Bakery and pastry making

Superior

performance,

home-baked

goodness

dito electrolux bakery 3

Bakeries

When variety is of utmost

importance. Satisfy even

the most demanding

customers by offering

specialty breads for all

occasions.

Pastry shops

Prepare even the most

delicate desserts and

make your customers

smile.

Give your customers a little

taste of home

Take-away &

Corner shops

When time is short but

home-baked goodness is

a must.

Pizzerias

The perfect choice for

original recipes: use soy,

wheat, and even corn ﬂour

to offer your customers

mouth-watering pizzas.

dito electrolux bakery4

Planetary mixers 5, 10 litres

Dito Electrolux offers a complete range of planetary mixers designed to

withstand the strong demands of bakery and pastry making.

BE5

Professional 5 litre planetary mixer for mixing, kneading

and emulsifying.

Powerful, reliable asynchronous motor with

frequency variator for a precise adjustment of the

planetary mechanism speed between 15 and 220 rpm

Aluminium column protects the motor and speed

variator against external agents

One-piece alloy head contains the planetary gears

and transmission for added safety

Equipped with 3 tools: whisk, paddle and spiral

kneading hook

Tools rotate at speeds from 31 to 462 rpm

•

Spiral hook Accessory hub

18/8 stainless steel bowl with handle, 5.2 litre

capacity

Transparent safety screen activates the raising and

lowering of the bowl and is removable to facilitate

cleaning

A metal base ensures perfect stability at all times

even when mixing stiff doughs and pastes

A model with accessory hub is available upon

request

For an even more complete machine, accessories

such as meat mincer and vegetable cutter are

available as an option. The wide choice of slicing discs

for the vegetable cutter allows you to prepare even the

most elaborate recipes

•

dito electrolux bakery 5

XBE10

10 litre planetary mixer which satisﬁes the many requirements of

professional bakeries.

Knead all types of doughs and pastry, mix sauces and emulsify

creams

Electronic speed variation allows an accurate setting of all

parameters

Powerful motor with frequency variator permits a precise adjustment

of the planetary mechanism speed between 26 and 180 rpm

Splash proof planetary system ensures water does not enter the

mechanism

18/8 stainless steel bowl, 10 litre capacity

Supplied with 3 tools: stainless steel whisk, robust paddle and spiral

hook

Tools rotate at speeds from 55 to 378 rpm

•

Stainless steel column Touch button control panel

Transparent safety screen Kit (bowl, hook, paddle, whisk)

Stainless steel column protects the

motor and speed variator

Height adjustable feet ensure stability

User friendly touch button control

panel for improved ergonomics and

protection against humidity or jets

of water

Equipped with 0-59 minute timer for an

even more precise operation

The simple movement of the safety

screen raises and lowers the bowl and

at the same time stops the motor

•

The transparent safety screen can

be easily removed for an accurate

cleaning

Available with accessory hub on

request

Kneading capacity (hook): 3,5 kg of

ﬂour (50% moisture content)

Whisking capacity: 16 eggs

Mixing capacity (paddle): 5 kg of

potatoes or meat

The model with mechanical speed

variation (XBM10) is equipped with

a 2 speed motor. Choose up to 8

different levels for each speed

•

dito electrolux bakery

Planetary mixers 20, 30, 40 litres

XBB 20/30 litre planetary mixers with 3 ﬁxed speeds

(40, 80 and 160 rpm) and electronic variable speed

with 10 levels ranging from 29 to 175 rpm.

