Advantech AIMB-224 Manuale di installazione e funzionamento
AIMB-224 Startup Manual 1
Before you begin installing your single board, please make
sure that the following materials have been shipped:
1. 1 x AIMB-224 Mini ITX Motherboard
2. 1 x CD-ROM or DVD-ROM contains the following:
- User’s Manual
- Drivers
3. 1 x Serial port cable
4. 2 x SATA HDD Data cable
5. 2 x SATA Power cable
6. 1 x I/O shield
7. 1 x CPU cooler
8. 1 x Startup manual
9. 1 x Warranty card
AIMB-224 Mobile AMD R-series Qual Core/Dual Core
FS1r2 socket Mini-ITX Motherboard with VGA/LVDS/
Display Port, 6 COMs and Dual LAN
Startup Manual
Processor System
• CPU: Support AMD R-series Quald Core 2.3 GHz/Quad
Core 1.9 GHz/ Dual Core 2.7 GHz / Dual Core 2.5 GHz
FS1r2 socket type processor
• Max. Speed: 2.3 GHz (Quald Core)
• L2 Cache: 1 MB/per core
• Chipset: A75M
• BIOS: 16 Mbit SPI
Expansion Slot
• Mini-PCIe: 2 (1 Full-size colay mSATA/ 1 Half-size)
• PCIe: PCIe x 8 (PCIe gen 3)
Memory
• Technology: Dual channels DDR3 1333/1600 MHz
• Max. Capacity: 16 GB
• Socket: 2 x 204-pin SODIMM
Graphic Interface
• Controller: AMD Radeon™ GPUs (RadeonTM HD 7xxx),
support DirectX 11, UVD3
• VGA: Supports up to 4096 x 2400 @ 60 Hz
• LVDS:Supports 24-bit dual channel and 1920 x 1200
• Display Port: Two dual model display port, max resolu-
tion: 1920 x 1200@60 Hz
• Triple Display: Supports Triple display of CRT/LVDS/DP
• Dual Display: Supports dual display of any two display
device (CRT, LVDS, DP)
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: GbE LAN1: RTL8111E;
GbE LAN2: RTL8111E
• Connector: RJ-45 x 2
SATA Interface
• Max Data Transfer Rate: 600 MB/s
• Channel: 3
Rear I/O
• VGA: 1
• DP: 2
• Ethernet: 2
• USB: 4 (2 USB 3.0 / 2 USB 2.0)
• Audio: 3 (Mic-in, Line-out, Line-in)
• Serial: 1 (RS-232)
• PS/2: 1
• DCIN Jack: 1
Specications
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the AIMB-224 series Rev. A1
Part No. 2006022410 1st Edition
October 2011
Packing List
2 AIMB-224 Startup Manual
Internal Connector
• LVDS & Inverter: 1
• USB: 6 (USB 2.0 compliant)
• Serial: 5 (1 RS-232/422/485, 4 RS-232, COM3 supports
5 V/12 V by jumper selection; COM6 supports RS-
232/422/485 function)
• SATA: 3
• DIO: 8-bit GPIO
Watchdog Timer
• Output: System reset
• Interval: Programmable 1 ~ 255 sec/min
Power Requirement
• Typical: DCIN 12 V or ATX 4 pin 12 V
Environment
• Temperature:
0 ~ 60° C (32 ~ 140° F), Operating
-40 ~ 85° C (-40 ~ 185° F), Non-operating
Physical Characteristics
• Dimensions: 170 mm x 170 mm (6.69” x 6.69”)
The board has a number of connectors and jumpers that
help configure the system to suit your application require-
ments. The tables below list the function of each of the
connectors and jumpers.
