Univex 7512 Manuale utente

7512

April 2005

Printed in USA

SLICER

UNIVEX CORPORATION ■3 Old Rockingham Road ■Salem, NH 03079-2140

Tel 603-893-6191 ■Fax 603-893-1249 ■E-mail univex@univexcorp.com

TOLL-FREE ORDERING FAX 1-800-356-5614

www.univexcorp.com

Our main ingredient is value

SINCE 1948

™

The most popular workhorse in Food

and Deli slicing is the 12" Slicer.

Again, Univex with its model #7512

Slicer offers the maximum weight and

horsepower. . . the keys to precision

slice production. A redesigned

slice control mechanism

now allows slices up to

1 3/16” thick. As with all

Univex Slicers the 7512

comes equipped with a

German hollow ground

cutting blade and built-in

sharpener.

WARRANTY

The Model 7512 Duro Slicer carries a one-year, on-site parts and labor warranty against any flaws in materials and workmanship. This period begins with the date of purchase and,

provided the unit is used properly in accordance with our instructions, is in full effect for one year from that date. Any work to be performed under this warranty must be performed

between the hours of 8:00 a.m. and 5:00 p.m. local time, Monday through Friday. Univex will not pay overtime charges for work performed other than during normal business hours.

Damages incurred in transit or from installation error, accident, alteration or misuse are not covered. Transit damages should be reported to the carrier immediately. Univex shall not

be liable for any consequential, compensatory, incidental, or special damages. Contact Univex Service Department for any warranty claims.

HEAVIEST DUTY – EXTRA-WIDE 1 3/16" CUT

ELECTRICAL: 115/60/1* - 3.9 Amps

*Consult Price List or factory for special voltages

MOTOR: 1/3 HP Capacitor start, capacitor run,1625 RPM

SPEED: Blade Speed = 475 rpm

CARRIAGE: Manual Operation

FINISH: Polished Anodized Aluminum

PRODUCT CUT:

STANDARD EQUIPMENT: 12" (305mm) German hollow ground hardened steel, high carbon chrome plated blade.

Built-in sharpener. Pilot Light indicating Knife and Motor (ON). Heavy duty multi-position

meat holder.

OPTIONAL ACCESSORIES: Vegetable Chute

BODY DIMENSIONS: 23" (584mm) high, 28 1/2" (724mm) wide, 24" (610mm) long

NET WEIGHT: 80lbs. (36kg)

SHIPPING WEIGHT: 92lbs. (42kg)

BOX DIMENSIONS: 23" (584mm) high, 28 1/2" (724mm) wide, 24" (610mm) long

NEW EXTRA WIDE 1 3/16" CUT

7512

SPECIFICATIONS

7512

April 2005

Printed in USA

UNIVEX CORPORATION ■3 Old Rockingham Road ■Salem, NH 03079-2140

Tel 603-893-6191 ■Fax 603-893-1249 ■E-mail univex@univexcorp.com

TOLL-FREE ORDERING FAX 1-800-356-5614

www.univexcorp.com

SINCE 1948

*21"

533 mm

*20 1/2"

521 mm

*19"

483 mm

Max. Width per stroke 8" 203mm

Max. Length per stroke 9" 229mm

Max. Thickness per stroke 1 3/8" 30 mm

SLICER

™
