Elcometer 415 Manuale utente

Elcometer 415

Paint & Powder Gauge

(for measuring on smooth surfaces)

User Guide

www.elcometer.com

For the avoidance of doubt, please refer to the original English language version.

Gauge Dimensions: 141 x 73 x 37mm (5.55 x 2.87 x 1.46")

Gauge Weight: 156g (5.5oz) including batteries

transcribed, stored (in a retrieval system or otherwise) or translated into any language, in any form or by any

means (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of

Elcometer Limited.

CONTENTS

en-1

Section

Page

Gauge Overview

en-2

Box Contents

en-2

Using the Gauge

en-3

Getting Started

en-3

Taking a Reading

en-5

Statistics

en-6

Calibrating the Gauge

en-6

Downloading Data

en-8

Upgrading your Gauge

en-9

Spares & Accessories

en-9

Warranty Statement

en-9

Technical Specification

en-10

Legal Notices & Regulatory Information

en-11

Appendix 1: Summary of Gauge Icons

en-12

Appendix 2: ElcoMaster Collect Design

en-13

1 GAUGE OVERVIEW

2 Colour Screen

6 USB Data Output Socket (below cover)

1 LED Indicators - Red (left), Green (right)

3 Multifunction Softkeys

7 Battery Compartment (¼ turn open/close)

5 Integral Probe

4 On/Off Key

8 Wrist Strap Connection

www.elcometer.com en-2

2 BOX CONTENTS

Elcometer 415 Paint & Powder Gauge

Calibration Check Piece; Steel

Calibration Check Piece; Aluminium (FNF gauges only)

Foil Set

Screen Protector (Model T only)

Wrist Strap

Protective Case

2 x AA Batteries

ElcoMaster Software & USB Cable (Model T only)

Test Certificate

User Guide

a Nominal Values: 25, 50, 125, 250, 500 &1000µm (1.0, 2.0, 5.0, 10, 20, 40mils)

3 USING THE GAUGE

www.elcometer.com

en-3

Power: Batteries or USB -

including battery life indicator

Bluetooth On (Model T only) -

Grey: not paired; Orange: paired

Substrate Type - F: Ferrous; FNF: Ferrous;

FNF: Non-Ferrous

Calibration Method

Units of Measurement - µm, mils

Menu Softkey

Statistics Softkey (see page en-6)

Calibration Softkey

Statistics

4 GETTING STARTED

4.1 ENSURING YOUR GAUGE HAS THE LATEST FIRMWARE

& UPGRADING YOUR GAUGE

Each gauge is supplied with 2 x AA alkaline

batteries.

To insert or replace the batteries:

To ensure that your gauge has the most up-to-date gauge firmware,

allowing you to benefit from the latest features and functionality, we

recommend that the gauge is connected to ElcoMaster on a regular

basis and before first use.

Simply connect the gauge via USB to an internet connected computer

running ElcoMaster using the ‘Connect Gauge’ feature. If a later

version of the gauge firmware is available, ‘Update Gauge’ will be

displayed to the right of the gauge details. Click ‘Update Gauge’ to

install the latest firmware.

4.2 FITTING THE BATTERIES

1 Lift the latch on the battery compartment

cover and rotate anti-clockwise to remove

the cover.

3 Refit the cover and rotate the latch

clockwise to close.

2 Insert 2 batteries taking care to ensure

correct polarity.

The battery condition is indicated by a symbol in the top right of the

display ( ):

4 Full symbol (orange) = batteries at full capacity

4.3 SWITCHING ON / OFF

4 Empty symbol (red, flashing) = batteries at lowest

sustainable level

To switch off: Press and hold the ON/OFF button until the screen

goes blank.

4.4 SETTING THE BEEP VOLUME

Note: The gauge will switch off automatically after 1 minute of inactivity.

2 Use the softkeys to highlight ‘ ’ and press ‘ ’ to select.

4.5 SETTING THE SCREEN BRIGHTNESS

2 Use the softkeys to highlight ‘ ’ and press ‘ ’ to select.

To switch on: Press and hold the ON/OFF button until the Elcometer

logo is displayed.

3 Use the softkeys to adjust the screen brightness and press

‘ ’ to set or ‘ ’ to disregard any changes made and return to the

previous screen.

4 The default setting is ‘ ’ (Auto) .

The screen brightness can be set to ‘ ’ - the brightness is (Auto)

adjusted automatically using the gauge’s ambient light sensor - or can

be set by the user to suit the measurement conditions. To set the

screen brightness:

The gauge beeps each time a measurement is taken. To set the beep

volume:

1 Press the ‘ ’ softkey.

3 Use the softkeys to adjust the volume and press ‘ ’ to set or

‘ ’ to disregard any changes made and return to the previous

screen.

www.elcometer.com en-4

4 GETTING STARTED (continued)

www.elcometer.com

en-5

The Elcometer 415 calculates and displays statistical values as each

reading is taken, see Section 6 ‘Statistics’ for details.

