American Dynamics Tyco ADC770 Manuale utente

FEATURES

The ADC770 1/3-inch color DSP camera offers an

advanced solution to your specific video surveillance

needs. Solid and powerful, these cameras are

engineered for optimal performance in low light and

contrasting lighting conditions.

On-screen menus provide simple access to the

camera’s parameter settings. Low light sensitivity

renders sharp images in scenes as dim as 0.4 lux.

Digital Slow Shutter (DSS) provides an even greater

level of low light viewing capability. Digital Signal

Processing (DSP) combines with 480 TV lines of

resolution to deliver the best in picture quality.

Equipped with built-in Auto Tracking White (ATW)

Balance and One-Touch White Balance (AWB), the

ADC770 can produce accurate color pictures in a

broad range of lighting conditions. The One-Touch

feature makes these one of the easiest cameras in the

industry to adjust for manual white balance.

The ADC770 camera also features motion detection

with alarm output, six backlight compensation

(BLC) zones (two are user-definable), phase-

adjustable line-lock for “roll-free” switching, and a

fully isolated power supply that allows you to

connect multiple cameras to a single 24 VAC source

with minimal interference from ground loops.

These energy efficient cameras are suited for a wide

range of applications and save you money in

operational costs.

ADC770

1/3-INCH COLOR DSP CAMERA WITH

WIDE DYNAMIC RANGE

•1/3-inch interline color

CCD

•Digital Signal Processing

(DSP)

•480 TV lines resolution

•0.4 lux low light

sensitivity, 0.02 lux at

1/32 slow shutter

•Wide dynamic range

(WDR)

•Automatic electronic

shutter (AES)

•Digital slow shutter

(DSS)

•Dual (H&V) edge

enhancement

•Automatic gain control

(AGC)

•Six backlight

compensation (BLC)

zones

•On-screen Menus

•On-screen Camera Titles

•Supports DC and

Video-type auto iris

lenses

•C/CS lens mount

•Phase adjustable line-

lock

•24 VAC or 12 VDC input

•Internal isolation

transformer

www.americandynamics.net

Lenses sold separately

SPECIFICATIONS

Model Numbers

ADC770 . . . . . . . . . . . . . . . . . . . . . .Camera, 1/3-inch, Color, 480 TVL,

0.4 lux, WDR, NTSC, 24 VAC/12 VDC

Operational

Imager . . . . . . . . . . . . . . . . . . . . . . . .Interline transfer 1/3-inch CCD array

Video Output . . . . . . . . . . . . . . . . .1.0 Vp-p / 75 Ω, composite

Active Pixel Count

NTSC . . . . . . . . . . . . . . . . . . . . . . .768 (H) x 494 (V) pixels

Minimum Scene Illumination . .0.4 lux (f1.2 lens)

Horizontal Resolution . . . . . . . . .480 TV lines

Light Compensation Modes . . . .Automatic electronic shutter, On/Off

(NTSC 1/60 -1/100,000 sec)

Auto Iris Drive . . . . . . . . . . . . . . . .DC and Video type

Backlight Compensation . . . . . . .6 Zones (2 definable), On/Off selectable

Aperture Correction . . . . . . . . . . .Horizontal and vertical

Synchronization Modes . . . . . . . .Internal, genlock or line-lock with 360º

phase adjustment

White Balance . . . . . . . . . . . . . . . . .Auto or One-Touch modes

(2,500º k to 8,000º k)

Geometric Distortion . . . . . . . . . .None

S/N Ratio . . . . . . . . . . . . . . . . . . . . .-50 dB

Synchronization . . . . . . . . . . . . . . .Internal, genlock or line-lock with phase

adjustment

DC Iris . . . . . . . . . . . . . . . . . . . . . . .Level control

Back Focus . . . . . . . . . . . . . . . . . . . .Adjustment ring with lock

Connectors

Input Power . . . . . . . . . . . . . . . . . . .Screw terminals

Composite Video . . . . . . . . . . . . . .BNC

Sync In . . . . . . . . . . . . . . . . . . . . . . .BNC

Y/C Out

Alarm Output . . . . . . . . . . . . . . . . .Push terminals

DC Iris . . . . . . . . . . . . . . . . . . . . . . .4 pin square connector

Electrical

AC Voltage . . . . . . . . . . . . . . . . . . . .24 VAC (+33% -15%)

60 Hz (NTSC)

DC Voltage . . . . . . . . . . . . . . . . . . . .12 VDC (+15%, -10%)

Power Consumption . . . . . . . . . . .5.2 watts

Mechanical

Lens Mount . . . . . . . . . . . . . . . . . .C or CS type

Camera Mount . . . . . . . . . . . . . . .1/4 in x 20 in

Dimensions (H x W x L) . . . . . . . .63 x 75 x 149 mm

(2.5 x 3.0 x 5.9 in)

Unit Weight . . . . . . . . . . . . . . . . . .600 g (1.32 lbs)

Color . . . . . . . . . . . . . . . . . . . . . . . .Light gray

Environmental

Temperature

Operating . . . . . . . . . . . . . . . . . . .-10° to 50° C (14° to 122° F)

Humidity . . . . . . . . . . . . . . . . . . . .90% RH (non-condensing)

Storage . . . . . . . . . . . . . . . . . . . . . .-20° to 60° C (-4° to 140° F)

Regulatory

Emissions . . . . . . . . . . . . . . . . . . . . .FCC: Part 15, Class B

ICES-003

Safety . . . . . . . . . . . . . . . . . . . . . . . .UL2044

ADC770 1/3-INCH COLOR DSP CAMERA WITH WIDE DYNAMIC RANGE

Product specifications and availability subject to

change without notice.

Certain product names mentioned herein may be trade

names and/or registered trademarks of other companies. VS418-02 07/05 L
