TRENDnet TEW-230APB Manuale utente

TRENDnet’s TEW-230APB Wireless Access Point is today’s link

to Wireless Technology. Compliant with the IEEE Wireless

Networking Standard 802.11b, it provides Direct Sequence

Spread Spectrum (DSSS) operation for transparent bridging and

roaming capabilities for wireless nodes. The TEW-230APB also

provides WDS bridging functions, allowing users to connect two

or more Access Points together, wirelessly. With TRENDnet’s

Wireless Access Point and Wireless Network Adapters, users

can connect to Ethernet/Fast Ethernet LAN at home or office to

access network resources such as hard drives, CD-ROM/DVD

drives, network printers, and Internet connection - with coverage

up to 300 meters.

TEW-230APB (C1)

11Mbps 802.11b Wireless Access Point

BENEFITSFeatures

Integration Friendly:

Economical:

Flexible:

Security:

Cost Effective:

Supports both Ethernet and Fast

Ethernet, with Web Browser

configuration for fast and easy setup

Attaches to Ethernet network at

anytime to add wireless users on the

network. Save time, labor, and

material for network cable installation

Works as stand-alone Access Point,

Single/Multiple Access Point(s)

Bridge, or Ethernet Access Point

Client

Provides 64/128-bit WEP Encryption,

WPA and 802.1x Authentication

Support

One unit provides multiple wireless

connections to wired LAN

Operates as Access Point, Access Point Client or WDS Wireless

Bridge/Repeater mode

Provides Security with 64/128-Bit WEP and WPA

Supports 802.1x Authentication and MAC Address Control for

Authorization Access (20 entries

Supports most operating systems, such as Windows

95/98/ME/NT/2000/XP, Unix and Mac

Allow Users to Disable ESSID Broadcast to increase wireless

security

10/100Mbps Auto-Sensing Fast Ethernet Port

Dynamic Data Rate Scaling at 11, 5.5, 2 and 1Mbps

Allow auto fallback data rate for optimized reliability, throughput

and transmission range

One 2dBi Detachable Diversity Antenna. Replace with optional

High-Gain antenna to extend the range/coverage area

Easy configuration and maintenance with Web Browser (HTTP)

Flash memory for firmware upgrade and save/restore settings

Distance coverage 40 to100 meters indoor, 100 to 300 meters

outdoors (depends on the environment)

3-Year Warranty

TEW-230APB (01-14-05)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TEW-230APB: 11Mbps 802.11b Wireless Access Point

TEW-226PC: 11Mbps 802.11b Wireless CardBus PC Card

TEW-228PI: 11Mbps 802.11b Wireless PCI Adapter

NETWORKING SOLUTIONS

SPECIFICATIONS

Standards:

• IEEE 802.11b, 802.3u

Modulation:

• Direct Sequence Spread Spectrum (DSSS)

Frequency Range:

• 2.4 ~ 2.497 Ghz

Data Rate:

• 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

(auto-fallback)

Operating Mode:

• AP, AP Client, WDS Bridging & Repeater

Channel:

• 1~ 14 Channels (Universal Support)

Security:

• 64/128-bit WEP (Hex & ASCII)

• WPA (TKIP)

• 802.1x Authentication

• MAC Address Access Control (ACL)

Antenna:

• 2 x 2dBi Detachable Diversity Antennas

with Female Reverse SMA connector

Output Power:

• 13 dBm (min)

Transmit Power:

• Adjustable 10dBm (12.5%), 12dBm (25%),

15dBm (50%) and 17dBm (100%)

Receiving Sensitivity::

• 11Mbps: -84dBm @ 8% PER

(Packet Error Rate)

• 2 Mbps: -90dBm @ 8% PER

(Packet Error Rate)

Media Connector:

• 10/100Mbps, Half/Full Duplex

LED Indicators:

• Power, LAN & WLAN

Power:

• 5V DC 1.2 A External Power Adapter

Dimensions:

• 124 x 86 x 40 mm (4.9 x 3.4 x 1.6 inches)

(without antenna)

Weight:

• 118g. (0.26 lb)

Temperature:

• Operating: -0° ~ 40°C (32° ~104°F)

• Storage: -10° ~ 70°C (14° ~ 158°F)

Humidity:

• Max. 90% (non-condensing)

Certification:

• FCC, CE

TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA

10/100Mbps

11Mbps Wireless

Workstation with

Wireless PCI Adapter

(TEW-228PI)

Notebook with

Wireless PC Card

(TEW-226PC)

Cable/DSL 4-Port

Firewall Router

(TW100-BRF114)

Workstation with

PCI Adapter

(TE100-PCIWN)

Cable/DSL

Modem

Internet

11Mbps 802.11b Wireless Access Point

(TEW-230APB)

TEW-230APB (C1)

11Mbps 802.11b Wireless Access Point
