Electrolux FM4863-WKA Manuale utente

FM4863WKA

User manual Induction wok

Dear Customer

Thank you for choosing one of our high-quality products.

With this appliance you will experience the perfect combination of

functional design and cutting edge technology.

Convince yourself that our appliances are engineered to deliver the

best performance and control - indeed we are setting the highest

standards of excellence.

In addition to this you find environmental and energy saving aspects as

an integral part of our products.

To ensure optimal and regular performance of your appliance please

read this instruction manual carefully. It will enable you to navigate all

processes perfectly and most efficiently.

To refer to this manual any time you need to, we recommend you to

keep it in a safe place. And please pass it to any future owner of the ap-

pliance.

We wish you much joy with your new appliance.

The following symbols are used in this user manual:

Important information concerning your personal safety and information

on how to avoid damaging the appliance.

3General information and tips

2Environmental information

3Contents

Contents

Operating Instructions 4

Safety instructions 4

Description of the Appliance 6

Cooking surface layout 6

Control panel layout 6

Touch Control sensor fields 7

Displays 7

Residual heat indicator 8

Accessories 8

Operating the appliance 9

Switching the appliance on and off 9

Setting the heat setting 9

Switching the power function on and off 9

Using the child safety device 10

Using the timer 11

Safety cutout 13

Tips for cooking with the wok 14

Cookware for induction cooking zones 15

Methods of preparation in the wok 16

Cleaning and Care 17

What to do if … 18

Disposal 20

Installation Instructions 21

Assembly 23

Installing more than one Frontline hob 25

Rating Plate 29

Guarantee/Customer Service 30

Service and Spare Parts 34

Operating Instructions

1Safety instructions

3Please comply with these instructions. If you do not, any damage re-

sulting is not covered by the warranty.

5This appliance conforms with the following EU Directives:

–73/23/EEC dated 19.02.1973 Low Voltage Directive

–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending

Directive 92/31/EEC

–93/68/EEC dated 22.07.1993 CE Marking Directive

Correct use

•This appliance should be used only for normal domestic cooking and

frying of food.

•The appliance must not be used as a work surface or as a storage sur-

face.

•Additions or modifications to the appliance are not permitted.

•Do not place or store flammable liquids, highly inflammable materials

or fusible objects (e.g. plastic film, plastic, aluminium) on or near the

appliance.

Children’s safety

•Small children must be kept away from the appliance.

•Only let bigger children work on the appliance under supervision.

•To avoid small children and pets unintentionally switching the appli-

ance on, we recommend activation of the child safety device.

General safety

•The appliance may only be installed and connected by trained, regis-

tered service engineers.

•Built-in appliances may only be used after they have built in to suita-

ble built-in units and work surfaces that meet standards.

•In the event of faults with the appliance or damage to the glass ce-

ramic (cracks, scratches or splits), the appliance must be switched off

and disconnected from the electrical supply, to prevent the possibility

of an electric shock.

•Repairs to the appliance must only be carried out by trained regis-

tered service engineers.

Safety during use

•Overheated fats and oils can ignite very quickly. When cooking with

fat or oil (e.g. chips) do not leave the appliance unattended.

•Risk of burns! Fat or oil added to a pan which has already been heat-

ed ignites very quickly and can spit.

•There is the risk of burns from the appliance if used carelessly.

•Remove stickers and film from the glass ceramic.

•Cables from electrical appliances must not touch the hot surface of

the appliance or hot cookware.

•Switch cooking zone off after every use.

•Users with implanted pacemakers should keep their upper body at

least 30 cm from induction cooking zones that are switched on.

•Risk of burns! Do not place objects made of metal, such as knives,

forks, spoons and saucepan lids on the cooking surface, as they can

get hot.

•Risk of fire! Do not place any paper, cardboard, cloth, etc. between

glass ceramic niche and wok pan.

Safety when cleaning

•For cleaning, the appliance must be switched off and cooled down.

•For safety reasons, the cleaning of the appliance with steam jet or

high-pressure cleaning equipment is not permitted.

How to avoid damage to the appliance

•The glass ceramic can be damaged by objects falling onto it.

•The edge of the glass ceramic can be damaged by being knocked by

the cookware.

•Objects that melt and things that boil over can burn onto the glass

ceramic and should be removed straightaway.

•Do not use cooking zone with empty cookware or without cookware.

•The ventilation gap of 5mm between the worktop and front of the

unit underneath it must not be covered.

Description of the Appliance

Cooking surface layout

Control panel layout

300 mm

Wok niche 2300W

with power function

3200W

Frontline strip

Control panel

Child lock pilot

light

Heat setting

indicator

Heat setting

indicator

Child lock

Heat setting 6 /

power function

Heat setting selection

Timer indicator

Timer selection

On/Off pilot

light

On/Off

Timer

Touch Control sensor fields

The appliance is operated using Touch Control sensor fields. Functions

are controlled by touching sensor fields.

Touch the sensor fields from above, without covering other sensor

fields.

Displays

Sensor field Function

On / Off To switch the appliance on and

off

Increase settings To increase heat settings

Reduce settings To reduce heat settings

Timer Timer selection

Increase settings To increase Timer time

Reduce settings To reduce Timer time

Child lock Locking control panel for children

Power Switching the power function on

and off

Heat setting 6 Set heat setting 6 immediately

Display Description

Cooking zone is switched off

Keep warm setting Keep warm setting is set

- Heat settings Heat setting is set

Fault Malfunction has occurred

Pan detection Cookware is unsuitable or too

small or no cookware has been

placed on the cooking zone

Residual heat Cooking zone is still hot

Child safety device Child safety device is engaged

Power Power function is switched on

Safety cut-out Safety cut-out has been activated

Residual heat indicator

1Warning! Risk of burns from residual heat. After being switched off,

the cooking zones need some time to cool down. Look at the residual

heat indicator .

3Residual heat can be used for melting and keeping food warm.

Accessories

Wok pan (supplied)

•390 mm, 6 litres

•With 2 handles

•WOK P 6.0 stainless steel

Operating the appliance

3Only use a wok pan that is suited to this appliance.

Switching the appliance on and off

3After switching on, within approx. 10 seconds a heat setting or a func-

tion must be set, otherwise the appliance automatically switches itself

off.

Setting the heat setting

Switching the power function on and off

The power function makes more power available to the induction

cooking zones, e.g. to bring a large quantity of water to the boil quick-

ly.

The power function is activated for 10 minutes. After that the induc-

tion cooking zone automatically switches back to heat setting 9.

Control panel Display Pilot light

To switch on touch for 2 seconds / lights up

To switch off touch for 2 seconds / none goes out

Control panel Indicator

To increase Touch to

To decrease Touch to

To switch off Touch and at the same time

Control panel Display left Display right

To switch on Touch

To switch off Touch goes out 9

Touch goes out 9

Using the child safety device

The child safety device prevents unintentional use of the appliance.

Switching on the child safety device

Deactivating the child safety device

Overriding the child safety device

The child safety device can be released in this way for a single cooking

session; it remains activated afterwards.

Step Control panel Display/Signal

1. Switch on appliance. (Do not

set a heat setting.)

2. Touch for 3 seconds

Appliance switches off. The child safety device is switched on

Step Control panel Display/Signal

1. Switch appliance on

2. Touch for 3 seconds 0lights up

Appliance switches off. The child safety device is switched off.

Step Control panel Display/Signal

1. Switch on the appliance

2. Touch and at the same time / acoustic signal

Until the appliance is next switched off, it can used as normal.
