Audiovox Pursuit PRO-OE3B3 Istruzioni operative
128-6121
1 of 4
TRANSMITTERPROGRAMMINGGUIDE
Model:PRO-OE3B3
The transmitters included with the security system have been pre-programmed
at the factory, with each button pre-assigned to control a specific function of the
security system. Although the security system in the vehicle has either a 3 or 4
channel receiver, depending on the model, the transmitters included with the
system are capable of transmitting 7 distinct signals. This allows you to program
each transmitter to more than one vehicle in two car families and also allows you
to change which button(s) control certain functions of the system.
(Example: Transmitter channel 5 can be programmed to activate Receiver
channel 2.) Refer to the chart below for access to each of the transmitter channels,
and for the standard factory button assignments.
Released 7-17-01.
Some of the more common accessories for these additional channels are;
AS 9554 Remote Garage Door Interface
AS 9075 Remote car starter
AS 9153 Remote window roll up
AS 9256 Remote trunk release relay
TRANSMITTER SYSTEM RECEIVER
CHANNEL BUTTON CHANNEL FUNCTION
Remote Arm
1 1 Remote Emergency Panic
Remote Door Lock
Remote Disarm
2 2 Remote Emergency Panic
Remote Door Unlock/Unlock 2
33
4& 4
5& 5
6 & 6 RF Channel For Options
7 7 RF Channel For Options
All 3
Buttons
Single Push Pulsed Output for Optional Accessory
Or Double Push For Additional Optional Accessory
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
128-6121
2 of 4
PROGRAMMINGTHETRANSMITTERS
It is important to remember that during programming, each individual step of
the procedure must be executed within 15 seconds of the previous step.
Whenthe15secondtimelimitisallowedtoexpire,thesystemwillautomatically
terminate the programming mode. This is indicated by a long chirp from the
siren.
NOTE: Some keyless entry systems will flash the interior light to indicate a
stored code. Substitute the words light flash below where indicated
sounding device will beep.
Additionally, the system will store codes from up to four different transmitters.
If a 5th transmitter is programmed to any receiver channel, then the first
transmitter programmed to that channel will be erased from the system's
memory.
To Program replacement or additional transmitters:
1. Enter the vehicle, and turn the ignition key to the "on" position.
2. Press and release the valet push-button switch 3 times.
3. The dash LED will flash one time and the sounding device will beep one
time, indicating the system is ready to accept programming for receiver's
Lock channel 1.
4. PressandholdtheLocktransmitterbuttonuntilthesoundingdeviceemits
a long beep, indicating the signal has been stored into memory.
5. If you have additional transmitters (up to 4) that need to be programmed,
repeat step 4 for each transmitter.
6. Press and release the valet push-button switch once.
7. The dash LED will flash two times and the sounding device will beep two
times,indicatingthesystemisreadytoaccept programmingforreceiver's
Unlock channel 2.
8. Press and hold the Unlock transmitter button until the sounding device
emits a long beep, indicating the signal has been stored into memory.
9. If you have additional transmitters (up to 4) that need to be programmed,
repeat step 8 for each transmitter.
10. Press and release the valet push-button switch once.
11. The dash LED will flash three times and the sounding device will beep
three times, indicating the system is ready to accept programming for
receiver's channel 3.
12. Press and hold the selected Option transmitter button until the sounding
device emits a long beep, indicating the signal has been stored into
memory.
13. If you have additional transmitters (up to 4) that need to be programmed,
repeat step 12 for each transmitter.
128-6121
3 of 4
14. Press and release the valet push-button switch once.
15. ThedashLED willflash fourtimesandthesounding devicewillbeepfour
times,indicatingthesystemisreadytoacceptprogrammingforreceiver's
channel 4.
16. Press and hold any button combination as shown on the front cover of
thisguideuntilthesoundingdeviceemitsalongbeep,indicatingthesignal
has been stored into memory.
17. If you have additionaltransmitters(up to 4) that need to be programmed,
repeat step 16 for each transmitter.
18. Press and release the valet push-button switch once.
19. The dash LED will flash four times, and the sounding device will beep
four times, indicating the system is ready to accept programming for
receiver's channel 5.
20. Press and hold any unused button combination as shown on the front
coverofthisguideuntilthesoundingdeviceemitsalongbeep,indicating
the signal has been stored into memory.
21. If you have additionaltransmitters(up to 4) that need to be programmed,
repeat step 20 for each transmitter.
22. Turn the ignition key off. The sounding device will emit one short beep
followed by one long beep indicating the system has terminated the
program mode.
TRANSMITTERBATTERYREPLACEMENT
You will notice a decrease in transmitter range as the battery condition
deteriorates. Transmitter battery replacement is recommended at least
every 10 to 12 months, depending upon how frequently the transmitter is
used.
ThetransmitterhasasmallLEDvisiblethroughthecase.ThisLEDcanbeused
to indicate battery condition. If the LED does not illuminate, then the battery
is discharged, and must be replaced.
To replace the transmitter battery:
1. Remove the small phillips head screws
from the bottom cover of the transmitter.
2. Carefully unsnap the top cover of the
transmitter from the bottom cover.
3. Removethedischargedbattery,making
note of the location of the + and - contacts, and replace with a new type
GP 27A 12 volt battery.
4. Replace the transmitter cover, taking care not to damage the LED or
switches on the circuit board, and secure with the small phillips head
screw.
128-6121
4 of 4
ORDER FORM FOR 3 BUTTON TRANSMITTER
MODEL NO. PRO-OE3B3
IMPORTANT : To help us expedite your order, please print all of the information legibly,
and mail this form and your payment according to the instructions below.
Note: Order Pad # 70 if your Lock & Unlock Icons are White
Order Pad # 71 if your Lock & Unlock Icons are Red.
Note: Transmitter model number found on back of case. ___________
1. Name : ____________________________________________________
Address: _____________________________________________________
City : _____________________ State : _______ Zip Code : ____________
2.Telephone Number : ( _______)_________________________________
3. Enter the total number of transmitters required here : ________________
4. List model number of your actual transmitter pad as shown on page 4 of this
manual: _________________________
5. The cost per transmitter is $ 65.00.
6. Enter the total amount enclosed here : ____________________________
(New York state residents must include the appropriate sales tax.)
7. Method of payment; check one of the boxes below.
!Mastercard !Visa !Check or money order * ( do not send cash )
* Make checks payable to Audiovox Corporation
8. Credit Card Number : ________________________________________
9. Credit Card Expiration Date : _____________________
Credit card purchasers can order additional or replacement
transmittersby phone. Simply dial 1 -800-645 - 4994, and follow
the instructions from the operator interface.
10. Mail this form, and your check, to ;
"
Audiovox Electronics Corp., 150 Marcus Blvd. Hauppauge, N.Y., 11788
Attn.:TRANSMITTER DEPARTMENT
© 2001 Audiovox Electronics Corporation, Hauppauge N.Y. 11788 128-6121
