ZyXEL Communications POE-12 Manuale utente

Empower Easy Power over

Ethernet Connectivity

Power over Ethernet Injector

poe-12

Benefits

Power over Ethernet Empowerment

ZyXEL PoE-12 is a single-port Power over Ethernet (PoE) Injector that

infuses and transmits electricity through unused pairs (4/5 and 7/8) in

CAT-5 Ethernet cables, while data flows are carried by the other pairs

(1/2 and 3/6). As such both power and data can be delivered to PoE

devices (PD) via a single CAT-5 Ethernet cable without extra power supply.

Hassle-free Installation

With the PoE-12, non-PoE switches can now power IEEE802.3af compliant

PoE devices through an effective single CAT-5 Ethernet cable link up to

100m in length.

In other words,users can install any IEEE 802.3af compliant PoE devices

like WLAN access points or IP surveillance cameras with more freedom.

Unlike traditional solutions, the PoE-12 can now take advantage of the

effortless connectivity in challenging places, such as ceiling or top of wall,

without laying power cables.It means that the devices are now untied

from power outlets for maximum flexibility.

The PoE-12 is easy to use and needs no configuration. Since only simple

inbound and outbound cable plugging is required,installation is

straightforward and can be performed by users without power cabling

expertise or expense.

ł

Offering installment freedom by empowering Power

over Ethernet (PoE) technology

ł

Easy installment for IEEE802.3af compliant WLAN AP

or IP Surveillance Camera in challenging places

ł

Carefree over location of power outlet by up to 328

feet (100 m) link distance via CAT-5 Ethernet cabling

ł

IEEE 802.3af Power over Ethernet (PoE) standard

compliant

ł

Advanced auto-sensing algorithm performing auto

power allocation only to 802.3af end devices

ł

Superior safety with overloading and short-circuit

protection

Power over

Ethernet Injector

poe-12

Standard Compliance

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100Base-Tx Ethernet

• IEEE 802.3af Power over Ethernet

Hardware Specifications

• 1-port 10/100Base-T (Data) for connection to the

passive hub or switch

• 1-port 10/100Base-T (Power/Data) for connection

to the PoE devices (PD)

Status LED

• PWR/LINK

- ON: Power ON (Green)

- OFF: Power OFF

Physical Specifications

• Dimensions: 117 (W) x 60 (D) x 35 (H) mm

• Weight: 500 g

Power Requirements

• Input Voltage of AC: 100 ~ 240V, 50 ~ 60Hz, 0.3A

• Output Power: 48VDC, 0.3A

Environmental Specifications

• Operating Temperature: 5°C ~ 45°C

• Storage Temperature: -20°C ~ 55°C

• Operating Humidity: 10% ~ 90%,non-condensing

Network Cable

• 10BASE-T:2-pair UTP/STP Cat.3, 4, 5 cable EIA/TIA-

568 100-ohm (100m)

• 100BASE-TX: 2-pair UTP/STP Cat.5 cable EIA/TIA-568

100-ohm (100m)

Certification

• FCC Part 15 Class B

• CE

• C-Tick

Specifications

Application Diagram

at5 Ca

(

Data

)

ower Cable

(

Power

)

DSL/Ca

ode

IP Cam with PoE

AP wi

E-1

ower over

ernet Injecto

E-12

wer

ver

Ethernet In

ector

wer

Out

wer

Out

Cat5 Cable

(Data+Power)

Cat5 Cable

(Data+Power)

Internet

65-100-111102G 04/06