Powerful and resistant 1500 W motor

Waterproof touch button control panel with 0-59 min.

timer

Stainless steel wire safety screen protects the operator

and permits ingredients to be added without

stopping the machine

Reinforced column and base for added support and

stability

Supplied with 18/8 stainless steel bowl and 3 tools

(whisk, paddle, spiral hook). Tools rotate at speeds

from 61 to 367 rpm

Splash proof planetary mechanism eliminates the risk

of water entering the system

Wheel kit (optional) for easier movement of mixer

when not in use

•

Wire safety screen Planetary mechanism Removable wheel kitReduction kit with 3 tools

XBB20/30

A wide range of models which offer the best response to the heavy duty

preparations in pastry making.

dito electrolux bakery 7

Removable spout Bowl scraper Bowl trolley

Lever for raising and lowering of

the bowl

Pivoting and removable rotating

safety guard provides protection

for the operator and facilitates

cleaning

A wide range of accessories such

as bowl heating, bowl scraper

and bowl trolley

20 litre bowl reduction kit with 3

tools available as an option

•

model capacity hook* paddle* whisk* notes

BE5 5 litres 2.5 2 16 electronic variator

XBE10 10 litres 5.5 5 30 electronic variator

XBB20 20 litres 11 10 55 electronic variator

XBB30 30 litres 15 15 80 electronic variator

MB40 40 litres 18 20 105 electro-mechanical

MBE40 40 litres 18 20 105 electronic variator

XBE60 60 litres 30 30 130 electronic variator

XBE80 80 litres 40 40 160 electronic variator

*Hook: kg of dough with 50% moisture content

*Paddle: kg of potatoes for puree

*Whisk: max. number of egg whites

Models also available with mechanical speed variation

MB/MBE40

MB/MBE 40 litre planetary mixers specially designed for

bakery and pastry works.

Powerful motor 2200 W with strengthened transmission

and heat treated gearing

MB40 with electromechanical 3 speed selection (40,

80 and 160 rpm), stop button and timer (0-15 min.)

MBE40 with 3 ﬁxed speeds (40, 80 and 160 rpm) and

electronic variable speed with 10 levels ranging from

29 to 175 rpm, stop button and timer (0-59 min.)

Supplied with 18/8 stainless steel bowl and 3 tools

(whisk, paddle spiral hook)

Tools rotate at speeds from 84 to 336 rpm (MB40) and

from 63 to 361 rpm (MBE40)

Kneading: average speed of 40 rpm with hook; Mixing:

average speed of 80 rpm with paddle; Emulsifying:

average speed of 160 rpm with whisk

•

dito electrolux bakery8

LMP 500 table top dough sheeter.

Thanks to its compact size it can be placed on a

table or ﬁtted onto a mobile stand (optional)

The rolling direction can be inverted by the simple

movement of a joystick. Cylinders can be regulated

from 0,1 to 34 mm in thickness allowing all types of

doughs to be worked. Flour container ﬁxed on top

Long lasting structure painted white with chromium

plated steel rollers (60 mm diameter). Slides have a

non-stick surface for easier dough movement and

can be disassembled to save space

All parts in contact with pastry dough are easily

accessible to facilitate cleaning. Removable upper

and lower roller scrapers

Safety microswitch avoids operator injury.

Emergency stop button with lock and manual re-start

ensures the rolling cylinders stop immediately

•

LMP500

Choose from a wide selection of dough sheeters perfect for rolling all types

of lining pastry, doughs and puff pastry work directly on the premises.

Dough sheeters

LMP400

LMP 400 manual hand dough sheeter.

Extremely versatile since it can be placed on a table

and moved easily around the kitchen

The slides can be disassembled to reduce the overall

size of the machine and save space

Steel cylinders (60 mm diameter) with non-stick

coating facilitate the sliding of the dough

The cylinders can be regulated from 0,1 to 34 mm in

thickness and have a working width of 400 mm

The inclined stainless steel ﬂaps are removable for

easier cleaning

•

dito electrolux bakery 9

LMP 500 BT (1 speed) table top belt

dough sheeter.

Versatility in the preparation of all

types of pastry with a working width

of 500 mm and two working belts of

1000 mm in length

Slides can be raised for optimum

space saving and cleaning

The ﬂour container is ﬁxed on the top

to continue dough preparation without

stopping the machine

The ergonomic controls are closely

situated to suit natural movements

•

Cutting module Foot pedal

LMP500BT

LMP600BF

LMP500BF

LMP 500 BF (1 speed or variable

speeds) mobile ﬂoor standing belt dough

sheeter.