Connector List
Label Function
FPAUD1 Front Panel audio connector
AUDIO1 Audio connector
CMOS1 CMOS clear ( Default 1-2 )
DIMM1_A1/B1 Memory connector channel
COM3-6 Serial port: 3RS232/1RS-232-422/485
COM2 Serial port: RS-232
CPU_FAN1 CPU FAN connector(3-pin)
DIO_CN1 GPIO Header
DCIN1 DC IN
ATX12V1 ATX 12V connector
ATX_5V1 PS_ON , 5VSB
LVDS2 LVDS connector (Internal)
INV2 LVDS Inverter Power
JVBR2 LVDS Brightness control selector for
Analog or Digital (Default 1-2, Analog)
JLVDS3 LVDS voltage jumper (default 1-2, 3.3V)
JLVDS4 LVDS 12V voltage jumper
VCON2 LVDS JEIDA/VESA jumper selection
JFP1+JFP2 Power switch/HDD LED/SMBus/
speaker
JFP3 Power LED and Keyboard lock
JSETCOM6 COM6 RS-232/422/485 Jumper setting
JSETCOM3 COM3 5V/12V Jumper setting
PCIEX8_1 PCI Express X8 slot
KBMS1 PS/2 Keyboard and Mouse external
connector
KBMS2 PS/2 Keyboard and Mouse internal
connector
LAN1_USB01 LAN1 / USB port 1, 2
LAN2_USB23 LAN2 / USB port 3, 4
MINI_PCIE1/2 Mini PCI express connector
PSON1 AT(1-2) / ATX(2-3) ( Default 2-3 )
S ATA 1 Serial ATA data connector 1
SATA2 Serial ATA data connector 2
SATA3 Serial ATA data connector 3
SATA_PWR1 SATA POWER
SATA_PWR2 SATA POWER
DOM_PWR DOM POWER
SPI1 SPI connector
SPI_CN1 SPI flash update connector.
SPDIF_OUT1 Digital Audio connector
SYS_FAN1 System FAN connector(3-pin)
USB456789 USB port 4,5, 6,7,8,9 (on board)
DUAL_DP1 Two Display port connector
VGA1 VGA connector
COM1 COM PORT CONNECTOR
JOBS1+JWDT1 OBS Alarm and Watchdog Reset
BAT1 Battery holder
Jumpers & Connectors
Jumpers & Connectors
Specications (Cont.)
AIMB-224 Startup Manual 3
LVDS2
Pin Signal
1 VDDSAFE
2 VDDSAFE
3 GND
4 GND
5 VDDSAFE
6 VDDSAFE
7 LVDS_L0_N
8 LVDS_U0_N
9 LVDS_L0_P
10 LVDS_U0_P
11 GND
12 GND
13 LVDS_L1_N
14 LVDS_U1_N
15 LVDS_L1_P
16 LVDS_U1_P
17 GND
18 GND
19 LVDS_L2_N
20 LVDS_U2_N
21 LVDS_L2_P
22 LVDS_U2_P
23 GND
24 GND
25 LVDS_CLKL_N
26 LVDS_CLKU_N
27 LVDS_CLKL_P
28 LVDS_CLKU_P
29 GND
30 GND
31 LVDS_CH7511_DDC_CLK
32 LVDS_CH7511_DDC_DATA
33 GND
34 GND
35 LVDS_L3_N
36 LVDS_U3_N
37 LVDS_L3_P
38 LVDS_U3_P
39 N22140709
40 VCON
JLVDS3 (LVDS Voltage jumper selection)
Pin Signal
pin1 12 V
pin 2 VDDSAFE_IN
JLVDS4 (LVDS voltage jumper selection)
Pin Signal
PIN1-2 3 V
PIN2-3 5 V
LVDS Inverter PWR
Pin Signal
1 12 V
2 GND
3 BL_EN
4 BL_CNL
5 5 V
JVBR2 (Brightness control selection)
Pin Signal
1 BL_Control
2 GND
3 NC
JWDT1+JOBS1
Pin Signal
1 NC
