Uplus Lighting 250 LED BEAM Manuale utente

User manual

250 LED BEAM

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

Technical Specifications…………………………………………………………………………4

Control Menu ……………………………………………………………………………………5-6

DMX Channels …………………………………………………………………………………6-11

Trouble Shooting…………………………………………………………………………………11

Fixture Cleaning………………………………………………………… ………………………11

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Light source: 250W LED white light module (The new generation of built-in light guide column

technology, perfect light concentration, super-bright brightness,)

Maximum power: 350W

Power supply: Wide voltage input switching power supply 100V-240V 50-60Hz

Color temperature: 6500K

Lamp life: 50000 hours

Control mode: DMX512 signal input, automatic operation

Channel mode: 16CH/20CH

X/Y scan: horizontal 540°, vertical: 270°

Color: 12 color +White

Fixed pattern: 14 fixed patterns + white light, dithering effect

Dimming: 0-100% linear dimming

Strobe: Synchronous pulse strobe, random pulse strobe

Prism disk: 8 prism

Beam angle: 2°

Focusing: the pattern can be adjusted freely

Display: color LCD display, Chinese and English display, reverse display

The system has an RDM function to remotely modify the address code.

Efficient heat pipe cooling system, no risk of lamp damage

Protection level: IP20

Dimension: 323*207*560 mm, NW:12.5KGS

NW: folding hooks version is 13.5kg

3.Control Menu

Menu Operation

On the base of the control panel offers a number of features, such as setting DMX fixture address,

switch the lamp, run the test program, the mode selection.