Sturdy base for optimum support in a

white painted ﬁnish to last longer

Chromium plated steel cylinders (60

mm diam.) with a 500 mm working

width and 2 working belts 1000 mm

in length

Invert rolling direction by means of

a joystick

Emergency stop button with lock

and manual re-start ensure operator

safety

•

LMP 600 BF (2 speeds) mobile ﬂoor standing belt

dough sheeter.

The chromium plated steel rollers (71,5 mm diam.)

have a working width of 600 mm and a belt length

of 1300 mm

Operator safety is guaranteed by a microswitch

which controls the gratings and stops the motor if they

exceed a certain level

Croissants made easy thanks to the optional cutting

module 130x140 mm

Easily invert the rolling

direction thanks to the

optional remote foot

pedal (excl. LMP400)

•

dito electrolux bakery

BPO 25/40 litre fork kneaders ideal for preparing specialty breads,

pizza doughs and Viennese pastries.

2 speed motor for optimum kneading quality: slow speed (45 rpm)

for traditional kneading and 2nd speed (90 rpm) for fast kneading

User friendly touch button control panel incorporates a timer (0-59

min.) for precise control

Welded base for added support and stability of the kneading head

and removable aluminium bowl with progressive action brakes for

perfect regulation of rotation speed

Operator safety assured thanks to the particular head raising and

instantaneous locking system

Maximum hygiene thanks to the transparent screen which allows

products to be added during operation and avoids the emission of

ﬂour into the work area

Safety guaranteed, the machine will not start if the bowl is not

correctly placed on the base

•

ZSP 12 to 49 litre spiral kneaders have all of the characteristics to

create a perfect mixture every time.

Sturdy and reliable construction in painted steel

When screen is raised the motor automatically stops, guaranteeing

operator safety

High capacity stainless steel bowl with rounded bottom facilitates

cleaning

Extremely resistant stainless steel mixing arm

Optimum speed and reliability thanks to the carefully designed

power system

•

BPO

ZSP

Dough kneaders

An indispensable asset, Dito Electrolux dough kneaders are the best choice

for professional bakeries and pizzerias.

model capacity power speeds note

BPO25/45 25/40 lt 750 W 2 fork kneaders

ZSP10 12 lt 550 W 1

spiral kneaders

ZSP20 25 lt 750 W 1

ZSP25 32 lt 750 W 1

ZSP30 38 lt 1100 W 1

ZSP40 49 lt 1100 W 1

** 50/100 litre spiral kneaders available on request

Questo manuale è adatto per i seguenti modelli

Altri manuali Electrolux Elettrodomestico da cucina

Electrolux

Electrolux CSIG 501 Manuale utente

Electrolux

Electrolux EKI6762AOX Manuale utente

Electrolux

Electrolux 7000 Manuale utente

Electrolux

Electrolux 300 Series Manuale utente

Electrolux

Electrolux EKC603602 Manuale utente

Electrolux

Electrolux EEA4545POX Manuale utente

Electrolux

Electrolux Dito 601579 Manuale utente

Electrolux

Electrolux Boiling pan Smart Manuale utente

Electrolux

Electrolux EKM51302OX Manuale utente

Electrolux

Electrolux thermaline S90 Manuale utente

Electrolux

Electrolux EKC603601X Manuale utente

Electrolux

Electrolux EKM61301OX Manuale utente

Electrolux

Electrolux 720008 Manuale utente

Electrolux

Electrolux ERW0673AOA Manuale utente

Electrolux

Electrolux thermaline S90 Manuale utente

Electrolux

Electrolux EKG6120AOK Manuale utente

Electrolux

Electrolux DTC50GA Manuale utente

Electrolux

Electrolux ESTM6 Series Manuale utente

Electrolux

Electrolux ICON appliances Guida

Electrolux

Electrolux EKE 5001 Manuale utente

Electrolux

Electrolux EKM11440CN Manuale utente

Electrolux

Electrolux EQT4520BOZ Manuale utente

Electrolux

Electrolux EKC 6702 Manuale utente

Electrolux

Electrolux EK 170 (S) Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
