TRENDnet TE100-S86FX Manuale utente

TRENDnet's TE100-S86FX is a 2-port 10/100Base-TX and 6-

port 100Base-FX Switch best for campus and networks that

require greater distance than the standard 100 meters copper

wire. Furthermore, it offers reliable, easy-to-use, and

affordable LAN solution to meet an immediate network

bandwidth demand. With unique Fast Ethernet Switching

ASIC, TRENDnet's TE100-S86FX delivers the power of

100Mbps switching at a very economical price.

TE100-S86FX

2-port 10/100Base-TX and 6-port 100Base-FX Switch with SC Connector

10/100Mbps auto-negotiating and auto-sensing on

the TX ports

Supports half- and full-duplex modes on all the fiber

ports (Dip-switch controlled)

Supports store-and-forward

Plug and Play

Address filtering on all the ports

Front panel LEDs for switch operation status and

troubleshooting

True non-blocking switch architecture

Supports 1,024 MAC address entries per device

Back pressure flow control for half duplex mode

5 Year Warranty

FEATURES BENEFITS

Performance:

Flexibility:

Expandability:

Compatibility:

Reliability:

Support the centralized fiber

application.

The TE100-S86FX seamlessly

connects 10/100Base-TX and

100Base-FX.

Offers FX fiber ports for distance

expansion for longer than 100

meters.

Support all major network

operating systems.

The TE100-S86FX/S88FX are

dependable with 5 year warranty.

TE100-S81FX (12-04-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE100-S86FX: 2-port 10/100Base-TX and 6-port

100Base-FX Switch with SC Connector

TE100-S88FX: 8-port 100Base-FX Switch with

SC Connector

TE100-PCIFX: 100Base-FX Fast Ethernet

Adapter for PCI

TE100-TF: 100Base-TX to 100Base-FX SC-type

Converter

NETWORKING SOLUTIONS

SPECIFICATIONS

TE100-S86FX

2-port 10/100Base-TX and 6-port 100Base-FX Switch with SC Connector

TE100-S86FX

2-port 10/100Base-TX and 6-port 100Base-FX Switch with SC Connector

Standards:

• IEEE 802.3 10Base-T

• IEEE 802.3u 100Base-TX/FX

Cable:

• 10Base-T 2-pair UTP CAT 3, 4, 5 up to

100 meters (328 ft.)

• 100Base-TX 2-pair UTP CAT 5 up

to 100 meters (328 ft.)

• 100Base-FX 62.5/125 multi-mode fiber optics

cable up to 2,000 meters (6,560 ft.)

Switching Method:

• Store-and-forward

Forwarding Rate:

• 14,880 pps for 10Mbps,

148,800 pps for 100Mbps

AC Input:

• 100-250VAC, 47-63Hz internal power supply

Power Consumption:

• 20W

Temperature:

• Operating: 0° to 40° C (32° to 104° F)

• Storage: -25° to 70° C ( -13° to 158° F)

Humidity:

• 10 % to 90 % non-condensing

Dimensions:

• 440 x 205 x 45 mm (17.3 x 8 x 1.8 inches)

Weight:

• 2,500 grams (5.5 lbs.)

Certifications:

• FCC, CE, VCCI, UL

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
