Uplus Lighting 200 LED BSW Manuale utente

User manual

200 LED BSW

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

2.Technical Specifications…………………………………………………………………………4

3.Control Menu ……………………………………………………………………………………5-6

4.DMX Channels ……………………………………………………………………………………7-8

5.Dimension …………………………………………………………………………………………9

6.Trouble Shooting…………………………………………………………………………………10

7.Fixture Cleaning………………………………………………………… ………………………10

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure

that they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is

firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to

which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s

weight. Also always use a safety cable that can hold 12 times of the weight of the unit when

installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Light Sources: 200W High Power White LED

Max Power Consumption: 290W

Power Input: 100-240V, 50/60Hz

Color Tempreture: 7500K

LED Lifespan: 50000 hours

Operating mode: DMX512,Auto, Sound active, Master/slave

Channel mode: 18 DMX512 Channel

Pan: 540°(16bit) Electric correction

Tilt：270° (16bit) Electric correction

Color wheel:9 colors + open, with rainbow effect

Gobo wheel：10 gobos + open, with rotation and running water effect

Rotation gobo wheel:7 gobos+open

Prism: 4 facet prism with bi-direction rotating

0-100% linear dimming, fit advanced iris aperture zoom effect, fast, precise, smooth, one of the most

advanced optical system in the same class of products.

Strobe: 0-25Hz/s, sync pulse strobe, random pulse stroboscopic,etc.

Frost: With frost effect

Zoom range:7°-21°

Display: Touch screen, English and Chinese interchangeable, reversible display.

Over heat protection

IP level: IP20

Packing Size: 343*232*537mm

N.W：15kgs

Gross weight: 18kgs

3.Control Menu

Menu Operation

On the base of the control panel offers a number of features, such as setting DMX fixture address,

switch the lamp, run the test program, the mode selection.

Main Menu

Second Menu

Third Menu

Forth Menu

Settings

Dmx Address

1 - 512

Fixture Set

Dmx Mode

STD / EXT

Run Mode

DMX / Host

Pan Inverse

Close / Open

Tilt Inverse

Close / Open

Display

Language

CH / EN

Display Flip

Close / Open

Display Mode

Show / 60s

Reset

XY Reset

Cance / Run

Motor Reset

Cance / Run

All Reset

Cance / Run

Factory

Cance / Run

Info

Time

Current Time

xxxH

Show Time

xxxH

Power Count

xxx

Sensor

xxxxxx

Software Version

Panel

Vx.xxx

Motor_XY

Vx.xxx

Motor

Vx.xxx

Manual

Pan

0 - 255

PanFine

0 - 255

Tilt

0 - 255

TiltFine

0 - 255

⁞

Factory

Password

0 - 255

Pan

0 - 255

Tilt

0 - 255

Iris

0 - 255

Color

0 - 255

RotGobo

0 - 255

Gobo Rot

0 - 255

Fix Gobo

0 - 255

Frost

0 - 255

Color7

0 - 255

Effect

0 - 255

Prism

0 - 255

PrismRot

0 - 255

Zoom

0 - 255

Focus

0 - 255

4.DMX Channels

Model – CH18

Channel

DMX Value

Dispaly

Function

0－255

Pan

Pan 0-540°

0－255

Pan fine

Pan fine 16bit

0－255

Tilt

Tilt 0-240°

0－255

Tilt fine

Tilt fine 16bit

0－255

P/T Speed

from fast to slow

0－255

Dimming

From dark to bright

0－3

Strobe

Open

4－99

Synchronous strobe

100－149

Split strobe

150－199

Strobe

200－249

Random strobe

250－255

Open

0－19

Color

Color 1 Linear

20－39

Color 2 Linear

…………

160－179

Color 9 Linear

180－199

Blank linear change

200－226

Color flow clockwise, from fast to slow

227－228

Stop

229－255

Color flow counterclockwise, from slow to fast

0－4

Fixed gobo

blank

5－54

10 fixed patterns, every 5 numbers correspond to a

pattern

55－154

10 fixed patterns jitter fast to slow, every 10 numbers

correspond to a pattern

155－204

Flowing in a clockwise pattern, from fast to slow

205－205

Stop

206－255

Color flow counterclockwise, from slow to fast

0－79

Rotary gobo

7 rotating patterns + blank, every 10 numbers

correspond to a pattern

80－159

7 rotating patterns + blank jitter fast to slow

160－206

Flowing in a clockwise pattern, from fast to slow

207－208

Stop

209－255

Flowing in a counterclockwise pattern, from slow to

fast

0－1277

Rotary gobo

rotation fine

Gobo rotation 0-360 degrees

128－191

The pattern rotates clockwise from fast to slow

192－193

Stop

194－255

The pattern turns counterclockwise from slow to fast

0-127

Prism insertion

Prism removed

128-255

Prism insertion

0-127

Prism rotation

Prism rotates 90 degrees

128-190

The pattern rotates clockwise from fast to slow

191-192

Stop

193-255

The pattern turns counterclockwise from slow to fast

0-127

Frost

white

128-255

Frost

0-255

Zoom

0-100% linear Zoom

0-255

enlarge

0-100% linear Enlarge

0-50

Macro function

51-100

System self-check

101-150

Auto-run 1

151-200

Auto-run 2

201-255

Sound

0-250

251-255

Reset (hold for 5 seconds to take effect)

5.Dimension

6.Trouble Shooting

ollo

ing

few

oble

occu

uring

ope

tion

leshooting

The

does

work

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

espons

el,

che

ess

etti

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

One

the

cha

ing

tep

moto

dam

the

nect

PCB

oken.

oto

’

ive

PCB

ndition

7.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates:

damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics .

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