MAIN

SECOND

THIRD

Dmx Address

1 - 512

Fixture

Dmx Mode

STD/EXT

Run Mode

DMX/Host/Sound

Pan Invert

Close/Open

Tilt Invert

Close/Open

Manual

Color

0 - 255

Strobe

0 - 255

Dimmer

0 - 255

Fix gobo

0 - 255

⁞

Information

Time

Current Time：xxx H

Show Time：xxx H

Power Count：xxx

Sensor

Pan

Tilt

Temp

⁞

Software Version

Panel：Vx.xxx

Motor：Vx.xxx

4.DMX Channels

Model 1- CH16

Channel

Feature

DMX value

Function

CH 1

Color

0-4

white

5-9

white + color 1

10-14

color 1

15-19

color 1 + color 2

20-24

color 2

25-29

color 2+ color 3

30-34

color 3

35-39

color 3+ color 4

40-44

color 4

45-49

color 4+ color 5

50-54

color 5

55-59

color 5+ color 6

60-64

color 6

65-69

color 6+ color 7

70-74

color 7

75-79

color 7+ color 8

80-84

color 8

85-89

color 8+color 9

90-94

color 9

95-99

color 9+color 10

Factory

Password

0 - 255

Pan

0 - 255

Tilt

0 - 255

Dimmer

0 - 255

Color

0 - 255

FixGobo

0 - 255

⁞

Reset

XY reset

Off/Run

Motor reset

Off/Run

All Reset

Off/Run

Factory

Off/Run

Display

Language

CH/EN

Display Flip

Normal / Reverse

Display Mode

60s / Show

CH 1

Color

100-104

color 10

105-109

color 10+color 11

110-114

color 11

115-119

color 11+color 12

120-124

color 12

125-129

color 12+White

130-189

FAST ROTATION - SLOW ROTATION

190-194

STOP

195－255

SLOW ROTATION - FAST ROTATION

CH 2

Strobe

0-3

4-103

strobe from slow to fast

104-107

Opening

108-207

Pulse strobe from fast to slow

208-212

Opening

213-251

random slow to fast

252-255

opening

CH 3

Dimmer

0-255

dimming

CH 4

Gobo

0-4

white

5-9

Gobo 1

10-14

Gobo 2

15-19

Gobo 3

20-24

Gobo 4

25-29

Gobo 5

30-34

Gobo 6

35-39

Gobo 7

40-44

Gobo 8

45-49

Gobo 9

50-54

Gobo 10

55-59

Gobo 11

60-64

Gobo 12

65-69

Gobo 13

70-74

Gobo 14

75-78

White

79-86

Gobo 1 Jitter

87-94

Gobo 2 Jitter

95-102

Gobo 3 Jitter

103-110

Gobo 4 Jitter

111-118

Gobo 5 Jitter

119-126

Gobo 6 Jitter

127-134

Gobo 7 Jitter

135-142

Gobo 8 Jitter

143-150

Gobo 9 Jitter

151-158

Gobo 10 Jitter

159-166

Gobo 11 Jitter

167-174

Gobo 12 Jitter

175-182

Gobo 13 Jitter

CH 4

Gobo

183-190

Gobo 14 Jitter

191-220

FAST ROTATION - SLOW ROTATION

221-225

Stop

226-255

SLOW ROTATION - FAST ROTATION

CH 5

Prism

0－127

Reserve

128-255

prism Insert

CH 6

Prism Rot

0－127

Rotation

128－190

FAST ROTATION - SLOW ROTATION

191－192

stop

193－255

SLOW ROTATION - FAST ROTATION

CH 7

7Colors

0－127

Reserve

128-255

7Colors Insert

CH 8

Frost

0－127

white

128-255

Frost Insert

CH 9

Foucs

0－255

Foucs，Linear

CH 10

Pan

0－255

Pan

CH 11

Pan fine

0－255

Pan fine

CH 12

Tilt

0－255

Tilt

CH 13

Tilt fine

0－255

Tilt fine

CH 14

P/T Speed

0－255

P/T Speed

CH 15

Reset

0－249

Reserve

250－255

All Reset

CH 16

Reserve

0－255

Reserve

Model 2- CH20

Channel

Feature

DMX value

Function

CH 1

Color

0-4

white

5-9

white + color 1

10-14

color 1

15-19

color 1 + color 2

20-24

color 2

25-29

color 2+ color 3

30-34

color 3

35-39

color 3+ color 4

40-44

color 4

45-49

color 4+ color 5

50-54

color 5

55-59

color 5+ color 6

60-64

color 6

65-69

color 6+ color 7

70-74

color 7

75-79

color 7+ color 8

80-84

color 8

CH 1

Color

85-89

color 8+color 9

90-94

color 9

95-99

color 9+color 10

100-104

color 10

105-109

color 10+color 11

110-114

color 11

115-119

color 11+color 12

120-124

color 12

125-129

color 12+White

130-189

FAST ROTATION - SLOW ROTATION

190-194

STOP

195－255

SLOW ROTATION - FAST ROTATION

CH 2

Strobe

0-3

4-103

strobe from slow to fast

104-107

Opening

108-207

Pulse strobe from fast to slow

208-212

Opening

213-251

random slow to fast

252-255

opening

CH 3

Dimmer

0-255

dimming

CH 4

Gobo

0-4

white

5-9

Gobo 1

10-14

