quick Installation Guide
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web:
Email:
1-888-326-6061
www.trendnet.com
TV-H400 Outdoor Camera Dome Enclosure with Heater and Fan
• Cat. 5 Ethernet cable (1.5m / 5ft.)
• Power adapter (5V, 2.5A)
• Wall mount kit
TV-IP600 (v1.0R)
ProView Pan/Tilt/Zoom Internet Camera
Pan/Tilt/Zoom Internet Camera Server
(TV-IP600)
Wireless Pan/Tilt/Zoom
Internet Camera Server
(TV-IP600W)
300Mbps Wireless N
Gigabit Router
(TEW-639GR)
Internet
Wireless Pan/Tilt/Zoom
Internet Camera Server
(TV-IP600W)
