Trinity 510 Manual

Revision 2.01

S2266

reproduced or translated without prior written consent from TYAN Computer Corp.

All registered and unregistered trademarks and company names contained in this manual are

property of their respective owners including, but not limited to the following.

TYAN, Trinity 510 S2266 are trademarks of TYAN Computer Corporation.

Intel, Intel Pentium, combinations thereof are trademarks of Intel Corporation.

VIA, P4X266, P4X, and combinations thereof are trademarks VIA Technology Inc.

Award, Award BIOS are trademarks of Phoenix Technologies Ltd.

Microsoft, Windows are trademarks of Microsoft Corporation.

IBM, PC, AT, PS/2 are trademarks of IBM Corporation.

Winbond is a trademark of Winbond Electronics Corporation.

Micronics is a trademark of Micronics Corporation.

Portable Document Format (PDF) is a trademark of Adobe Corporation.

Information contained in this document is furnished by TYAN Computer Corporation and has been

reviewed for accuracy and reliability prior to printing. TYAN assumes no liability whatsoever, and

disclaims any express or implied warranty, relating to sale and/or use of TYAN products including

liability or warranties relating to fitness for a particular purpose or merchantability. TYAN retains the

right to make changes to product descriptions and/or specifications at any time, without notice. In

no event will TYAN be held liable for any direct or indirect, incidental or consequential damage,

loss of use, loss of data or other malady resulting from errors or inaccuracies of information

contained in this document.

http://www.TYAN.com

Table of Contents

Before you begin…

Chapter 1: Introduction

1.1 Congratulations

1.2 Hardware Specifications

1.3 Software Specifications

Chapter 2: Board Installation

2.1 Jumper Layout

2.2 Front Panel Connector

2.3 CMOS Reset

2.4 USB 1 and 2

2.5 Mounting the motherboard

2.6 Installing Memory

2.7 Installing the CPU and Cooling Fan

2.8 Connecting IDE/Floppy Drives

2.9 Installing Add-in Cards

2.10 Connecting PS/2, USB, Serial

2.11 Connecting the Power Supply

2.12 You’re Done!

Chapter 3: BIOS Setup

3.1 Main Setup

3.2 Advanced

3.3 Advanced CMOS Features

3.4 Advanced Chipset Features

3.5 Integrated Peripherals

3.6 VIA OnChip IDE Device

3.7 VIA OnChip PCI Device (Optional)

3.8 Super IO Configuration

3.9 Power Management Setup

3.10 IRQ/Event Activity Detect

3.11 IRQs Activity Monitoring

3.12 Frequency/Voltage Control

3.13 Exit and Saving

Chapter 4: Installing the Hard Drives

Chapter 5: System Resources

5.1 Beep Codes

5.2 Flash Utility

Appendix I: Memory Installation Instructions

Appendix II: Glossary

Technical Support

……………………………………………..Page 4

……………………………………………..Page 5

……………………………………………..Page 6

……………………………………………..Page 7

……………………………………………..Page 8

..……………………………………………Page 8

..……………………………………………Page 9

..…………………………………………Page 10

..…………………………………………Page 11

..…………………………………………Page 12

……………………………………………Page 15

……………………………………………Page 17

……………………………………………Page 18

……………………………………………Page 19

……………………………………………Page 20

……………………………………………Page 21

……………………………………………Page 22

……………………………………………Page 23

……………………………………………Page 24

……………………………………………Page 25

……………………………………………Page 26

……………………………………………Page 27

……………………………………………Page 29

……………………………………………Page 30

……………………………………………Page 31

……………………………………………Page 36

http://www.TYAN.com

Before you begin…

Check the box contents!

The retail motherboard package should contain the following:

1x Trinity 510 motherboard

1x Pentium 4 Heatsink Mounting Kit

1x 34-Pin floppy drive cable

1x Ultra-DMA-100/66/33 IDE cable

1x Trinity 510 user’s manual

1x TYAN driver CD

1x I/O shield with 1 LAN port (optional)

If any of these items are missing, please contact your vendor/dealer for replacement before

continuing with the installation process.

http://www.TYAN.com

Chapter 1: Introduction

1.1 Congratulations!

You are now the owner of the TYAN Trinity 510 motherboard, the most reliable, high performance

motherboard for Pentium 4 processing. Designed to be portable as well as flexible, the Trinity 510

can fit into standard ATX chassis. This platform utilizes VIA’s high-performance P4X266 chipset,

enabling next generation application and platform support. Intel Pentium 4 processors (2GHz) are

supported. *Please see TYAN’s website for updates and information concerning CPU information

and support:

http://www.tyan.com

This integrated performance board is supported in an ATX form factor. Features of the Trinity 510

include onboard UltraDMA-100/66/33, optional integrated 100Mbit LAN, optional AC’97 Audio and

multiple boot options.

