Electrolux Dito 603311 Manuale utente
Item
Model
ProjectName
Vegetable slicers
TRS - 1 Speed
With the TRS universal vegetable
slicer it is possible to quickly and
easily make over 70 different types
of cuts for the stylish and
imaginative presentation of salads,
garnishings, macedoines, chips
and many other combinations.
FEATURES
V Wide range of functions: slicing, mincing,
grating, shredding and cutting into chips or
cubes of all sizes.
V Plate speed at 360 RPM for precise cutting,
slicing and dicing.
V Large round hopper (215cm²) allows food of
greater dimension to be processed.
V Feeding arm with integrated long-vegetable
hopper (tube pusher), 60mm in diameter. Ideal
for carrots, zucchini, cucumbers, etc.
V Base inclined at 20° provides easy loading
and unloading.
V High discharge zone permits the use of deep
GN containers (up to 20cm).
V Feeding arm and hopper are made entirely in
stainless steel and ABS. Aluminium motor
housing.
V Plates and ejector may be removed in
seconds by opening the cover.
V All parts that come into contact with the food
are in stainless steel or plastic, can be removed
for easy cleaning and are dishwasher safe.
Specifications
MODEL
TRS1V371
603312
TRS1V501
603311
TRS1V503
603313
TRS1V3716
603387
TRS1V5016
603519
External dimensions - mm
width 252 252 252 252 252
depth 500 500 500 500 500
height 502 502 502 502 502
Speed - rpm 360 360 360
Cutting capacity - kg/h
carrots 250 250 250 250 250
chips 500 500 500 500 500
dicing 450 450 450 450 450
Cutting capacity - kg/h
potatoes 250 250 250 250 250
Power - kW
installed-electric 0.37 0.5 0.5 0.37 0.5
Net weight - kg. 21.4 21.4 21.4 21.4 21.4
Supply voltage 220...240 V,
1N, 50
220...240 V,
1N, 50
200...240/380...440
V, 3, 50/60
208...240 V,
1N, 60
208...240 V,
1N, 60
V Sleek, compact and innovative design. Rounded
corners allow for easy cleaning.
V IPX5 touch-control, waterproof panel. Green
button indicates ON, Red button indicates OFF.
Pulse control for precise slicing.
V Asynchronous industrial motor with no brushes
for high reliability and quiet functioning. Stainless
steel motor shaft.
V Two separate safety switches stop the machine in
order to protect the operator from potentially
dangerous conditions. One senses when the handle
is lifted and/or the shaft is removed and the other
senses when the cover is opened.
V IP24 throughout entire machine.
Optional accessories
CODE DESCRIPTION
TRS1V371
603312
TRS1V501
603311
TRS1V503
603313
TRS1V3716
603387
TRS1V5016
603519
653568 DICING GRID 10 MM FOR VEGETABLE
SLICER ✓✓✓✓✓
653569 DICING GRID 12 MM FOR VEGETABLE
SLICER ✓✓✓✓✓
653570 DICING GRID 20 MM FOR VEGETABLE
SLICER ✓✓✓✓✓
653566 DICING GRID 5 MM FOR VEGETABLE
SLICER ✓✓✓✓✓
653567 DICING GRID 8 MM FOR VEGETABLE
SLICER ✓✓✓✓✓
653122 DISC WITH CORRUGATED BLADES 2
MM ✓✓✓✓✓
653123 DISC WITH CORRUGATED BLADES 3
MM ✓✓✓✓✓
653126 DISC WITH CORRUGATED BLADES 6
MM ✓✓✓✓✓
653111 DISC WITH CURVED BLADES 1 MM ✓✓✓✓✓
653511 DISC WITH CURVED BLADES 10 MM ✓✓✓✓✓
653112 DISC WITH CURVED BLADES 2 MM ✓✓✓✓✓
653113 DISC WITH CURVED BLADES 3 MM ✓✓✓✓✓
653115 DISC WITH CURVED BLADES 5 MM ✓✓✓✓✓
653162 GRATING DISC 2 MM ✓✓✓✓✓
653163 GRATING DISC 3 MM ✓✓✓✓✓
653164 GRATING DISC 4 MM ✓✓✓✓✓
653167 GRATING DISC 7 MM ✓✓✓✓✓
653498 GRATING DISC 9 MM ✓✓✓✓✓
653008 GRATING DISC FOR KNODELN AND
BREAD ✓✓✓✓✓
653170 GRATING DISC FOR PARMESAN AND
BREAD ✓✓✓✓✓
653573 GRID FOR CHIPS 10MM FOR
VEGETABLE SLICER ✓✓✓✓✓
653571 GRID FOR CHIPS 6MM FOR
VEGETABLE SLICER ✓✓✓✓✓
653572 GRID FOR CHIPS 8MM FOR
VEGETABLE SLICER ✓✓✓✓✓
653283 S/S WORK TABLE+FOLDING
SHELVES+DISK RACK ✓✓✓✓✓
653214 SHREDDING DISC 2X2 MM ✓✓✓✓✓
653153 SHREDDING DISC 3X3 MM ✓✓✓✓✓
653154 SHREDDING DISC 4X4 MM ✓✓✓✓✓
653289 SLICING BLADES VARIABLE DEPTH
1MM-7MM ✓✓✓✓✓
653565 SLICING DISC FOR MOZZARELLA 10
MM ✓✓✓✓✓
653101 SLICING DISC WITH STRAIGHT
BLADES 1 MM ✓✓✓✓✓
653110 SLICING DISC WITH STRAIGHT
BLADES 10 MM ✓✓✓✓✓
653185 SLICING DISC WITH STRAIGHT
BLADES 14 MM ✓✓✓✓✓
653102 SLICING DISC WITH STRAIGHT
BLADES 2 MM ✓✓✓✓✓
653103 SLICING DISC WITH STRAIGHT
BLADES 3 MM ✓✓✓✓✓
653106 SLICING DISC WITH STRAIGHT
BLADES 6 MM ✓✓✓✓✓
653108 SLICING DISC WITH STRAIGHT
BLADES 8 MM ✓✓✓✓✓
653180 TABLE+SHELF+GN 1/1
POLYCARBONATE TRAY ✓✓✓✓✓
AAAC010
www.dito-electrolux.com
Vegetable slicers
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
Installation drawings
XXX
I - Electrical connection 220...240 V, 1N,
50
220...240 V, 1N,
50
200...240/380...440
V, 3, 50/60
208...240 V, 1N,
60
208...240 V, 1N,
60
MODEL
TRS1V371
603312
TRS1V501
603311
TRS1V503
603313
TRS1V3716
603387
TRS1V5016
603519
603312, 603519, 603387, 603313, 603311
I
780
202
320
502
252
500