Gobo 2

15-19

Gobo 3

20-24

Gobo 4

25-29

Gobo 5

30-34

Gobo 6

35-39

Gobo 7

40-44

Gobo 8

45-49

Gobo 9

50-54

Gobo 10

55-59

Gobo 11

60-64

Gobo 12

65-69

Gobo 13

70-74

Gobo 14

75-78

White

79-86

Gobo 1 Jitter

87-94

Gobo 2 Jitter

95-102

Gobo 3 Jitter

103-110

Gobo 4 Jitter

111-118

Gobo 5 Jitter

119-126

Gobo 6 Jitter

127-134

Gobo 7 Jitter

135-142

Gobo 8 Jitter

143-150

Gobo 9 Jitter

151-158

Gobo 10 Jitter

CH 4

Gobo

159-166

Gobo 11 Jitter

167-174

Gobo 12 Jitter

175-182

Gobo 13 Jitter

183-190

Gobo 14 Jitter

191-220

FAST ROTATION - SLOW ROTATION

221-225

Stop

226-255

SLOW ROTATION - FAST ROTATION

CH 5

Prism

0－127

Reserve

128-255

prism Insert

CH 6

Prism Rot

0－127

Rotation

128－190

FAST ROTATION - SLOW ROTATION

191－192

stop

193－255

SLOW ROTATION - FAST ROTATION

CH 7

7Colors

0－127

Reserve

128-255

7Colors Insert

CH 8

Frost

0－127

white

128-255

Frost Insert

CH 9

Foucs

0－255

Foucs，Linear

CH 10

Pan

0－255

Pan

CH 11

Pan fine

0－255

Pan fine

CH 12

Tilt

0－255

Tilt

CH 13

Tilt fine

0－255

Tilt fine

CH 14

P/T Speed

0－255

P/T Speed

CH 15

Reset

0－249

Reserve

250－255

All Reset

CH 16

Reserve

0－255

Reserve

CH 17

Reserve

0－255

Reserve

CH 18

Color speed

0－255

Fast to Slow

CH 19

Gobo speed

0－255

Fast to Slow

CH 20

Focus speed

0－255

Fast to Slow

Indice

Altri manuali Uplus Lighting Attrezzatura di illuminazione

Uplus Lighting

Uplus Lighting PF350 Manuale utente

Uplus Lighting

Uplus Lighting 6 EYE RETRO BAR Manuale utente

Uplus Lighting

Uplus Lighting 10X30 COB BAR Manuale utente

Uplus Lighting

Uplus Lighting RETRO 360 Manuale utente

Uplus Lighting

Uplus Lighting IP-L360 Manuale utente

Uplus Lighting

Uplus Lighting COB400 ZOOM Manuale utente

Uplus Lighting

Uplus Lighting 230 BEAM Manuale utente

Uplus Lighting

Uplus Lighting BL6 Manuale utente

Uplus Lighting

Uplus Lighting W1925 Manuale utente

Uplus Lighting

Uplus Lighting PIXEL IP20X15 BAR Manuale utente

Uplus Lighting

Uplus Lighting LED PROFILE MZ Manuale utente

Uplus Lighting

Uplus Lighting W3725 Manuale utente

Uplus Lighting

Uplus Lighting BSW 350 Manuale utente

Uplus Lighting

Uplus Lighting 4020 IP Manuale utente

Uplus Lighting

Uplus Lighting DUAD540 STROBE Manuale utente

Uplus Lighting

Uplus Lighting 200 LED RETRO Manuale utente

Uplus Lighting

Uplus Lighting 37X15ZWASH Manuale utente

Uplus Lighting

Uplus Lighting BR360 Manuale utente

Uplus Lighting

Uplus Lighting 19X15Z WASH Manuale utente

Uplus Lighting

Uplus Lighting 750 BSWF Manuale utente

Uplus Lighting

Uplus Lighting 400 BLINDER Manuale utente

Uplus Lighting

Uplus Lighting 400 IP BLINDER Manuale utente

Uplus Lighting

Uplus Lighting 200 LED BSW Manuale utente

Uplus Lighting

Uplus Lighting 200 BLINDER Manuale utente

Manuali Attrezzatura di illuminazione popolari di altre marche

Brizo

Brizo 8SP-MU-4 Manuale utente

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuale utente

IKEA

IKEA BJÖRKSPIREA Manuale utente

Laserworld

Laserworld Evolution Series ES-400RGB Manuale utente

Alien

Alien RG STAR Manuale utente

EuroLite

EuroLite LED B-40 Manuale utente

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuale utente

Commercial Electric

Commercial Electric 54568141 Manuale utente

CREE LIGHTING

CREE LIGHTING 304 Series Manuale utente

Goobay

Goobay 49867 Manuale utente

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuale utente

Alkalite

Alkalite Krypton KT-81 Manuale utente

Clas Ohlson

Clas Ohlson GU10 Manuale utente

DTS

DTS DELTA 10 F Manuale utente

ring

ring Solar Steplight Manuale utente

One Stop Gardens

One Stop Gardens 57696 Istruzioni per il montaggio

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuale utente

SIREM

SIREM Swimeo A2 Manuale utente
