DFI NF2 U400SG-AGF Manuale utente

82200435

nF2 U400SG-AGF

nF2 U400S-AL

System Board

User’s Manual

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or

used to make any transformation/adaptation without the prior writ-

ten permission from the copyright holders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any

express or implied warranties of merchantability or fitness for any

particular purpose.The user will assume the entire risk of the use or

the results of the use of this document. Further, the manufacturer

reserves the right to revise this publication and make changes to its

contents at any time, without obligation to notify any person or

entity of such revisions or changes.

Trademarks

Windows®98, Windows®98 SE, Windows®ME, Windows®2000,

Windows NT®4.0 and Windows®XP are registered trademarks of

Microsoft Corporation. AMD, SempronTM, AthlonTM XP and DuronTM

are registered trademarks of Advanced Micro Devices, Inc. nVIDIA®

is a registered trademark of NVIDIA Corporation. VIA®is a regis-

tered trademark of VIA Technologies, Inc. Award is a registered

trademark of Award Software, Inc. Other trademarks and registered

trademarks of products appearing in this manual are the properties

of their respective holders.

Caution

To avoid damage to the system:

• Use the correct AC input voltage range.....

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis

cover for installation or servicing. After installation or servicing,

cover the system chassis before plugging the power cord.

Battery:

• Danger of explosion if battery incorrectly replaced.

• Replace only with the same or equivalent type recommend

the manufacturer.

• Dispose of used batteries according to the battery manufactur-

er’s

instructions.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2. Shielded interface cables must be used in order to comply with

the emission limits.

About this Manual

This user’s manual contains detailed information about the system

board. If, in some cases, some information doesn’t match those

shown in the multilingual manual, the multilingual manual should al-

ways be regarded as the most updated version. The multilingual

manual is included in the system board package.

To view the user’s manual, insert the CD into a CD-ROM drive.The

autorun screen (Mainboard Utility CD) will appear. Click the

“TOOLS” icon then click “Manual” on the main menu.

About the Package

The system board and accessories in the package may not come

similar to the information stated in this manual. This may differ in

accordance to the sales region or models in which it was sold. For

more information about the standard package in your region, please

contact your dealer or sales representative.

Warranty

1. Warranty does not cover damages or failures that arised from

misuse of the product, inability to use the product, unauthorized

replacement or alteration of components and product

specifications.

2. The warranty is void if the product has been subjected to

physical abuse, improper installation, modification, accidents or

unauthorized repair of the product.

3. Unless otherwise instructed in this user’s manual, the user may

not, under any circumstances, attempt to perform service,

adjustments or repairs on the product, whether in or out of

warranty. It must be returned to the purchase point, factory or

authorized service agency for all such work.

4. We will not be liable for any indirect, special, incidental or

consequencial damages to the product that has been modified

or altered.

Table of Contents

Chapter 1 - Introduction

1.1 Specifications......................................................................................................................

1.2 Special Features of the System Board.....................................................

1.3 Package Checklist.........................................................................................................

Chapter 2 - Hardware Installation

2.1 System Board Layout ...........................................................................................

2.2 System Memory...........................................................................................................

2.3 CPU........................................................................................................................................

2.4 Jumper Settings.............................................................................................................

2.5 Rear Panel I/O Ports..............................................................................................

2.6 I/O Connectors...........................................................................................................

Chapter 3 - Award BIOS Setup Utility

3.1 The Basic Input/Output System.....................................................................

3.2 NVRAID BIOS...............................................................................................................

3.3 Updating the BIOS.....................................................................................................

Chapter 4 - Supported Softwares

4.1 Drivers, Utilities and Software Applications.....................................

4.2 Installation Notes......................................................................................................

107

Introduction

Appendix A - System Error Messages

A.1 POST Beep........................................................................................................................

A.2 Error Messages...............................................................................................................

Appendix B - Troubleshooting

B.1 Troubleshooting Checklist.....................................................................................

108

110

Notice

This user’s manual is for the nF2 U400SG-AGF and nF2 U400S-AL

system boards. The differences between these boards are shown

below.

nF2 U400SG-AGF NVIDIA nForce2 Ultra 400 and nForce2 MCP GIG

VIA VT6307 supports 2 IEEE 1394 connectors

Gigabit Phy supports 10/100/1000Mbps

nF2 U400S-AL NVIDIA nForce2 Ultra 400 and nForce2 MCP RAID

IEEE 1394 - not supported

LAN Phy supports 10/100Mbps

Introduction

Chapter 1 - Introduction

1.1 Specifications

Processor

• AMD SempronTM and AthlonTM XP (up to 3200+)

