User Guide

Site Masterä

S311D

Cable and Antenna Analyzer

Anritsu Company PN: 10580-00185

490 Jarvis Drive Revision: D

Morgan Hill, CA 95037-2809 Published: October 2012

USA Copyright ã2003-2012 Anritsu Co.

WARRANTY

The Anritsu product(s) listed on the title page is (are) warranted against defects in

materials and workmanship for one year from the date of shipment.

Anritsu's obligation covers repairing or replacing products which prove to be defec-

tive during the warranty period. Buyers shall prepay transportation charges for

equipment returned to Anritsu for warranty repairs. Obligation is limited to the origi-

nal purchaser. Anritsu is not liable for consequential damages.

LIMITATION OF WARRANTY

The foregoing warranty does not apply to Anritsu connectors that have failed due to

normal wear. Also, the warranty does not apply to defects resulting from improper or

inadequate maintenance by the Buyer, unauthorized modification or misuse, or op-

eration outside the environmental specifications of the product. No other warranty is

expressed or implied, and the remedies provided herein are the Buyer's sole and

exclusive remedies.

TRADEMARK ACKNOWLEDGMENTS

Windows, Windows 95, Windows NT, Windows 98, Windows 2000, Windows ME,

Windows XP and Windows Vista are registered trademarks of Microsoft Corpora-

tion. Anritsu, InstaCal and Site Master are trademarks of Anritsu Company.

NOTICE

Anritsu Company has prepared this manual for use by Anritsu Company personnel

and customers as a guide for the proper installation, operation and maintenance of

Anritsu Company equipment and computer programs. The drawings, specifications,

and information contained herein are the property of Anritsu Company, and any un-

authorized use or disclosure of these drawings, specifications, and information is

prohibited; they shall not be reproduced, copied, or used in whole or in part as the

basis for manufacture or sale of the equipment or software programs without the

prior written consent of Anritsu Company.

UPDATES

Updates to this manual, if any, may be downloaded from the Anritsu internet site at:

http://www.us.anritsu.com.

ѻકЁ᳝↦᳝ᆇ⠽䋼៪ܗ㋴ⱘৡ⿄ঞ৿䞣

᳝↦᳝ᆇ⠽䋼៪ܗ㋴䚼ӊৡ⿄

䪙

3E

∲

+J

䬝

&G

݁Ӌ䫀

>&UĎ@

໮⒈㘨㣃

3%%

໮⒈Ѡ㣃䝮

3%'(

ࠋ㒓䏃ᵓ

3&$



hhƻƻ

ᴎ໇ǃᬃᶊ

&KDVVLV

h

ƻhhƻƻ

/&'hhhhƻƻ

݊Ҫ˄⬉㓚ǃ亢᠛ǃ

䖲᥹఼ㄝ˅

$SSHQGHGJRRGV

hƻhhƻƻ

ƻ˖㸼⼎䆹᳝↦᳝ᆇ⠽䋼೼䆹䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ৿䞣ഛ೼ 6-7 󰵼ޚ㾘

ᅮⱘ䰤䞣㽕∖ҹϟǄ

h˖㸼⼎䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ೼䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ёⱘ৿䞣䍙ߎ 6-7

󰵼ޚ㾘ᅮⱘ䰤䞣㽕∖Ǆ

⦃ֱՓ⫼ᳳ䰤

䖭Ͼ󰵼䆄ᰃḍ᥂  ݀Ꮧⱘǋ⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ǌҹঞ

6-7ǋ⬉ᄤֵᙃѻક∵ᶧ᥻ࠊ󰵼䆚㽕∖ǌⱘ㾘ᅮˈ䗖⫼Ѣ೼Ё೑

䫔ଂⱘ⬉ᄤֵᙃѻકⱘ⦃ֱՓ⫼ᳳ䰤Ǆҙ䰤Ѣ೼䙉ᅜ䆹ѻકⱘᅝܼ㾘㣗ঞՓ⫼

⊼ᛣџ乍ⱘ෎⸔ϞˈҢ⫳ѻ᮹䍋ㅫⱘ䆹ᑈ䰤ݙˈϡӮ಴ѻક᠔৿᳝ᆇ⠽䋼ⱘ⊘

ⓣ៪さথᗻবᓖˈ㗠ᇍ⦃๗∵ᶧˈҎ䑿ঞ䋶ѻѻ⫳⏅ࠏഄᕅડǄ

⊼˅⬉∴ⱘ⦃ֱՓ⫼ᳳ䰤ᰃ  ᑈǄ⫳ѻ᮹ᳳ󰵼Ѣѻકᑣোⱘࠡಯⷕ

བ 61;;;;

 ᑈ㄀  ⫳ѻǄ

For Chinese Customers Only YLYB

Equipment marked with the Crossed-out Wheelie

Bin symbol complies with the European

Parliament and Council Directive 2002/96/EC (the

“WEEE Directive”) in European Union.the

For Products placed on the EU market after

August 13, 2005, please contact your local Anritsu

representative at the end of the product's useful

life to arrange disposal in accordance with your

initial contract and the local law.

