ZyXEL Communications PMG1006-B20A Manuale utente

EU Importer: ZyXEL Communications A/S∣Generatorvej 8D, 2730 Herlev∣http://www.zyxel.dk

US Importer: ZyXEL Communications, Inc∣1130 North Miller Street Anaheim, CA 92806-2001∣http://www.us.zyxel.com

Declarations

English

Environmental product declaration

RoHS Directive 2011/65/EU

WEEE Directive 2012/19/EU

PPW Directive 94/62/EC

REACH Regulation (EC) No 1907/2006

ErP Directive 2009/125/EC

Name/ title Raymond Huang / Quality & Customer

Service Division Assistant VP

Signature Date (dd/mm/yyyy)

01/10/2013

www.zyxel.com

Declaration of Conformity

Product information

Product Name :

GPON SFU with 4-port GbE Switch

Model Number : PMG1006-B20A

Produced by

Company Name : ZyXEL Communications Corporation

Company Add. : No. 2, Gongye E. 9th Road Hsinchu Science Park, Hsinchu, Taiwan

to which this declaration relates, is in conformity with the following standards or other

normative documents:

EMC:

EN 55022: 2010/AC: 2011

EN 61000-3-2: 2006 + A2: 2009

EN 61000-3-3: 2008

EN 55024: 2010

Safety :

EN 60950-1:2006+A11:2009+A1:

2010+A12:2011

ErP:

EN 50564:2011 ( IEC 62301 Modified )

RoHS 2 :EN 50581:2012

The Product herewith complies with requirements of the following Directive :

The Low Voltage Directive 2006/95/EC , The EMC Directive 2004/108/EC,

The ErP Directive 2009/125/EC, The RoHS Directive 2011/65/EU

and carries the CE Marking accordingly.

The TCF-File is located at:

Local contact for regulatory topics only :

Company Address :

Hsinchu Office : No. 2, Gongye E. 9th Road Hsinchu Science Park,

Hsinchu Taiwan

: No. 6, Innovation Road II, Science-Park,Hsin-chu,300

Taiwan

TAIPEI Office :11F., NO.223, SEC. 3, BEIXIN RD., XINDIAN DIST., NEW

TAIPEI CITY 23143, TAIWAN (R.O.C.)

Person is responsible for marking this declaration:

Raymond Huang

Assistant VP.

Quality & Customer Service Division

Name (Full Name) Position/ Title

2013-10-9

Hardware Connections

Connect power and press the power button.

LAN

POWER

PON

GREEN

PON

ORANGE

PON

RED

PON not connected. Turn off, disconnect power,

and repeat hardware connection steps.

PON connected and registered.

Make sure the LEDs are on and check the

PON LED.

Connect computer using an Ethernet cable.

PON connected but not registered.

An installation technician must have already

connected the fiber optic cable. See the Fiber

Connection section on the next page for more

information

Warning! To avoid possible eye injury, do NOT

look into an operating fiber-optic module's

connector.

Quick Start Guide

PMG1006-B20A

GPON SFU with 4-port GbE Switch

INTERNET

See the User's Guide on the CD or at www.zyxel.com for more information.

EU Importer: ZyXEL Communications A/S∣Generatorvej 8D, 2730 Herlev∣http://www.zyxel.dk

US Importer: ZyXEL Communications, Inc∣1130 North Miller Street Anaheim, CA 92806-2001∣http://www.us.zyxel.com

Fiber Connection

Warning! To avoid possible eye injury, do NOT look into an

operating fiber-optic module's connector.

Unscrew and remove the bottom

cover.

Use the screws to re-attach the

bottom cover.

Remove the fiber connector's cover

and connect the fiber cable.