The gauge should be calibrated before taking readings, see Section 7

‘Calibrating the Gauge’ on page en-6.

1 Whilst holding the gauge perpendicular, gently place the probe

onto the surface.

To take a reading:

4 The reading may be inaccurate if the probe is not held flat against the

surface.

2 The coating thickness is shown on the display.

4 ‘>1000µm’ (‘>40mils’) indicates a reading outside the gauge range.

3 For subsequent readings, lift the probe off and then replace it on

to the coated surface.

Using ElcoMaster the Elcometer 415 can simultaneously transmit the

live reading to a PC or mobile device (Model T only) for report

generation, see Section 8 ‘Downloading Data’ on page en-8 for more

information.

4.6 SELECTING THE MEASUREMENT UNITS

The Elcometer 415 can take measurements in µm and mils. To set the

measurement units:

2 Use the softkeys to highlight ‘µm/mil’ and press ‘ ’ to

alternate between ‘µm’ and ‘mil’, followed by the ç softkey to

return to the main reading screen.

4.7 SCREEN ROTATION

To enable / disable automatic screen rotation:

1 Press the ‘ ’ softkey.

2 Use the softkeys to highlight ‘ ’ and press ‘ ’ to alternate

between ‘ ’ (disabled) and ‘ ’ (enabled), followed by the ç

softkey to return to the main reading screen.

1 Press the ‘ ’ softkey.

Using the internal accelerometer, the gauge will automatically rotate

the display to allow the user to easily read the thickness value in any

orientation - 0°, 90°, 180° & 270°.

5 TAKING A READING

4 GETTING STARTED (continued)

www.elcometer.com en-6

7 CALIBRATING THE GAUGE

values of thickness to ensure accuracy on different substrate types,

shapes and surface finishes.

The calibration adjustment method chosen depends on the condition

of the substrate to be measured. As the Elcometer 415 has been

specifically designed for measuring smooth coatings on thin ferrous

and non-ferrous metal surfaces, two calibration options are available;

Zero Calibration and Smooth Calibration.

Calibration adjustment is the process of setting the gauge to known

Calibration

Method

Icon

Description

Zero

Calibration

A simple method for calibrating on smooth

uncoated metal and the gauge will adjust the

calibration accordingly. Also known as the

single point calibration method.

substrates. Simply place the probe on the

Smooth

Calibration

This is a more accurate method of calibrating

the gauge than the Zero method as it

requires the user to calibrate the gauge

using a foil of known thickness and the un-

coated substrate.

6 STATISTICS

The Elcometer 415 calculates and displays the following statistical

values as each measurement is taken:

Ÿ Number of readings (n:)

Ÿ Average reading (X:)

Ÿ Lowest reading (Lo:)

Ÿ Highest reading (Hi:)

To display or hide the statistics from the screen, press the ‘ ’

softkey.

To clear the current statistical values, ‘ ’ softkey press and hold the

for approximately 3 seconds (when statistics are displayed). The

gauge will beep and the statistics will reset to zero.

www.elcometer.com

en-7

7 CALIBRATING THE GAUGE (continued)

Note: FNF gauges must be calibrated in both the ferrous

and non-ferrous mode to ensure accuracy of

readings.

1 Press the ‘ ’ softkey.

4 Foils can also be stacked to increase the

thickness value.

3 Use the softkeys to adjust the value,

followed by ‘ ’ to set.

2 When prompted, whilst holding the gauge

perpendicular, gently place the probe onto

the uncoated metal substrate. ‘Zero’ will

be displayed and the gauge will return to

the main reading screen.

4 When selecting the foil value, the user should

choose a thickness that is close to but greater

than the expected dry film thickness value.

4 When prompted, whilst holding the gauge

perpendicular, gently place the probe onto

the uncoated metal substrate. ‘Zero’ will

be displayed and the gauge will return to

the main reading screen.

7.1 SELECTING THE CALIBRATION METHOD

2 Use the softkeys to highlight ‘ ’ and press ‘ ’ to

alternate between Zero ‘ ’ and Smooth ‘ ’ calibration,

followed by the ç softkey to return to the main reading screen.

1 Press the ‘ ’ softkey.

2 When prompted, whilst holding the gauge

perpendicular, gently place the probe onto the

centre of the foil(s).

Note: FNF gauges must be calibrated in both the ferrous

and non-ferrous mode to ensure accuracy of

readings.