With both I/O and drive controller support onboard, five 32-bit PCI slots provide upgrade solutions

for future add-in cards. Optional integrated audio reduces overall system costs as well as optional

blazing fast 100Mbit LAN is integrated, providing instant high speed connectivity without any

hassles.

The Trinity 510 supports up to 2GB of unbuffered or registered PC1600/PC2100 DDR SDRAM.

Remember to visit TYAN’s Website at http://www.tyan.com. There you can find information on all

of TYAN’s products with FAQs, distributors list and BIOS setting explanations.

1.2 Hardware Specifications

Processor

•Single PGA478 socket

•Supports one Intel Pentium 4 processor

•Onboard VRM (VRM 9.0 spec)

•Front-side Bus support for 400MHz

Chipset

•VIA P4X266 chipset

•VT8753 north bridge and VT8233 south

bridge

•Winbond LPC Super I/O ASIC

Memory

•Four 2.5v 184-pin DDR DIMM sockets

•Supports up to 2GB of unbuffered or

registered PC1600/2100 DDR RAM

Expansion Slots

•One AGP 4X slot (1.5v design)

•Five 32-bit/33MHz PCI slots (5.0v, version

2.2)

•Total of six usable slots

Integrated Audio (optional)

•VIA VT1611A controller

•AC’97 audio codec

•One MIDI/Game port

•Line-in, Line-out and Mic-in ports

Integrated LAN (optional)

•Onboard network controller

•10/100Mbit data transfer rate

•3-pin Wake-on-LAN (WoL) header

Hardware Monitoring

•Winbond hardware monitoring ASIC

•CPU Temp, voltage and fan monitoring

BIOS

•Award 2Mb BIOS Flash ROM

•Supports APM v1.2 and ACPI v1.0

•User settings for hardware monitoring

•Auto-configure IDE drive types

•Multiple boot options

•DMI 2.0 compliant

http://www.TYAN.com

Integrated PCI IDE

•Dual-channel master mode

•Up to four Enhanced IDE devices

•Support for ATA-100/66/33 IDE and ATAPI

compliant devices

Integrated I/O

•One floppy connector supports up to two

drives

•Two 9-pin 16550-based serial ports

•One 25-pin SPP/ECP/EPP parallel port

•Two USB ports (two via optional cables)

•PS/2 keyboard and mouse ports

Form Factor

•ATX footprint (12” x 9.6”, 304.8mm x

243.84mm

•One 20-pin ATX power connector

•Stacked USB (two) ports and LAN (one-

optional) ports

•Stacked keyboard and mouse ports

Regulatory

•FCC DoC (declaration of Conformity)

•European Community of CE (declaration of

Conformity)

Note: The Trinity 510 S2266 accepts a standard ATX 2.01 power supply, with a minimum

output of 30 amps on the 5-volt line.

1.3 Software Specifications

OS Windows 9x/ME/NT/2000

http://www.TYAN.com

Chapter 2: Board Installation

Installation

You are now ready to install your motherboard. The mounting hole pattern of the Trinity 510

matches the ATX system board specifications. Your chassis should support a standard ATX

motherboard form factor.

How to install our products right… the first time

The first thing you should do is read this user’s manual. It contains important information which will

make configuration and setup much easier. Here are some precautions you should take when

installing your motherboard:

(1) Ground yourself properly before removing your motherboard from the antistatic bag.

Unplug the power from your computer power supply and then touch the power supply.

For the safest conditions, TYAN recommends wearing a static safety wrist strap.

(2) Hold the motherboard by its edges and do not touch the bottom of the board.

(3) Avoid touching the motherboard components, IC chips, connectors, and leads.

