DBD-16H-Mini-Bender-Manual | Page 3
WARNING - Incorrect use could result in death or serious
injury to the user or othes near by.
is product must not be used for purposes other than those
described in this instruction manual. .
Keep your workbench and surrounding workplace clean and
uncluttered..
Please use safety glasses, gloves and rubber-bottomed safety
shoes.
Use this tool on a stable surface with a stable working pos-
ture your feet rmly planted and balanced.
is is an electric power tool so be extremely careful of elec-
tric shock. Remember that moisture reduces the insulation
properties of the motor and may cause electric shock. Do
not use in the rain, wet places, or situations where water and
oil could easily enter inside the machine.
Please use a GFI power supply. Be sure the tool is grounded
correctly.
Please work properly. Baggy clothes, jewelry such as neck-
laces, ties, open cus, could get caught in the rotating part of
this machine.
Please be careful about ignition and explosion. Power tools
emit rectied sparks during use and when the switch is
opened and closed. Products emmiting amable fumes may
be ignited or explode Never use it in locations where these
dangers are present. Avoid using this tool in poorly venti-
lated places such as a closed area.
Do not mishandle the power cord. Do not carry the tool by
the power cord, or pull the cord to disconnect it from the
outlet. Be careful that the cord does not touch high-tempera-
ture heat, oil, chemicals, or sharp objects, etc.
Turn o the power tool and removing the plug from the
power outlet in the following cases;
when inspection, maintenance, repair are necessary and
when the tool is not in use
Before inserting the plug into the power outlet, make sure
that the switch is turned o.
Before use, carefully inspect the cord and protective parts for
damage, and make sure that it performs the desired func-
tion. Overheating can cause a malfunction.
Please use specied genuine parts when repairing this tool.
If you feel any abnormality while using the product, stop us-
ing it immediately and perform inspection and repair.
Do not exceed the maximum capacity
Handle power tools with care. If dropped or hit by mistake,
the outer frame may be deformed or damaged, take the time
to perform a thorough inspection before use.
Store power tools in places that are out of the reach of chil-
dren. Storage areas should be locked and where temperature
and humidity do not change suddenly. Storage areas should
also be free from direct sunlight and rain, free from mois-
ture, and dry.
Be careful of voltage drop when using extension cord.
is machine is a power tool intended for “bending work of
reinforcing steel used for concrete reinforcement”. Do not
use it for any other purpose.
Do not exceed the maximum capacity of the machine See
the specication chart.
When placing and using the product, use it on a level and
stable surface.
Specications:
Maximum Bending Diameter: 5/8” (#5) Rebar (16mm) Grade 60
Bending Angle / Speed Up to 180 degrees / 6 seconds
Voltage/Amperage: 100V 50/60Hz / 11 amps / 1050 W
Tool Weight: 40 lbs (20 kg)
Dimensions L x W x H: 12.5” (320 mm) x 13.75” (350 mm) x 9.65” (245 mm)
