Model : PRO-OE2
TRANSMITTER PROGRAMMING GUIDE
The transmitters included with the system have been pre-programmed
at the factory, with each button pre-assigned to control a specific function
of the system. Although the system in the vehicle has eithera2or3
channel receiver, depending on the model, the transmitters included with
the system are capable of transmitting 3 distinct signals. This allows you
to program each transmitter to more than one vehicle in two car families,
and also allows you to change which button(s) control certain functions
of the system.
( Example: Transmitter channel 3 can be programmed to activate
Receiver channel 2. ) Refer to the chart below for access to each of the
transmitter channels, and for the standard factory button assignments.
TRANSMITTER SYSTEM RECEIVER
CHANNEL BUTTONS CHANNEL FUNCTION
1 LOCK 1 Remote Lock & Unlock
UNLOCK & or **Remote Arm/Disarm
**Remote Emergency Panic
2 OPTION 2 * Pulsed Output for Accessories
3 LOCK 3 * Switched Output for Accessories
UNLOCK * Second Vehicle Control
& OPTION
Some of the more common accessories for these additional
channels are;
*AS 9154 Remote Garage Door Interface
*AS 9075 Remote car starter
*AS 9153 Remote window roll up
*AS 9256 Remote trunk release relay
** Only Available With Some Systems
PROGRAMMING THE TRANSMITTERS
It is important to remember that during programming, each individual step
of the procedure must be executed within 15 seconds of the previous step.
When the 15 second time limit is allowed to expire, the system will
automatically terminate the programming mode. This is indicated by a long
chirp from the siren.
Additionally, the system will store codes from up to four different
transmitters. Ifa5thtransmitter is programmed to any receiver channel,
then the first transmitter programmed to that channel will be erased from
the system's memory.
NOTE:Some Keyless Entry Units do not include a sounding device
therefore may not respond with beep tones where indicated below.
Simply follow the proceedure and where where indicated, press
and hold the transmitter button for 3 seconds.
To program new or additional transmitters,
1. Enter the vehicle, and turn the ignition key to the " on " position.
2. Flip the valet switch on - off - on - off - on - then off.
3. The dash L.E.D. will flash one time, and the sounding device will beep
one time, indicating the system is ready to accept programming for
receiver channel 1.
4. Press and hold the Lock/Unlock Icon button until the sounding device
emits a long beep, indicating the signal has been stored into memory.
5. If you have additional transmitters ( up to 4 ) that need to be programmed,
repeat step 4 for each transmitter.
6. Flip the valet switch on then off.
7. The dash L.E.D. will flash two times, and the sounding device will beep
two times, indicating the system is ready to accept programming for
receiver channel 2.
8. Press and hold the Option transmitter button until the sounding device
emits a long beep, indicating the signal has been stored into memory.
9. Ifyouhaveadditional transmitters ( upto 4 ) thatneed to be programmed,
repeat step 8 for each transmitter.
10. Flip the valet switch on then off.
11. The dash L.E.D. will flash three times, and the sounding device will
beep three times, indicating the system is ready to acceptprogramming
for receiver channel 3 (only available on certain models).
13. Ifyouhave additional transmitter( up to4 ) thatneed to be programmed,
repeat step 12 for each transmitter.
14. Turn the ignition key off. The sounding device will emit one short beep
followed by one long beep indicating the system has terminated the
program mode.
TRANSMITTER BATTERY REPLACEMENT
You will notice a decrease in transmitter range as the battery condition
deteriorates. Transmitter battery replacement is recommended at least
every 10 to 12 months, depending upon how frequently the transmitter is
used.
The transmitter has a small red L.E.D. built into the case. This L.E.D. can
be used to indicate battery condition. If the L.E.D. does not illuminate, then
the battery is discharged, and must be replaced.
To replace the transmitter battery,
1. Remove the small phillips head screw from the bottom cover of the
transmitter.
2. Carefully unsnap the top cover of the transmitter from the bottom cover.
3. Remove the discharged battery, making note of the location of the +
and - contacts, and replace with a new type GP 27A 12 volt battery.
4. Replace the transmitter cover, taking care not to damage the L.E.D.
or switches on the circuit board, and secure with the small phillips
head screw.
© 1999 Audiovox Corporation 128-5308C
ORDER FORM FOR 2 BUTTON TRANSMITTER
MODEL NO. PRO OE2
Please indicate which transmitter pad is used with your transmitter as shown,
PD20 WhiteText PD21Red & White Text or PD22
IMPORTANT : To help us expedite your order, please print all of the information
legibly, and mail this form and your payment according to the instructions below.
1.Name: ____________________________________________________
Address: _____________________________________________________
City : _____________________ State : _______ Zip Code : ____________
2. Telephone Number : ( _______ ) _________________________________
3. Enter the total number of transmitters required here : ________________
4. The cost per transmitter is $ 65.00.
5. Enter the total amount enclosed here : ____________________________
( New York state residents must include the appropriate sales tax.)
6. Method of payment; check one of the boxes below.
Mastercard Visa Check or money order*(donotsend cash )
* Make checks payable to Audiovox Corporation
7. Credit Card Number : __________________________________________
8. Credit Card Expiration Date : _____________________
Credit card purchasers can order additional or replacement
transmitters by phone. Simply dial 1 - 800 - 645 - 4994, and follow
the instructions from the operator interface.
9. Mail this form, and your check, to ;
Audiovox Corporation, 150 Marcus Blvd., Hauppauge, N.Y., 11788
Attn : TRANSMITTER DEPARTMENT
© 1999 Audiovox Corporation 128-5308C
