TRENDnet TV-IP400W - Wireless Advanced Pan Manuale utente
TV-IP400W
Advanced Pan & Tilt Wireless Internet
Camera Server
TEW-503PI (07-28-2005) TV-IP400W
rev:01.02.2007
FEATURES
The Pan/Tilt IP Camera is a full-featured surveillance system that
provides high quality video over a wireless network connection.
Built-in CPU and Web Server allow the camera to function as a
standalone device, allowing users to access the camera anywhere
in the world by using a Web browser. Users can also move the
camera remotely in almost any direction, scanning sensitive
locations for unauthorized intrusion. The IP Camera comes with a
CMOS sensor to deliver clear and crisp images, and its powerful
IPView software gives users enhanced security options to archive
streaming video straight to a computer's hard drive. IP View
software can also monitor multiple cameras on a single screen,
enable motion detection to trigger automatic recording, and send
email alert notification.
• Wi-Fi Compliant with IEEE 802.11b/g Devices on 2.4 GHz ISM Frequency Band
• Wireless Supports Infrastructure and Ad-Hoc Modes
• Wireless Supports WEP 64/128-bit Encryption (ASCII & HEX)
• Built-in Pan & Tilt Control for More Flexible Monitoring
• Supports 4x Digital Zoom for Close Up Images
• Supports Both Active X control for IE and Java applet for IE and Netscape Navigator
• Allows for Remote Access from Web Browser for Live Image Viewing
• Supports TCP/IP networking, SMTP e-mail, HTTP and other Internet related protocols
• Supports in a mixed Operating System Environment such as Windows and Macintosh
• Supports Web Configuration with Password Protection
• Powerful Windows IPView Application Software for multiple cameras monitoring, image capturing, and video recording (Windows
98/ME/2000/XP)
• Broad Range of Applications for Monitoring Homes, Offices, Banks, Hospitals, and a Variety of Private and Public Monitoring
• 3-Year Warranty
Resolution
Resolution / Frame Rate Setting
Lens
Min. Illumination
LAN
Protocol
Left/Right Reversal
Up/Down Reversal
Digital Zoom
Light Frequency
OS Support
Application
Browser
Gain/Exposure/White Balanced Control
Compression Rate
• ¼” Color CMOS Sensor
• 160 x 120, 320 x 240, 640 x 480 / 1, 5, 7, 15, 20, auto
• 640 x 480 pixel
• Yes
• Yes
• 5 Levels
• Internet Explorer (5.0 or above) or Netscape Navigator (6.0 or above)
• Built-in f: 6.0mm F:1.8
• 10/100Mbps Ethernet, Auto-Sensing
• Automatic
• HTTP, FTP, TCP/IP, UDP, ARP, ICMP, BOOTP, RARP, DHCP, PPPoE, DDNS, UPnP
• 30fps@QCIF • 25fps@CIF • 10fps@VGA
• 50Hz / 60Hz
• 4x
• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
• Windows 98SE, ME, NT4, 2000,XP
• IPView Software
Frame Rate
Compression / Selection
Communication
Video/Image
Software
Sensor
Image Sensor
Advanced Pan & Tilt Wireless Internet Camera Server
TV-IP400W
SPECIFICATIONS
• JPEG / Yes
RAM/Flash ROM
Dimension
OS
Pan
Tilt
Control
Weight
Consumption
Humidity
LED
Emissions
Power
Temperature
• RDC R2880
• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
• 8Mbytes/2Mbytes
• 117x115x105 mm (4.6”x4.5”x4”)
• 0.3kg (0.75lb)
• 5% ~ 95% Non-Condensing
• FCC. CE
• RTOS
• -156° ~ +156°
• -45° ~+70°
• 8 watt ( 1600mA x 5V), max
• Up, Down, Right, Left, Center
• 128MB (256MB Recommended)
• Operating: 5° C ~ 40° C (41° F ~ 104° F) • Storage: -25° C ~ 50° C (-13° F ~ 122° F)
• 5V DC, 2.5A External Adapter
• Power: Green • Link/Active: Orange
Memory Size
Requirements
Physical/Environmental
Pan & Tilt
CPU
System
• Pentium III, 450 MHz or above VGA card resolution: 800 x 600 or above
TV-IP400W
rev:01.02.2007
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
Advanced Pan & Tilt Wireless Internet Camera Server
TV-IP400W
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
RELATED PRODUCTS
TV-IP200W
TV-IP300
TV-IP300W
TV-IP200 Internet Camera Server
Wireless Internet Camera Server
Advanced Day/Night Internet Camera Server
Advanced Wireless Day/Night Internet Camera Server
PACKAGE CONTENTS
• CD-ROM (UG & Utility)
• Power Adapter (5V DC, 2.5 A)
• RJ-45 Cable (1.5m)
• Mounting Frame
• TV-IP400W
• Multi-Language QIG
Internet
Cable/DSL
Modem Office Monitoring
(TV-IP400)
Front Gate Monitoring
(TV-IP400)
Parking Monitoring
(TV-IP400W)
Warehouse Monitoring
(TV-IP400W)
Wireless
Access Point
(TEW-430APB)
100Mbps
54Mbps Wireless
Firewall Router
(TW100-BRF114)
Workstation with
PCI Adapter
(TE100-PCIWN)
+156°
-156°
+70°
-45°
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web:
Email: [email protected]
www.trendnet.com
