TRENDnet TEG-2248WS - Gigabit Web Smart Switch Manuale utente
FCC Warning
This equipment has been tested and found to comply with the
regulations for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with this user’s guide, may cause harmful interference to
radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will
be required to correct the interference at his or her own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user may be required
to take adequate measures.
VCCI Warning
This is a product of VCCI Class A Compliance.
UL Warning
a) Elevated Operating Ambient Temperature- If installed in a closed
or multi-unit rack assembly, the operating ambient temperature of the
rack environment may be greater than room ambient. Therefore,
consideration should be given to installing the equipment in an
environment compatible with the manufacturer's maximum rated
ambient temperature (Tmra).
b) Reduced Air Flow- Installation of the equipment in a rack should
be such that the amount of air flow required for safe operation of the
equipment is not compromised.
c) Mechanical Loading- mounting of the equipment in the rack
should be such that a hazardous condition is not achieved due to
uneven mechanical loading.
d) Circuit Overloading- Consideration should be given to the
connection of the equipment to the supply circuit and the effect that
overloading of circuits might have on over current protection and
supply wiring. Appropriate consideration of equipment nameplate
ratings should be used when addressing this concern.
e) Reliable Earthing - Reliable earthing of rack-mounted equipment
should be maintained. Particular attention should be given to supply
connections other than direct connections to the branch circuit (e.g.,
use of power strips).
Ver. C1-1.00
i
TABLE OF CONTENT
About This Guide.................................................................................1
Purpose ............................................................................................1
Terms/Usage....................................................................................1
Introduction..........................................................................................3
Gigabit Ethernet Technology...........................................................3
Fast Ethernet Technology................................................................4
Switching Technology.....................................................................5
VLAN (Virtual Local Area Network)..............................................6
Features............................................................................................6
Unpacking and Installation ..................................................................9
Unpacking........................................................................................9
Installation .......................................................................................9
Rack Mounting ..............................................................................10
Connecting Network Cable............................................................11
AC Power.......................................................................................12
Identifying External Components......................................................19
Front Panel.....................................................................................19
Rear Panel......................................................................................20
Understanding LED Indicators ..........................................................21
Power and System LEDs ...............................................................21
100BASE-TX Port 1~48 Status LEDs...........................................22
mini-GBIC Port 49~50 Status LEDs..............................................22
1000BASE-T Port 49~52 Status LEDs..........................................22
Configuration.....................................................................................23
Installing the Web Management Utility.........................................23
Discovery List................................................................................24
Monitor List...................................................................................25
Device Setting................................................................................27
Toolbar...........................................................................................29
Configuring the Switch..................................................................30
Login..............................................................................................30
Setup Setting..................................................................................32
Port Settings...............................................................................32
IEEE 802.1Q VLAN..................................................................34
Trunk Setting .............................................................................47
Mirror Setting.............................................................................48
IEEE 802.1p Default Priority.....................................................49
Broadcast Storm Control Setting ...............................................50
Jumbo Frame Setting .................................................................50
Advanced Setting...........................................................................51
SNMP Setting ............................................................................51
Spanning Tree Setting................................................................53
802.1x Setting............................................................................55
IGMP Snooping Setting.............................................................56
IGMP VLAN Setting.................................................................59
System Setting ...............................................................................61
System Information....................................................................61
System Setting ...........................................................................62
ii
iii
Trap Setting................................................................................63
Password Setting........................................................................64
Statistic.......................................................................................65
Factory Reset .............................................................................67
Backup Setting...........................................................................67
Firmware Upload .......................................................................68
System Reboot...........................................................................68
Logout........................................................................................69
Technical Specifications....................................................................70
1
ABOUT THIS GUIDE
Congratulations on your purchase of the TEG-448WS 48-Port Gigabit
Web Smart Switch w/4 Shared Mini-GBIC Slots. This device
integrates 1000Mbps Gigabit Ethernet, 100Mbps Fast Ethernet and
10Mbps Ethernet network capabilities in a highly flexible package.
Purpose
This guide discusses how to install your TEG-448WS 48-Port Gigabit
Web Smart Switch w/4 Shared Mini-GBIC Slots.
Terms/Usage
In this guide, the term “Switch” (first letter upper case) refers to your
TEG-448WS 48-Port Gigabit Web Smart Switch w/4 Shared Mini-
GBIC Slots and “switch” (first letter lower case) refers to other
Ethernet switches.