Table of Contents

Chapter 1

General Information

Introduction ..................................1-1

Description ...................................1-1

Standard Accessories .............................1-2

Options .....................................1-2

External Detectors ...............................1-3

Optional Accessories..............................1-3

Performance Specifications ..........................1-6

Preventive Maintenance ............................1-9

Calibration ...................................1-9

InstaCal Module ..............................1-10

Annual Verification..............................1-10

ESD Precautions ...............................1-10

Anritsu Service Centers............................1-10

Mode References ...............................1-11

Chapter 2

Functions and Operations

Introduction ..................................2-1

Test Connector Panel .............................2-1

Display Overview ...............................2-3

Front Panel Overview .............................2-4

Function Hard Keys ..............................2-5

Keypad Hard Keys ...............................2-6

Soft Keys....................................2-8

Power Monitor, External Detector (Option 5) ................2-19

Symbols....................................2-20

Self Test ...................................2-21

Error Messages ................................2-22

Battery Information..............................2-26

Charging a New Battery ..........................2-26

Determining Remaining Battery Life....................2-27

Important Battery Information .......................2-29

Chapter 3

Getting Started

Introduction ..................................3-1

Power On Procedure .............................3-1

Cable and Antenna Analyzer Mode ......................3-2

All Modes...................................3-10

Save and Recall a Setup ..........................3-10

Save and Recall a Display .........................3-10

Changing the Units .............................3-11

Changing the Language...........................3-11

Adjusting Markers .............................3-11

Adjusting Limits ..............................3-12

Adjusting the Display Brightness......................3-13

Printing ....................................3-14

Using the Soft Carrying Case.........................3-15

Chapter 4

Cable and Antenna

Analyzer Measurements

Introduction ..................................4-1

Line Sweep Fundamentals ...........................4-1

CW Mode/RF Immunity ...........................4-1

Information Required for a Line Sweep ...................4-2

Typical Line Sweep Test Procedures ....................4-2

Chapter 5

Power Monitor Mode

Introduction ..................................5-1

Power Measurement ..............................5-1

Chapter 6

High Accuracy Power Meter

Introduction ..................................6-1

Units and Relative Power ..........................6-1

Limit Lines ..................................6-1

Zeroing the Sensor ..............................6-2

Using Attenuators ..............................6-2

Power Measurement ..............................6-2

Chapter 7

Handheld Software Tools

Introduction ..................................7-1

Features ....................................7-1

System Requirements .............................7-2

Installation ...................................7-2

Using Handheld Software Tools ........................7-5

Downloading Traces .............................7-5

Plot Capture to the PC ............................7-5

Plot Upload to the Instrument ........................7-5

Plot Properties ................................7-6

Signal Standards Editor...........................7-11

Chapter 8

Master Software Tools

Introduction ..................................8-1

Key Features of Master Software Tools ....................8-1

Minimum System Requirements........................8-4

Appendix A

Windowing

Introduction .................................A-1

Examples ..................................A-1

iii

Chapter 1

General Information

Introduction

This chapter provides a description, performance specifications, optional accessories,

preventive maintenance, and calibration requirements for the Site Master™ model S311D.

Model Frequency Range

S311D Cable and Antenna Analyzer Mode: 25 to 1600 MHz

Description

The S311D Site Master is a handheld cable and antenna analyzer designed for Land Mobile

Radio (LMR) and Public Safety system technicians testing the RF performance of P25 and

TETRA radios in the VHF/UHF, 700 MHz and 800 MHz bands. The S311D is also ideal

for broadcast and cellular applications.

It is designed to measure Return Loss, VSWR, Cable Loss, of cable and antenna systems

from 25 MHz to 1600 MHz. Integrated Distance-To-Fault measurement can be used to

locate the precise location of a fault within the feedline system. Options available with the

S311D include High Accuracy Power Meter (Option 19) and Power Monitor (Option 5).

The Site Master is capable of up to 1.5 hours of continuous operation from a fully charged

field-replaceble battery and can be operated from an external power source. Built-in energy

conservation features can be used to extend the battery life.

A standard 640 x 480 color TFT display provide graphic indications of various measure-

ments. The displayed trace can be scaled or enhanced with frequency markers and limit

lines. A menu option provides for an audible “beep” when the limit value is exceeded.

1-1