2SIO_WG
3SYS_RST
4ERR_BEEP
5BEEP
Jumpers & Connectors
4 AIMB-224 Startup Manual
9 +5 V
10 GND
PSON1
Pin Function
1 FRP_PANSWIN#_AT
2 FRP_PANSWIN#
3 NC
SPDIF_OUT
Pin Function
1 +5 V
3 SPDIF_0
4 GND
JSETCOM3
Pin Function
1 COM3P9SEL
2 RRI3
3 COM3P9SEL
4 5 V
5 COM3P9SEL
6 12V
JSETCOM3
Pin Signal
1 +12 V
2 RI6xPOWERxJMP
3 COM6_RI#
4 RI6xPOWERxJMP
5 +5 V
6 RI6xPOWERxJMP
USB45
Pin Signal
1 +SBV45
2 +SBV45
3 USBP4-
4 USBP5-
JFP1+JFP2
Pin Signal
1 +5 V
2 HDLED+
3 FRP_PANSWIN#
4 SPK_CN17P2
5 HDD_LED-
6 GND(R1160:100OHM)
7 SPK_CN17P4
8 SMBDATA_R
9 FRP_RST#
10 SPK_CN17P3
11 SMBCLK_R
12 GND
JFP3
Pin Signal
1POWER LED
2NC
3GND
4KEYLOCK
5GND
ATX5V1
Pin Function
1 5 VSB_IN
2 GND
3 PS_ON#
DIO_CN1
Pin Function
1 DIO0
2 DIO4
3 DIO1
4 DIO5
5 DIO2
6 DIO6
7 DIO3
8 DIO7
Jumpers & Connectors
AIMB-224 Startup Manual 5
5 USBP4+
6 USBP5+
7 GND
8 GND
10 GND
USB67
Pin Signal
1 +SBV67
2 +SBV67
3 USBP6-
4 USBP7-
5 USBP6+
6 USBP7+
7 GND
8 GND
10 GND
JCMOS1
Pin Signal
1 NC
2 RTC_RST#
3 GND
SPI_CN1
Pin Signal
1 +V3.3M_SPI
2 GND
3 SPI_CS#
4 SPI_CLK
5 SPI_MISO
6 SPI_MOSI
8 NC
CPU_FAN, SYS_FAN
Pin Signal
1GND
2+12VPWM
3Sensor
3 6 9 12
2 5 8 11
1 4 7 10
JFP1+JFP2
PIN Signal
1 +5V
2 HDLED+
3 FRP_PANSWIN#
4 SPK_CN17P2
5 HDD_LED-
6 GND(R1160:100OHM)
7 SPK_CN17P4
8 SMBDATA_R
9 FRP_RST#
10 SPK_CN17P3
11 SMBCLK_R
12 GND
Declaration of Conformity
The device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference;
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Software Installation
The CD disc contains a driver installer program that will lead
you through the installation as various device drivers are
needed to take full advantage of your motherboard.
Caution! The computer is supplied with a battery-powered
real-time clock circuit. There is a danger of explo-
sion if the battery is incorrectly replaced. Replace
only wih same or equivalent type recommended
by the manufaturer. Discard used batteries ac-
cording to manufaturer’s instructions.
Jumpers & Connectors Installation Note
6 AIMB-224 Startup Manual
MINI_PCIE1
SATA_PWR
CPUFAN1
SATA_PWR2
KBMS2
ATX12V1
COM2
SATA2
SATA3
USB89
DOM_PWR1
SATA1
USB45
USB67
SPI1
BAT1
INV2
SPDIF_OUT
JCMOS1
FPAUDIO1
JAMP1
SYSFAN1
DDR_PWR1
JWDT1+JOBS1
JFP3
JFP1+JFP2
PSON1
DIO_CN1 JESTCOM6
DIMM_B1
DIMM_A1
ATX5V1
COM3-6
JSETCOM3
SPI_CN1
JVBR2
JLVDS4
VCON2
JLVDS3
EDP1
LVDS2
DCIN1 KBMS1 DUAL_DP1 COM1 VGA LANUSB01 LANUSB23
AUDIO1
MINI_PCIE2
Board Diagram
