TRENDnet TE100-PCBUSR - DATA SHEETS Manuale utente
FCC Warning
This equipment has been tested and found to comply with the
regulations for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with this user’s guide,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
CE Mark Warning
This is a Class B product. In a domestic environment, this
product may cause radio interference, in which case the user
may be required to take adequate measures.
VCCI Mark Warning
Table of Contents
INTRODUCTION..................................................1
GENERAL DESCRIPTION..................................................1
LED INDICATORS............................................................1
SUMMARY OF FEATURES.................................................2
CARD INSERTION AND REMOVAL......4
CARD INSERTION............................................................4
[1] Insert the 32-bit CardBus 10/100Mbps PC Card.4
[2] Connect to the Network Media............................5
CARD REMOVAL .............................................................5
DRIVER INSTALLATION...............................7
DIAGNOSTICS......................................................8
Adapter Basic Diagnostics........................................9
Network Diagnostics...............................................10
TECHNICAL SPECIFICATIONS..............10
1
Introduction
General Description
The 32-bit CardBus 10/100Mbps Fast Ethernet PC
Card is a credit-card sized Fast Ethernet adapter for
connecting a notebook to an IEEE 802.3 Ethernet
network and IEEE 802.3u Fast Ethernet network, it’s
designed to work with notebooks or handheld computers
that with CardBus slots. Inside its compact package, the
32-bit CardBus 10/100Mbps Fast Ethernet PC Card
holds the Ethernet controller, network processing
interface, RAM for the data buffer a, 68-pin PC Card plug
and RJ-45 10/100Mbps Fast Ethernet port. It requires
no pre-installation setup -- simply insert the PC Card into
the computer's 32-bit CardBus slot.
The 32-bit CardBus 10/100Mbps Fast Ethernet PC Card
features LED indicators for 10M Link/Activity, and 100M
Link/Activity.
LED Indicators
The 32-bit CardBus 10/100Mbps Fast Ethernet PC Card
provides two LED indicators:
1. 10M Link/Activity
(10M Link/ACT)
¾This indicator lights green when the RJ-45 port
is connected to a 10Mbps Ethernet network, if
the indicator blinking green will be transmissing
/received data to/from the 10Mbps Ethernet
network.
2
2. 100M Link/Activity Indicator (100M Link/ACT)
¾This indicator lights green when the RJ-45 port
is connected to a 100Mbps Fast Ethernet
network, if the indicator blinking green will be
transmissing/received data to/from the
100Mbps Fast Ethernet network.
Summary of Features
The 32-bit CardBus 10/100Mbps Fast Ethernet PC Card
provides the following features:
¾Complies with IEEE 802.3 10BASE-T Ethernet
standard
¾Complies with IEEE 802.3u 100BASE-TX Fast
Ethernet standard
¾Complies with ANSI / IEEE 802.3 Auto-Negitiation
standard
¾Complies with 32-bit CardBus Standard
¾Built-in 32KB RAM data buffer
¾Auto-Polarity for UTP/STP cables.
¾No manual setup switches -- automatically
configured by software
¾Low power consumption
¾Supported driver list:
Microsoft Windows 95/OSR2
Microsoft Windows 98
Microsoft Windows ME
Microsoft Windows NT 4.0
Microsoft Windows 2000
Microsoft Windows XP
Microsoft Windows Vista
MS Windows for Workgroup 3.11 (NDIS2)
Microsoft Client for DOS (NDIS2)
Novell NetWare Client for DOS
Novell NetWare v5.0 Server
Novell NetWare v4.1x Server
Novell NetWare v3.12 Server
Novell NetWare Client 32 for DOS/WIN
Packet Driver
NDIS Driver v2.0 for DOS
Linux
4
Card Insertion and Removal
Card Insertion
Follow these steps to install the 32-bit CardBus
10/100Mbps Fast Ethernet PC Card:
[1] Insert the 32-bit CardBus 10/100Mbps Fast
Ethernet PC Card
Find/select an available Type II or Type III 32-bit PC Card
slot on your notebook’s side or rear panel. Holding the
32-bit CardBus 10/100Mbps Fast Ethernet PC Card with
the LED indicator facing up then insert to the 32-bit PC
Card slot. Slide the 32-bit CardBus 10/100Mbps Fast
Ethernet PC Card all the way into the 32-bit PC Card slot
until it reaches a firm stop.
[2] Connect to the Network Media
Simply plug one end of the cable (RJ-45 connector) into
an available hub/switch port, and plug the other end
(RJ-45 connector) into the RJ-45 port of your 32-bit
CardBus 10/100Mbps Fast Ethernet PC Card.
Card Removal
Use the computer's PC Card Eject mechanism to unseat
the 32-bit CardBus 10/100Mbps Fast Ethernet PC Card
from the computer's PC Card slot. The PC Card will
then protrude from the PC Card slot and you can easily
remove the PC Card by gripping its protruding end and
withdrawing it from the PC Card receptacle.