• AMD DuronTM

• Socket A

Front Side Bus

• 266/333/400MHz

Chipset

• nF2 U400SG-AGF

nVIDIA®nForce2 Ultra 400Gb

- North bridge: nForce2 Ultra 400

- South bridge: nForce2 MCP GIG

• nF2 U400S-AL

nVIDIA®nForce2 Ultra 400R

- North bridge: nForce2 Ultra 400

- South bridge: nForce2 MCP RAID

System Memory

• Three 184-pin DDR SDRAM DIMM sockets

• Supports dual channel (128-bit wide) memory interface

• Supports up to 3GB memory

• Supports PC2100 (DDR266), PC2700 (DDR333) and PC3200

(DDR400) DDR SDRAM DIMM

• Supports x8/x16, non-ECC, up to 512Mb DDR devices

• Supports unbuffered DIMM

BIOS

• Award BIOS

• CPU/DRAM/AGP overclocking

• CPU/DRAM/AGP overvoltage

• 4Mbit flash memory

Energy Efficient Design

• Supports ACPI specification and OS Directed Power

Management

• Supports ACPI STR (Suspend to RAM) function

Introduction

• Wake-On-Events include:

- Wake-On-PS/2 Keyboard/Mouse

- Wake-On-Ring (external modem)

- Wake-On-LAN

- RTC timer to power-on the system

• AC power failure recovery

Hardware Monitor

• Monitors CPU/system temperature

• Monitors 12V/5V/3.3V/Vcore/Vbat/5Vsb/3.3Vsb voltages

• Monitors the speed of the CPU fan and chassis fan

• CPU Overheat Protection function monitors CPU temperature

during system boot-up

Audio Features

• AC’97 CODEC

• Supports Microsoft®DirectSound/DirectSound 3D

• AC’97 supported with full duplex, independent sample rate

converter for audio recording and playback

• S/PDIF-in/out interface

• 6-channel audio output

Onboard LAN Features

• nF2 U400SG-AGF

- Marvell 88E1111 Gigabit Phy supports 10/100/1000Mbps

- Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-

TX) and 802.3ab (1000BASE-T) standards

• nF2 U400S-AL

- LAN Phy supports 10/100Mbps

- Fully compliant to IEEE 802.3 (10BASE-T) and 802.3u

(100BASE-TX) standards

IDE Interface with NVIDIA RAID

• Two IDE connectors support four UltraDMA 133Mbps hard

drives

• NVIDIA RAID supports spanning across Serial ATA and Parallel

ATA

• RAID 0, RAID 1, RAID 0+1 and JBOD

Introduction

Serial ATA Interface with NVIDIA RAID

• Two Serial ATA interfaces with speed up to 1.5Gbps

• NVIDIA RAID supports spanning across Serial ATA and Parallel

ATA

• RAID 0, RAID 1, RAID 0+1 and JBOD

IEEE 1394 Interface (nF2 U400SG-AGF only)

• VIA VT6307 controller

• Supports two 100/200/400 Mb/sec ports

Accelerated Graphics Port (A.G.P.)

• Supports AGP 8x up to 2132MB/sec. and AGP 4x up to

1066MB/sec. bandwidth for 3D graphics applications

• Supports 0.8/1.5V add-in cards

Rear Panel I/O Ports

• 1 PS/2 mouse port

• 1 PS/2 keyboard port

• 1 DB-25 parallel port

• 2 S/PDIF RCA jacks (S/PDIF-in and S/PDIF-out)

• 1 DB-9 serial port

• 1 RJ45 LAN port

• 4 USB 2.0/1.1 ports

• Line-in, line-out and mic-in jacks

I/O Connectors

• 2 connectors for 4 additional external USB 2.0/1.1 ports

• 2 connectors for 2 external IEEE 1394 ports (nF2 U400SG-AGF

only)

• 1 front audio connector for external line-out and mic-in jacks

• 1 CD-in internal audio connector

• 1 S/PDIF connector for optical cable connection

• 1 IrDA connector

• 2 Serial ATA connectors

• 2 IDE connectors

• 1 floppy connector

• 1 20-pin ATX power connector

• 1 4-pin ATX 12V power connector

• 1 front panel connector

• 2 fan connectors

Introduction

Expansion Slots

• 1 AGP 8x/4x slot

• 5 PCI slots

PCB

• ATX form factor

• 30.5cm (12") x 24cm (9.44")

1.2 Special Features of the System Board

CPU Overheat Protection

CPU Overheat Protection has the capability of monitoring the CPU’s

temperature during system boot up. Once the CPU’s temperature

exceeded the temperature limit pre-defined by the CPU, the system

will automatically shutdown.This preventive measure has been added

to protect the CPU from damage and insure a safe computing

environment.

DDR

DDR (Double Data Rate) is a type of SDRAM that doubles the

data rate through reading and writing at both the rising and falling

edge of each clock. This effectively doubles the speed of operation

therefore providing two times faster data transfer.

S/PDIF

S/PDIF is a standard audio file transfer format that transfers digital

audio signals to a device without having to be converted first to an

analog format. This prevents the quality of the audio signal from

degrading whenever it is converted to analog. S/PDIF is usually

found on digital audio equipment such as a DAT machine or audio

processing device.The S/PDIF connector on the system board sends

surround sound and 3D audio signal outputs to amplifiers and

speakers and to digital recording devices like CD recorders.

6-channel Audio

The audio jacks at the rear panel will support 6-channel audio only

when the audio utility is configured to support this function.

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Scheda madre popolari di altre marche

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente

DFI nF2 U400SG-AGF Manuale utente

Manuali Scheda madre popolari di altre marche