7.2 USING ZERO CALIBRATION

7.3 USING SMOOTH CALIBRATION

1 Press the softkey.‘ ’

8 DOWNLOADING DATA

Using ElcoMaster - supplied with each gauge and available as a free

download at elcometer.com - the Elcometer 415 can simultaneously

transmit the live reading via USB or Bluetooth (Model T only), to a PC

for report generation. For more information on ElcoMaster visit

www.elcometer.com.

Ideal when out in the field or on-site, using the ElcoMaster Mobile App

users can:

Ÿ Store live readings directly on to a mobile device and save them

into batches together with GPS coordinates.

8.2 USING ELCOMASTER MOBILE APPS - MODEL T

Ÿ Add photographs of the test surface (via the mobile device’s camera).

Ÿ Map readings on to a photograph or diagram (when using the

® ®

‘Collect Design’ function in ElcoMaster - see Appendix 2 ‘ElcoMaster

Collect Design’ on page en-13)

8.1 USING ELCOMASTER ON A PC

Ÿ Inspection data can be transferred from mobile to PC for further

analysis and reporting.

Compatible with smart phones

and tablets running Android 2.1

or above. To install, download

via www.elcometer.com or using

the Google Play™ Store app,

and follow the on screen

instructions.

For more information on ElcoMaster Mobile Apps visit

www.elcometer.com

www.elcometer.com en-8

If the gauge does not display a valid reading, it may require

re-calibration - see Sections 7.2 & 7.3.

3 The gauge should read the value printed on the foil label ±1-3%

or ±2.5 - whichever is the greater.μm (±0.1mil)

7.4 CHECKING THE GAUGE CALIBRATION

2 Whilst holding the gauge perpendicular, gently place the probe

onto the foil.

1 Place a calibration foil on to the steel or aluminium check piece

supplied.

7 CALIBRATING THE GAUGE (continued)

Gauge firmware can be upgraded to the latest version by the user via

® ®

ElcoMaster , as it becomes available. ElcoMaster will inform the user

of any updates when the gauge is connected to the PC with an internet

connection.

9 UPGRADING YOUR GAUGE

10 SPARES & ACCESSORIES

Certified Foil Set; 0 - 1000µm (0 - 40mils) T99022255-1C

Calibration Check Piece; Aluminium (Non-Ferrous) T99916901

Foil Set; 0 - 1000µm (0 - 40mils) T99022255-1

The following spares and accessories are available from your local

Calibration Check Piece; Steel (Ferrous) T99916925

Description Part Number

Self Adhesive Screen Protectors, Pack of 10 T99922341

Elcometer supplier or direct from Elcometer.

USB Cable T99921325

a Nominal Values: 25, 50, 125, 250, 500 &1000µm (1.0, 2.0, 5.0, 10, 20, 40mils)

11 WARRANTY STATEMENT

manufacturing defects, excluding contamination and wear.

The warranty can be extended to two years within 60 days of purchase

via www.elcometer.com.

Elcometer 415 gauges are supplied with a one year warranty against

www.elcometer.com

en-9

Made for iPhone 6 Plus, iPhone

6, iPhone 5s, iPhone 5c, iPhone

5, iPhone 4s, iPhone 4, iPad Air

2, iPad mini 3, iPad Air, iPad mini

2, iPad (3rd and 4th generation),

iPad mini, iPad 2, and iPod touch

(4th and 5th generation). To

install, download via

www.elcometer.com or the App

Store, and follow the on screen

instructions.

8 DOWNLOADING DATA (continued)

Altri manuali per 415

Indice

Altri manuali Elcometer Strumento di misura

Elcometer

Elcometer 3000 Series Manuale utente

Elcometer

Elcometer 2350 Manuale utente

Elcometer

Elcometer 456 IPC Manuale utente

Elcometer

Elcometer 319 Standard Manuale utente

Elcometer

Elcometer 500 Manuale utente

Elcometer

Elcometer 701 Manuale utente

Elcometer

Elcometer 102 Manuale utente

Elcometer

Elcometer 550 Manuale utente

Elcometer

Elcometer G116A-1 Manuale utente

Elcometer

Elcometer CG70ABDL Manuale utente

Elcometer

Elcometer 138 Manuale utente

Elcometer

Elcometer 320 Manuale utente

Elcometer

Elcometer 138 Manuale utente

Elcometer

Elcometer 319 Standard Manuale utente

Elcometer

Elcometer protovale P330 Manuale utente

Elcometer

Elcometer 116c Manuale utente

Elcometer

Elcometer Novo-Gloss 406 Manuale utente

Elcometer

Elcometer Zahn 2210 Manuale utente

Elcometer

Elcometer 3000 Series Manuale utente

Elcometer

Elcometer PG70 Manuale utente

Elcometer

Elcometer 112 Manuale utente

Elcometer

Elcometer 456 Manuale utente

Elcometer

Elcometer Protovale 331 Manuale utente

Elcometer

Elcometer FD700DL+ Manuale utente

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente
