Uplus Lighting MH12X40 PIXEL BAR Manuale utente

User manual

MH 12X40 PIXEL BAR

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

Technical Specifications…………………………………………………………………………4

Control Menu ……………………………………………………………………………………5-6

DMX Channels ……………………………………………………………………………………6-8

Trouble Shooting…………………………………………………………………………………9

Fixture Cleaning………………………………………………………… ………………………9

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Input Voltage: 100-240V,50/60Hz

Light Source: 12*40W RGBW 4in1 LED

Light source life: 50000 hours

Power consumption: 600W

Color temperature: 2800K-8500K

Zoom angle: 5-45°

Tilt: 270°Tilt resolution: 16 bits

Sectional independent control of focusing system

Dimmer:0-100%(16bit)

Strobe:1-20Hz

DMX Channels: 20/57CH

Operate mode: Master/Slave,Auto,Sound active,DMX512,RDM

NW:15KG

Dimension:1020x110x310mm

Features:

The appearance is simple, the structure is compact, the shell is made of aluminum alloy and

engineering plastics, the volume is small, the weight is light, and the side wall has a positioning

splicing shaft design to keep the lamps vertically spliced in a straight line. The operation is simple

and convenient. After splicing, the distance between the lamp beads is equal, The overall lighting

effect is continuous, the focusing system can be individually controlled in sections, a single light

source can be controlled, a variety of color macro effects, 16bit dimming, efficient heat dissipation

system, full temperature monitoring, automatic over-temperature protection, only fan speed

adjustment, Real-time display of temperature, one-key reverse display of settings

3.Control Menu

Menu Operation

On the base of the control panel offers a number of features, such as setting DMX fixture address,

switch the lamp, run the test program, the mode selection.

Main menu

Secondary menu

hree-level menu/parameters

parameters

Dmx Address

001 - 512

Fixture

Ch Mode

STD/EXT

Run Mode

DMX/Host/Sound

Tilt Inv

Close/Open

Manual

Tilt

0 - 255

Tilt Fine

0 - 255

Information

Time

Current Time

xxxh

Total Time

xxxh

Power Count

xxx

Sensor

Tilt

TRUE/FALSE

Zoom1

TRUE/FALSE

Zoom2

TRUE/FALSE

Temp

TRUE/FALSE

Temperature

Head Temp

xxx C

Software Version

Panel

Vx.xxx

Dimmer

Vx.xxx

Factory

Password

0 - 255

Tilt

0 - 255

Zoom1

0 - 255

Zoom2

0 - 255

Red

0 - 255

Green

0 - 255

Blue

0 - 255

White

0 - 255

Fixture Reset

Reset

Run/OFF

Factory

Run/OFF

Display

Language

EN/CH

Display Flip

Normal/Reverse

Display Mode

Show/60s

4.DMX Channels

20 CH Mode

20CH

Standard mode

Channel name

Channel value

Channel content

Tilt

0 - 255

Vertical rotation

Tilt Fine

0 - 255

Vertical fine-tuning

Tilt-Speed

0 - 255

Vertical motor speed

Zoom All

0 - 255

Enlarge the whole

Zoom1

0 - 255

Zoom in 1

Zoom2

0 - 255

Zoom in 2

Dimmer

0 - 255

Dimming 8bit

Dim Fine

0 - 255

Dimming 16bit

Strobe

0 - 3

shut down

4 - 103

Regular stroboscopic, the speed changes

from slow to faster

104 - 107

turn on

108 - 207

Pulse stroboscopic, the speed changes

from slow to fast

208 - 212

turn on

213 - 225

Random slow strobe

226 - 238

Random medium speed strobe

239 - 251

Random fast strobe

252 - 255

turn on

Red

0 - 255

red

Green

0 - 255

green

Blue

0 - 255

blue

White

0 - 255

white

Inner Effect

Built-in effect selection

0 - 10

no effect

11 - 13

Static effect 1

14 - 16

Static effect 2

… …

67 - 70

Static effect 20

71 - 72

Dynamic effect 1

73 - 75

Dynamic effects 2

… …

……

188 - 190

Dynamic effects 40

191 - 193

Dynamic color effect 1

… …

218 - 220

Dynamic color effect 10

221 - 255

Dynamic color effect 11

Effect Speed

0 - 255

Dynamic effect speed (from slow to fast)

LED Mirror

0 - 255

LED lamp beads left and right mirroring

For Color

0 - 255

Foreground color macro

Back Color

0 - 255

Background color macro

Back Color Dimmer

0 - 255

Background dimming

Function

Features

57 CH Mode

57CH

Extended mode

Channel name

Channel value

Channel content

Tilt

0 - 255

Vertical rotation

Tilt Fine

0 - 255

Vertical fine-tuning

Tilt-Speed

0 - 255

Vertical motor speed

Zoom1

0 - 255

Zoom in 1

Zoom2

0 - 255

Zoom in 2

Dimmer

0 - 255

Dimming 8bit

Dim Fine

0 - 255

Dimming 16bit

Strobe

0 - 3

shut down

4 - 103

Regular stroboscopic, the speed changes

from slow to faster

104 - 107

turn on

108 - 207

Pulse stroboscopic, the speed changes

from slow to fast

208 - 212

turn on

213 - 225

Random slow strobe

226 - 238

Random medium speed strobe

239 - 251

Random fast strobe

252 - 255

turn on

LED1 Red

0 - 255

LED1 red

LED1 Green

0 - 255

LED1 green

LED1 Blue

0 - 255

LED1 blue

LED1 White

0 - 255

LED1 white

LED2 Red

0 - 255

LED2 red

LED2 Green

0 - 255

LED2 green

LED2 Blue

0 - 255

LED2 blue

LED2 White

0 - 255

LED2 white

… …

……

LED12 Red

0 - 255

LED12 red

LED12 Green

0 - 255

LED12 green

LED12 Blue

0 - 255

LED12 blue

LED12 White

0 - 255

LED12 white

Function

Features

Fixture Reset

101-120

Fixture reset

Reserve

5.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
