Cleco CellCore CCBPW04Q Manuale utente

CellCore Demo

Pocket Guide

EASY TO HANDLE. HARD TO BREAK.

1. Inventory Check

 Do you have the essentials?

 Tool

 Battery

 Charger

 Don’t forget the small items!

 Test joint, socket, C-clamp, controller and ac-

cess point (if applicable)

 Does it look presentable?

 Free of dirt, grime, smudges, rust, and

scratches

 Cleaning toolkit

 Does it work?

 Test it 3 days prior to the event if possible

EASY TO HANDLE. HARD TO BREAK.

2. Walk the Line

 Do this the day of the demo

 Listen

 What are their pain-points?

 Ergonomics

 Speed

 Reliability

 Programming

 Accuracy requirement? CellCore is 2.0 cm/

cmk @ +/- 10%; designed specifically for

quality critical applications in MVI, but cus-

tomer requirements may vary

 Observe

 What product are we competing with?

 How are the operators using the tool?

 What is their process?

 Get creative with solutions

 We can improve by…

EASY TO HANDLE. HARD TO BREAK.

3. Talk About The Durability & Reliability

 500k Cycles Maintenance Free

 Increase uptime with more maintenance free

cycles

 Assembly Line Tough

 Drop tested up to 5 feet

 Accuracy guaranteed for life of the tool

 2.0 Cm/Cmk at +/- 10% accuracy

EASY TO HANDLE. HARD TO BREAK.

4. Talk About The Ergonomics

 Pistol tools start at 2.16lb (.98kg)

 Up to 23% lighter than LiveWire

 Right Angle tools start at 3.75lb (1.7kg)

 Up to 35% lighter than LiveWire

 2.0 Ah batteries weighs 0.94lb (.43kg)

 Tools are well balanced for comfort grip and

reduced torque on the operator

 Configure screen brightness in 3 levels for

multiple ambient conditions

EASY TO HANDLE. HARD TO BREAK.

5. Talk About the Ease of Use

 FastApps can be programmed on the tool through

intuitive user interface

 Up to 10 FastApps can be stored on each tool and

selected from the run screen with the push of a but-

ton

 User interface is icon based for multi-lingual plants

 Tool can be locked out to 4 different levels

EASY TO HANDLE. HARD TO BREAK.

6.Talk About the Mul-Color Worklight

 Multicolor LED worklight illuminates workpiece with

OK/NOK indication

 Green—OK

 Red—NOK

 Blue—Batch OK

 Offers additional operator feedback for error pre-

vention

 Programmable in 4 different modes:

 Light disabled

 Tool light on during partial trigger pull

only

 Tool light on for 3 seconds after start

switch is pulled

 Tool light on during entire tightening se-

quence

EASY TO HANDLE. HARD TO BREAK.

7. Talk About The Stay Alive Funcon

 Tool will stay connected and on while the battery is

being changed (up to 15 seconds)

 Saves boot time

 Saves reconnect to wifi time

 Prevents tool from losing batch count

EASY TO HANDLE. HARD TO BREAK.

8. Talk About The Versality

 Tool can be ran with or without a controller

 With a controller:

 Operates identical to LiveWire series

 Can connect to legacy mPro controllers

(Primary, Hybrid and Master)

 Connect up to 16 tools on an mPro 400 con-

troller

 Connect up to 10

tools on an mPro

200 controller

 Without a controller:

 Store up to 10 pre-

programmed appli-

cations on the tool

 Store 15,000 run-

downs on tool

 Store 500 torque

traces on tool

 Easily export run-

EASY TO HANDLE. HARD TO BREAK.

9. Talk About The mPro200 Controller

 10 cordless tools pair to one controller

 Compatible with CellCore, LiveWire and I-Wrench

 Compact size (LxWxH) (12.6” x 4.4” x 13.4”)

 VGA output to remotely mount a monitor or screen

 Connections:

2X Fieldbus

2X Ethernet

2X Serial RS-232

3X USB

1X VGA Output

8X 24V I/O

1X Power Input
