TRENDnet TV-IP300W Manuale utente
TRENDnet's TV-IP300W Internet Camera Server is the perfect
device for remote monitoring and transmitting real-time events over
t h e I n t e r n e t . T h e T V - I P 3 0 0 W f u n c t i o n s a s a
video/audio/surveillance camera allowing you to view live events
with your web browser via Internet or Intranet. Up to 4 cameras can
be remotely managed with the bundled IPViewSP software. This
Internet Camera Server has MPEG4 quality streaming video,
automatic image capture, and event notification via e-mail, making it
the ideal solution for Internet video broadcasting applications.
TV-IP300W
Advanced Wireless Day/Night
Internet Camera Server
TEW-503PI (07-28-2005) TV-IP300W
rev:02.02.2007
• Wi-Fi Compliant with IEEE 802.11b/g Devices on 2.4 GHz ISM Frequency Band
• Wireless Supports Infrastructure and Ad-Hoc Modes
• Wireless Supports WEP 64/128-Bit Encryption (ASCII & HEX)
• Supports High Quality MPEG4 Compression
• Supports Night Vision with IR Lens
• Supports Audio Monitoring and RS-485 Port for PAN & TILT Control
• Supports CCD Image Sensor and DC-Iris Control
• Supports DirectX 9.0 Control for Internet Explorer
• Allows for Remote Access from Web Browser for Live Image Viewing
• Supports TCP/IP networking, SMTP e-mail, HTTP and other Internet related protocols
• Supports Web configuration with password protection
• Powerful Windows IPView SP Application Software for multiple cameras monitoring, image capturing, and video recording
(Windows 98/ME/2000/XP)
• Built-in I/O Ports to Trigger Alarm and Email Notification
• Broad Range of Applications for Monitoring Homes, Offices, Banks, Hospitals, and a Variety of Private and Public Monitoring
• 3-Year Warranty
FEATURES
Resolution
Resolution
Lens
MIC Input
Speed
Up/Down Reversal
Left/Right Reversal
Quality Selection
Control
Data Rate
Standard
Motion Detection
Bit Rate Selection
Max Frame Rate Selection
• Sharp 1/4” type CCD
• CIF(350x240NTSC, 352x288PAL) • QCIF(176x120NTSC, 176x144PAL)
• 512 x 480(NTSC), 512 x 576(PAL)
• Yes
• Yes (Brightness/ Contrast/ Flicker/ Saturation/ Hue)
• Yes
• Yes
•
• 11g: 54, 48, 36, 24, 12, 9 & 6Mbps • 11b: 11, 5.5, 2 & 1Mbps
• Built-in f 6.0mm F1.8 IR Lens (CS-Mount Standard, Replaceable)
• Internal MIC (mono) • S/N ratio: More than 60dB • Frequency: 50 ~ 16000Hz
• 24Kbps bit Rate • 8K Sampling Rate
• 8 Levels
• 30fps@CIF(NTSC) • 25fps@CIF(PAL)
• 9 Levels
• 5 Levels
• IEEE 802.11b/g
• Automatic
• DSSS
• Detachable 2dBi Diversity Antenna (Reversed SMA Connector)
Frame Rate
Compression
Audio
Video
Wireless
Sensor
Image Sensor
SPECIFICATIONS
• MPEG4 short header mode compression
Gain/Exposure/White Balanced Control
Modultechnik
Antenna
Iris Level
Frequency
• Adjustable • VR for Iris Control Adjustment
• 2.4 ~ 2.4835Ghz (ISMB)
RELATED PRODUCTS
PACKAGE CONTENTS
TV-IP200W
TPH-5000
TV-IP300 Advanced Day/Night Internet Camera Server
• Utility CD-ROM
• Metal Camera Stand
Wireless Internet Camera Server
• TV-IP300W
• Power Adapter
Outdoor Camera Housing
• Quick Installation Guide
NETWORKING SOLUTIONS
Advanced Wireless Day/Night Internet Camera Server
TV-IP300W
Internet
Cable/DSL
Modem
Office Monitoring
(TV-IP300)
Front Gate Monitoring
(TV-IP300)
Parking Monitoring
(TV-IP300W)
Warehouse Monitoring
(TV-IP300W)
Wireless
Access Point
(TEW-430APB)
100Mbps
54Mbps Wireless
Firewall Router
(TW100-BRF114)
Workstation with
PCI Adapter
(TE100-PCIWN)
TV-IP300W
rev:02.02.2007
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
Advanced Wireless Day/Night Internet Camera Server
TV-IP300W
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
SPECIFICATIONS
System
Generic Output
RAM/Flash ROM
Generic Input
RS-485
Memory Size
Weight
Application
LED
Power
Certifications
LAN
Consumption
Protocol
Dimension
Browser
Temperature
Stand Height
OS Support
Humidity
• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
• 2 pin (Half Duplex)
• 128M (256 Recommended)
• 270 grams (9.5 oz)
• IPView SP Software
• Power: Blue • Link/Active: Red
• 7 watt ( 580mA x 12V), max
• HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP, TCP/IP, DDNS, UPnP
• Pentium III, 450 MHz or above • VGA card resolution: 800 x 600 or above
• 16Mbytes/2Mbytes
• 1 set, 2 pin (photo coupler, 12V DC 50mA max)
• Philips Trimedia • PNX1300 VLIW DSP
• Linux
• 120 mm (4.7 inches)
• Windows 98SE, ME, NT4, 2000,XP
• 5% ~ 95% Non-Condensing
• 195x90x50 mm (7.7x3.5x2 inches)
• IE 5.0 or above
• Operating: 5°C ~ 40°C (41°F ~ 104°F) • Storage: -25°C ~ 50°C (-13°F ~ 122°F)
• 12V DC, 1.5A External Adapter
• FCC. CE, VCCI Class B
• 10/100Mbps Ethernet, Auto-Sensing
CPU
OS
I/O & Control
Requirements
Physical/Environmental
Software
Communication
• 1 set, 2 pin (relay, 24V DC 1A/125V AC 0.5A)
* NTSC: US Version; PAL: AU/EU/UK Version
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web:
Email: [email protected]
www.trendnet.com
