AT&T 5800 Manuale utente

Please also read

Part 1 — Important

Product Information

USER’S MANUAL

Part 2

AT&T and the Globe Design are trademarks of AT&T Corp., licensed to Advanced American Telephones.

Expansion Handset 5800/5806

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page II

AT&T and the Globe Design are

trademarks of AT&T Corp., licensed to

Advanced American Telephones.

Printed in China. Issue 3AT&T 06/04

Visit us at www.telephones.att.com

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page III

CONTENTS

BEFOREYOU BEGIN....................................................................................................1

About Handset Registration......................................................................................................1

About Softkeys..............................................................................................................................1

CHARGE THE BATTERY............................................................................................2

To Model 5830/5870/3358/3658B Base Unit.........................................................................3

To Model 5840/5845 Base Unit ................................................................................................3

INSTALLATION ...............................................................................................................4

Belt Clip..........................................................................................................................................4

Headset...........................................................................................................................................4

Battery Life ....................................................................................................................................5

Charge the Handset Battery Pack............................................................................................5

CONTENTS

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page V

About Handset Registration

•You must register this (and any other) handset with

the base, following the directions in “REGISTER THE

HANDSET.” This handset is compatible with

telephone models 5840/3358/3658B/5845/5870 and

5830.

•The original handset that came with the base is

automatically registered as Handset 1.

•Additional handsets will be assigned Handset 2,

Handset 3, Handset 4, Handset 5, and Handset 6.

•Whenever you install a handset battery pack, the

handset will display SEARCHING FOR BASE (if

it’s registered) or ENTER BASE ID (if it’s not

registered).

About Softkeys

• The handset softkeys are located below the screen

display.

•Press the softkey below the operation displayed on

the screen to select that operation. (For example, to

enter the menu, press the center softkey).

•Press O/Cat any time to return to the

previous screen.

•Press and hold O/Cto return to the idle

screen.

BEFORE YOU BEGIN

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page 1

1Install the handset battery pack.

Use only the battery supplied with this handset or AT&T Accessory

Battery Model 2401, SKU#91077.

•When you install the battery pack the first time, the handset will

display ENTER BASE ID.

Charge the handset battery.

•Place the handset in the

remote charging stand.

The CHARGING light

goes on.

•Charge the battery at least

12 hours. After the first

charge, the battery typically

charges in only eight hours.

CHARGE THE BATTERY

b) Align the contacts and place

the battery pack in the

battery compartment.

a) Remove battery

compartment cover by

pressing on indentation

and sliding downward.

c) Replace cover by

sliding it on its

track up over

battery case until

it snaps firmly into

place.

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page 2

To Model 5830/5870/3358/3658B Base Unit

1Make sure to charge the handset battery pack at least 12 hours.

2At the cordless handset, use the softkey to select NEW.

3Enter the 15-digit Base Unit ID Code located on the underside of your

Model 5830/5870/3358/3658B base.

4Use the softkey to select OK.The screen displays PLEASE WAIT!!.

5After about 45 seconds, the screen displays FOUND BASE.If the

handset displays BASE BUSY TRY LATER,the base is in use.

To Model 5840/5845 Base Unit

1Make sure to charge the handset battery pack at least 12 hours.

2At the 5840/5845 corded base, press .

3Use or to select DISPLAY BASE-ID.

4Press . The base screen will display the 15-digit Base ID code

for about 30 seconds, then return to the idle screen. Write down the

Base ID code so you can enter it at the handset in

STEP 6below.

5At the cordless handset, use the softkey to select NEW.

6Enter the 15-digit Base ID code.

7Use the softkey to select . The screen displays PLEASE

WAIT!!.

8After about 45 seconds, the screen displays FOUND BASE.If the

handset displays BASE BUSY TRY LATER,the base is in use.

For complete operational instructions,

please refer to the manual that came

with your 5830/5840/5845/3358/3658B/5870 telephone

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page 3

Belt Clip

Attach the belt clip (optional).

Headset

You can use this telephone

hands-free when you install

any industry standard

2.5 mm headset (purchased

separately). For best results

use an AT&T 2.5 mm headset.

Plug the headset into the jack

located on the left side of the

handset (under the small

rubber flap). Do not force the

connection, but make sure the

plug fits securely.

INSTALLATION

b) Press tabs

on belt clip

into slots

on back of

handset to

reattach.

a) Slide

down

into

grooves

to attach.

c) To remove,

lift one side

with your

thumbnail

and push

back.

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page 4

Battery Life

A fully charged battery provides an average talk time of about eight hours,

or standby time of five days.

NOTE: Talk time and standby time may vary depending on operating

conditions.

Charge the Handset Battery Pack

•After a low battery indicator, the handset battery needs to be charged.

•Place the handset in the base so the CHARGING light goes on. The

battery pack is typically charged

in nine hours.

•If you repeatedly get a low

battery indicator, even after nine

hours of charging, the battery

should be replaced. Use only

AT&T Battery 2401,

SKU# 91077.

CAUTION: Charge the

battery provided with

or identified for use

with this product only

in accordance with the

instructions and limitations

specified in the User’s

Manual, Part 1.

INSTALLATION

91-5785-10-ATT5806-manual 5/25/04 3:51 PM Page 5
