Frigidaire AFFC1526DW Manuale utente

Product No. AFFC1526DW0

Series 134A

Color white

Volts 115

Wiring Diagram 216908200

Owner's Guide 216960000

Market North America

Energy Guide 216794206

P08F0060.eps P08D0405.eps P08C0646.eps P08S0343.eps

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995417440

04/09/29

(EN/SERVICE/MLR)

365

FREEZER CHEST

Model No.

AFFC1526DW

Publication No: 5995417440 AFFC1526DW0

09/04 2

DOOR

P08D0405

AFFC1526DW0 Publication No: 5995417440

# Functional Parts 3 09/04

* Non-Illustrated Parts

DOOR

POS. NO PART NO. DESCRIPTION

1 216481201 Gasket-door, white

2 5303925107 Lock Assy

* 5303313518 Washer, sealing

5 # 216702900 Key, lock

9 216829104 Panel-lid

10 216923001 Plug button, 1/4", white

11 216129932 Lid, white

* 5303161215 Screw, ph truss head, 8-18AB x 0.500

14 216822900 Switch, light/lamp, ramp

15 216846400 Light Bulb/Lamp

16 216817600 Socket, light/lamp, 25 W

18 216897600 Handle, white

23 216212700 Light-signal, amber

27 5303212828 Clip, panel mtg

34 5303296969 Shield, lid lamp

40 216922700 Fastener, .330 dia stud, handle, (2)

47 # 216908000 Harness-lid

57 216899508 Overlay

* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995417440 AFFC1526DW0

09/04 4

CABINET

AFFC1526DW0 Publication No: 5995417440

# Functional Parts 5 09/04

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

1 216909800 Catch-lock, white

1A 216818900 Support, lock catch clip

3 216502600 Plug, drain, interior

4 216073905 Plug-drain, exterior

6 216111000 Breaker, Plain, white

7 216111600 Breaker, lock side

11 216110800 Breaker, chest end, (2)

18 216707200 Knob, temp control

21# 216714601 Control temperature

27 216629600 Screw, hex washer head, 10-16 x 0.500, tapping

28 216035200 Hinge

30 216110700 Breaker, corners

59 216916201 Basket, blue, upper, (2)

59A 216867401 Basket, blue, lower, (2)

62A 131420300 Screw, cr truss head, 8-18AB x 0.750

75 216034301 Panel, access, white

93 5303161215 Screw, ph truss head, 8-18AB x 0.500

100 216654400 Track-basket

* 5303305324 Paint, touch-up, white

* 216794206 Energy Guide

Publication No: 5995417440 AFFC1526DW0

09/04 6

SYSTEM

AFFC1526DW0 Publication No: 5995417440

# Functional Parts 7 09/04

* Non-Illustrated Parts

SYSTEM

POS. NO PART NO. DESCRIPTION

1 # 5303925238 Condenser

4 216634500 Drier-filter

5 # 216906200 Harness-main

22 216056400 Clip, compressor mtg, SPRING

27 5308002681 Grommet, compressor

28 5303212615 Support, compressor

29 # 216888100 Compressor, w/o electricals

30 216596800 Starter, relay

31 # 216100106 Overload Protector

42 216232700 Washer, flat, 1"OD x 0.531"ID

43 5303212614 Clip, harness mount

47 216629600 Screw, hex washer head, 10-16 x 0.500, tapping

53 216347800 Cover terminal, cover-comp term

86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
