TYAN 1.00 Manuale utente
Tyan S1894
Tigercub 100
Motherboard Users Manual
Revision 1.10
Copyright © Tyan Computer Corporation, 1998. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from Tyan
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are propery of their respective companies including, but not limited to the
following.
Award BIOS is a trademark of Award Software Incorporated.
Windows is a trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
INTEL, Pentium II, Celeron are trademarks of Intel Corporation.
S1894 Tigercub 100 Micro-ATX is a trademark of TYAN Computer Corporation.
Information contained in this publication has been carefully checked for accuracy and
reliability. In no event will Tyan Computer be held liable for any direct or indirect,
incidental or consequential damage, loss of use, loss of data, or other malady resulting
from errors or inaccuracies of information contained in this manual. The information
contained in this document is subject to change without notice.
PRINTED IN USA.
Table of Contents
1. Introduction...........................................................................4
Overview........................................................................ 4
Icons.............................................................................. 5
Hardware Specifications/Features................................... 6
Software Specifications...................................................8
Technical Support......................................................... 8
2. Board Installation.............................................................. 10
Unpacking....................................................................10
Installation................................................................... 10
Setting Jumpers............................................................ 24
3. Onboard Resource Settings.............................................. 26
Quick Reference for Jumpers........................................26
Map of Motherboard Jumpers....................................... 27
Hardware CMOS & Password Reset............................30
Soft Power Connector.................................................. 32
Speaker Connector Installation...................................... 32
Hardware Reset Switch Connector Installation............... 32
External SMI............................................................... 32
Chassis Intrusion Alarm Connector................................ 33
Ensoniq Audio Connectors............................................ 33
CMOS RTC.................................................................33
Flash EEPROM........................................................... 34
RAM Installation.......................................................... 34
Cache Memory.............................................................36
Frequently Asked Questions.......................................... 37
4. BIOS Configuration...........................................................40
Introduction to Setup.....................................................40
Main Setup Menu......................................................... 44
Standard CMOS Setup..................................................46
BIOS Features Setup....................................................50
Chipset Features Setup................................................. 54
Power Management Setup............................................ 58
PnP/PCI Configuration ................................................ 62
Integrated Peripherals...................................................65
PC Health Monitor....................................................... 68
Supervisor Password.................................................... 68
Flash Writer Utility........................................................69
5. System Resources............................................................. 72
POST Messages.......................................................... 72
6. Appendix 1 - CPU Retention Module Options.................76
7. Appendix 2 - Glossary........................................................78
http://www.tyan.com
4
Chapter 1
Introduction
Overview
The S1894SLATigercub 100 Micro ATX is a quality, high performance
motherboard designed for Intel Pentium II microprocessors. This motherboard
utilizes the Intel 440BX / 440ZX or VIAAGPset and can support CPU speeds
of 233MHz through 450MHz, and host bus speeds of 66MHz to 100MHz.
The S1894SLAmotherboard, with built-in AGP slot, provides high performance
capabilities that are ideal for a wide range of demanding applications such as
CAD, CAM, CAE, desktop publishing, 3D animation, and video production.
This integrated system board achieves high reliability with numerous features
and yet is small enough to be supported in a Micro ATX form factor. Some of
the features included are onboard dual channel PCI PIO, BUS Master IDE and
UltraDMA/33, onboard Ensoniq 1371 PCI Wavetable sound, onboard floppy
controller, and onboard high speed I/O.
Flexibility and expandability have been designed into the Tigercub 100. With I/
O and drive controller support built onboard, the one AGP slot, three PCI and
one ISA slots (one shared, four usable) are free for add-on expansion cards.
Remember to take a look at TYAN Computers web site located at
chapter 1
Introduction
S1894 Tigercub 100
5
INTRO
http://www.tyan.com. There you can find information on all of TYANs
products along with FAQs, distributors list, drivers, and BIOS setting explana-
tions.
Icons
In order to help you navigate this manual and set up your system, we have
added several icons to our format.
This icon alerts you to particularly important details regarding
the setup or maintenance of your system. This icon often
appears next to information that may keep you from damaging
your board or system. While we will often point out the most
vital paragraphs in a chapter, you should always read every word in the text.
Failing to do so can lead to exasperation and expense.
Wherever possible, we have included step-by-step instructions
for setting up your system, which are indicated by this icon.
However, it is in your best interest to read an entire section (and
perhaps the entire manual) before you begin to fiddle with your
motherboard.
While we have alerted you to potential dangers in several places
in the manual with this icon, these warnings should not be
regarded as the whole of your safety regimen. Never forget that computers are
electrical devices, and are capable of delivering a shock. Prevent damage to
yourself and to your board: always ensure that your system is turned off and
unplugged whenever you are working with it, and that you are equipped with a
static safety device.
!
important!
procedure
1.
2.
