ADA INSTRUMENTS ZSM 330 Manuale utente

Operating manual

Digital Sound Level Meter

Model: ZSM 330

Manufacturer Address: WWW. ADAINSTRUMENTS.COM

ZSM 330

Table of contents

1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4. Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

5. Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

6. Operation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

7. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

8. Warranty/Exceptions from responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Appendix 1. Certificate of acceptance and sale

Appendix 2. Warranty card

ZSM 330 3

INTRODUCTION

ZSM 330 is used in acoustics and electroacoustics measurement but also used in machine manufacture, architectural design,communication

and transportation,environmental protection,Medical and health care,national defence construction and other fileds.

SAFETY INSTRUCTIONS

Please read this manual thoroughly before operate the unit.

Please do not remove any label from the unit.

Avoid sudden shock and dropping.

Keep away from direct sunlight, heat/cool source and strong air drift places.

Do not put the corrosive gases or other corrosive substances together.

Provide proper cleaning: don’t use acetone to clean the product. Gently clean the unit with a soft dry cloth.

Do not operate the tool with in the presence of flammable/explosive gases.

Keep the device away from vibration source and high power EMF places. The ambient temperature should be stable.

Remove the battery when storing the tool for an extended period of time to prevent the deteriorative battery from damage to the

tool.

ZSM 330

APPEARANCE

А. Electret microphone

В. LCD screen

C. Button

D. Battery lid

Е. Sound output jack

FUNCTIONS

LCD screen show sound level

Measuring range:30~130dB; Resolution:0.1db

Accuracy: ±1.5db

A Weighting

Fast time weighting

Max/Min with backlight

After 20 minutes Auto power off

Low battery indication

BATTERY

Please remove the batteries when clean the product.

Remove the batteries before long term storage.

Please install the batteries properly as the instructions of the positive and negative charges.

Avoid high temperature.

•

ZSM 330 5

OPERATION INSTRUCTIONS

1. Battery installation

Unscrew the screw nut, insert the battery ,than fasten the screw.

2. Operation Instruction

After insert the battery, press the red button to start the tool,after displayed all in the screen 3 seconds, then shows reading, if shut down manu-

ally, press and hold the side button for 3 seconds to shut down .

MAX: Press this button,the screen will display the MAX ,it display the MAX value until now,then press the button again to exit this mode.

MIN: Press this button,the screen will display the MIN ,it display the MIN value until now,then press the button again to exit this mode.

3. Operation Notes

1. Keep the device away from vibration source and high power EMF places. The ambient temperature should be stable.

2. Put on a wind shield in gentle breeze(to avoid wind noise), stop measuring when the wind is resh breeze or stronger.

3. Keep away from the ground and walls, to avoid echo.

4. To avoid damages to the instrument, do not use it near following places:

a. EMF places, Electro-magnetic fields: such as arc welders, induction heaters.

b. High temperature objects

c. Static environment

Notes

Please read this manual thoroughly before operate the unit.

Please do not remove any label from the unit.

Avoid sudden shock and dropping.

Keep away from direct sunlight, heat/cool source and strong air drift places.

•

ZSM 330

Do not put the corrosive gases or other corrosive substances together.

Provide proper cleaning: don’t use acetone to clean the product. Gently clean the unit with a soft dry cloth.

Do not operate the tool with in the presence of flammable/explosive gases.

Keep the device away from vibration source and high power EMF places. The ambient temperature should be stable.

Remove the battery when storing the tool for an extended period of time to prevent the deteriorative battery from damage to the tool.

TECHNICAL DATA

•

Display LCD

Range 30~130dB

Resolution 0.1dB

Accuracy ±1.5dB

A/C weighting A

FAST/SLOW weighting FAST

MAX display mode YES

MIN display mode YES

Auto power off 20 Minutes

Backlight YES

Low voltage alarm YES

Power supply 9Vbattery (6F22/6LR61)

Working current <25mA

Operating Temperature 0ºС~+40ºС

Operating humidity 10-90%RH non-condensing

Dimensions 207×61×40 mm

Weight 112g (without battery)

ZSM 330 7

Warranty

This product is warranted by the manufacturer to the original purchaser to be free from defects in material and workmanship under

normal use for a period of two (2) years from the date of purchase.

During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or similar model at

manufactures option), without charge for either parts of labour.

In case of a defect please contact the dealer where you originally purchased this product. The warranty will not apply to this product

if it has been misused, abused or altered. Withiut limiting the foregoing, leakage of the battery, bending or dropping the unit are

presumed to be defects resulting from misuse or abuse.

Exceptions from responsibility

The user of this product is expected to follow the instructions given in operators’ manual.

Although all instruments left our warehouse in perfect condition and adjustment the user is expected to carry out periodic checks of

the product’s accuracy and general performance.

The manufacturer, or its representatives, assumes no responsibility of results of a faulty or intentional usage or misuse including any

direct, indirect, consequential damage, and loss of profits.

The manufacturer, or its representatives, assumes no responsibility for consequential damage, and loss of profits by any disaster

(earthquake, storm, flood ...), fire, accident, or an act of a third party and/or a usage in other than usual conditions.

The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of profits due to a change of data, loss

of data and interruption of business etc., caused by using the product or an unusable product.

The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of profits caused by usage other thsn

explained in the users’ manual.

The manufacturer, or its representatives, assumes no responsibility for damage caused by wrong movement or action due to connect-

ing with other products.

WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:

1. If the standard or serial product number will be changed, erased, removed or wil be unreadable.

2. Periodic maintenance, repair or changing parts as a result of their normal runout.

3. All adaptations and modifications with the purpose of improvement and expansion of normal sphere of product application, men-

tioned in the service instruction, without tentative written agreement of the expert provider.

4. Service by anyone other than an authorized service center.

5. Damage to products or parts caused by misuse, including, without limitation, misapplication or nrgligence of the terms of service

instruction.

6. Power supply units, chargers, accessories, wearing parts.

7. Products, damaged from mishandling, faulty adjustment, maintenance with low-quality and non-standard materials, presence of

any liquids and foreign objects inside the product.

8. Acts of God and/or actions of third persons.

9. In case of unwarranted repair till the end of warranty period because of damages during the operation of the product, it’s transpor-

tation and storing, warranty doesn’t resume.

For more information you can visit our website WWW.ADAINSTRUMENTS.COM

or write the letter with your questions on [email protected]

WARRANTY CARD

Name and model of the product ________________________________________________

Serial number ________________date of sale_______________________

Name of commercial organization _____________________stamp of commercial organization

Warranty period for the instrument explotation is 24 months after the date of original retail purchase.

During this warranty period the owner of the product has the right for free repair of his instrument in case of manufacturing defects.

Warranty is valid only with original warranty card, fully and clear filled (stamp or mark of thr seller is obligatory).

Technical examination of instruments for fault identification which is under the warranty, is made only in the authorized service center.

In no event shall manufacturer be liable before the client for direct or consewuential damages, loss of profit or any other damage which

occur in the result of the instrument outage.

The product is received in the state of operability, without any visible damages, in full completeness. It is tested in my presence. I have no

complaints to the product quality. I am familiar with the conditions of qarranty service and i agree.

purchaser signature _______________________________

Before operating you should read service instruction!

If you have any questions about the warranty service and technical support contact seller of this product

Certificate of acceptance and sale

__________________________________________________________________________

___________________________________________________________№_____________

name and model of the instrument

Corresponds to ______________________________________________________________

designation of standard and technical requirements

Data of issue _______________________________________________________________

Stamp of quality control department

Price

Sold ___________________________________ Date of sale ______________________

name of commercial establishment