(4) Avoid touching memory module contacts and IC chips

(5) Place the motherboard on a grounded antistatic surface or on the antistatic bag from

which it came in.

Having reviewed the precautions above, the next step is to take the motherboard out of the

cardboard box and static bag, hold it by its edges and place it on a grounded antistatic surface,

component side up. Inspect the board for damage.

NOTE DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED

http://www.TYAN.com

2.1 – Jumper Section

Pin outs for certain connectors are available on the TYAN website: http://www.TYAN.com

2.2 – Front Panel Connector (J26)

17 15 13 11 9 7 5 3 1

18 16 14 12 10 8 6 4 2 1,3: HD LED

2,4: Power LED

5,7: Reset Switch

6,8: Power Switch

2.3 – CMOS Reset (J15)

1 2 1,2: Connect these two pins together to reset the CMOS settings in case an incorrect

setting causes system instability or you have forgotten your system/setup password or

have just flashed your BIOS.

-Power off the system and disconnect the power supply.

-Close pins 1 and 2 on J15

-Wait about 5 seconds

-Open pins 1 and 2 on J15

-Reconnect the power supply and power on the system

2.4 – USB 1 and 2 (JUSB1, JUSB2) - Optional

2 4 6 8 10

1 3 5 7 9 Use the USB1 and USB2 headers here for front panel USB connectors.

http://www.TYAN.com

Note: All other jumpers on the Trinity 510 are NOT user

adjustable.

Also, for the IDE and floppy connectors on the motherboard,

Pin 1 is located towards the inside of the motherboard

whereas the last pins are towards the edge of the board.

Please see page 28 for IDE pin diagram.

http://www.TYAN.com

2.5 Mounting the motherboard

Your chassis may include mounting hardware. If mounting hardware was included, you can use

the following examples to help you in stalling your motherboard into the chassis.

If your chassis has the studs integrated into the chasses wall, then you would only need to use

screws (possibly included with your chassis) to install the motherboard. See examples (Figure 2.0,

shown below for more details.

If the chassis includes mounting hardware without the studs pre-installed, then you will need to

install the motherboard using the mounting hardware as shown in the examples below.

Remember not to over tighten any of the screws, or you may risk breaking internal traces in the

surrounding area, or damage the motherboard in some other way.

Other examples of how to install your motherboard using other hardware (that may or may not

have been included with your chassis) are shown below.

chassis wall

stud

screw

motherboard

base

One solution for installing motherboardType of hardware Another solution Another solution

chassis wall

standoff

motherboard

base

chassis wall

standoff

motherboard

base

NOTE The diagrams above are only representative of a few solutions for installing a

motherboard into the chassis. The installation procedure for installing your

motherboard into the chassis may differ.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali TYAN Scheda madre

TYAN

TYAN THUNDER K8S Manuale utente

TYAN

TYAN S2505T Istruzioni per l'installazione e il funzionamento

TYAN

TYAN THUNDER I7505 Manuale utente

TYAN

TYAN S7103 Manuale utente

TYAN

TYAN TOMCAT I7230B Manuale utente

TYAN

TYAN Tempest i5000VS S5372 Manuale utente

TYAN

TYAN THUNDER H2000M Manuale utente

TYAN

TYAN THUNDER N4250QE Manuale utente

TYAN

TYAN S5620 Manuale utente

TYAN

TYAN TIGER K8W Manuale utente

TYAN

TYAN S1668 Manuale utente

TYAN

TYAN Tempest i5000VF S5370 Manuale utente

TYAN

TYAN S7086 Manuale utente

TYAN

TYAN THUNDER K7 Manuale utente

TYAN

TYAN Tomcat i875P S5102 Manuale utente

TYAN

TYAN TAHOE AT Manuale utente

TYAN

TYAN TIGER MPX Manuale utente

TYAN

TYAN THUNDER X Manuale utente

TYAN

TYAN TAHOE 2 ATX Manuale utente

TYAN

TYAN Tomcat i7221 S5150 Manuale utente

TYAN

TYAN THUNDER K8SR Manuale utente

TYAN

TYAN TOMCAT I845GL Manuale utente

TYAN

TYAN TITAN TURBO ATX-2 Manuale utente

TYAN

TYAN TOMCAT I815E Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