3.
warning
http://www.tyan.com
6
Chapter 1
Introduction
Hardware Specifications/Features
Processor Information One SEC slot (Slot One type)
66 to 100MHz bus support
Pentium II 233-450MHz (Celeron)
Supports Celeron CPU
VRM component installed on-board
On-board CPU/case fan headers
Chipset Information Intel 440BXAGPset,
Intel 440ZXAGPset, or
ViaAGPset
Intel PIIX4e controller
National 351 Super I/O chipset
Voltage and Power ATX power supply connector
Information +12V power source for DC fan
onboard
3.3V DRAM support
Utilizes GTL+ bus to reduce power
consumption and EMI
Main Memory Up to 256MB onboard
(386MB for BX - without registered
buffer)
Three 168-pin DIMM sockets
(Two 168-pin DIMM for ZX)
Supports 100MHz SDRAM w/SPD,
and SDRAM+ECC
System Management ADM9240 control chip with on-board
alarm for heat, fan and voltage
System Management software
Chassis intrusion detection capable
Expansion Slots One 32-bit AGP slot
Three 32-bit PCI BUS Master slots
One 16-bit ISA slots
One shared, four usable slots
S1894 Tigercub 100
7
INTRO
Physical Dimensions Micro-ATX design
7.5 inches x 9.0 inches
Double-row ATX connectors
BIOS Information Award Plug nPlay flash BIOS
Deep Green, Energy Star, PC98, and
Year 2000 compliant
LED for sleep mode
Disk Drive & System I/O Two PCI bus mastering EIDE
channels
Supports EIDE CD-ROMs
PIO Mode 3 & 4 (up to 17MB/sec
DTR)
UltraDMA/33 (UIDE) built-in
(up to 33MB/sec DTR)
Bus Mastering Mode (up to 22MB
/sec DTR)
Support for two floppy drives (up to
2.88MB)
Two serial ports (16550 UARTs)
One ECP/EPP parallel port
One IR (InfraRed) I/O interface port
Two USB rev 1.2 ports
One PS/2 mouse port
One PS/2 keyboard port
Wake-on LAN feature header (3-pin)
(requiresATX 2.01 power supply)
Power supply fan control connector
Ensoniq ES 1371AudioPCI AC97 Codec
Uses a single, shared IRQ
High performance PCI bus master
Spatial enhanced 3D sound (SWS)
Wavetable synthesis built in
Joystick,Audio in, Speaker,
Microphone connectors
http://www.tyan.com
8
Chapter 1
Introduction
Software Specifications
OS Operates with MS-DOS, Windows
3.x, Windows for WorkGroup 3.x,
Windows 95, Windows 98, Windows
NT, OS/2, Novell Netware, and SCO Unix.
Information presented in this publication has been carefully checked for
reliability. However, no responsibility is assumed for inaccuracies. The
information contained in this document is subject to change without notice.
Technical Support
If a problem arises with your system, you should turn to your dealer for help
first. Your system has most likely been configured by them, and they should
have the best idea of what hardware and software your system contains.
Hence, they should be of the most assistance. Further, if you purchased your
system from a dealer near to you, you can actually bring your system in to
them to have it serviced, instead of attempting to do so yourself (which can
have expensive consequences).
If your dealer is unable to assist you,
(1) Try our web page: http://www.tyan.com
(2) User Newsgroup: alt.comp.periphs.mainboard.tyan
(3) Technical support phone line: (510)-440-8808
S1894 Tigercub 100
9
Unpacking
INTRO
This page left blank intentionally
http://www.tyan.com
10
Chapter 2
Board Installation
chapter 2
Board Installation
The motherboard package should contain the following:
(1) S1894SLA motherboard
(1) 40-pin IDE and 34-pin floppy cable pack
(1) S1894 Users manual
(1) CPU retention module
(1) System Management & Driver CD (Intel LANDesk optional) with Ensoniq
AudioPCI manual and installation instructions
Installation
You are now ready to install your motherboard. The mounting hole pattern of
the S1894 matches the MicroATX system board specifications. The S1894 will
fit in a Micro ATX or a standard ATX chassis.
Quick References for Jumpers
Altri manuali per 1.00
2
Questo manuale è adatto per i seguenti modelli
1
Altri manuali TYAN Scheda madre
TYAN
TYAN S1570 AT Manuale utente
TYAN
TYAN TOMCAT I7221 Manuale utente
TYAN
TYAN S7002 Manuale utente
TYAN
TYAN Tempest i5000VS S5372-LC Manuale utente
TYAN
TYAN Tiger i7505 Manuale utente
TYAN
TYAN S7105 Manuale utente
TYAN
TYAN S5548GM4NED83-4T Manuale utente
TYAN
TYAN THUNDER K8SE Manuale utente
TYAN
TYAN TOMCAT I875P Manuale utente
TYAN
TYAN S8032 Manuale utente
TYAN
TYAN THUNDER K7 Manuale utente
TYAN
TYAN Tiger 230T S2507T Manuale utente
TYAN
TYAN S3227 Manuale utente
TYAN
TYAN Tempest i5000VS S5372 Manuale utente
TYAN
TYAN TOMCAT IVS D Manuale utente
TYAN
TYAN Tempest i5100X S5375 Manuale utente
TYAN
TYAN THUNDER HESL-T Manuale utente
TYAN
TYAN S2932-E Manuale utente
TYAN
TYAN THUNDER I7505 Manuale utente
TYAN
TYAN Tiger 100 S1832DL Manuale utente
Manuali Scheda madre popolari di altre marche
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuale utente
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
