Frigidaire FFC18C8CB Manuale utente

CHEST FREEZER

Base Model:

FFC18C8CB

FACTORY PARTS CATALOG

FREEZER

WIRING DIAGRAM - # 216801000

OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216794306

SERVICE DATA SHEET - # 216801000

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FFC18C8CB0 FFC18C8CB 134A black 115

MARKET

North America

Publication No.

5995393252

030728

-EN/SERVICE /MLR

365

ELECTROLUX HOME PRODUCTS, INC.

P.O BOX 212378, AUGUSTA , GA 30917

07/03 2

Publication No FFC18C8CB0

5995393252

DOOR

# = Fast-moving Parts 3 07/03

* = Non-Illustrated Parts

FFC18C8CB0 Publication No.

5995393252

DOOR

POS. NO PART NO DESCRIPTION

1 216481304 Gasket-door,black

2 5303925107 Lock Assy

5 # 216702900 Key,lock

9 216893202 Panel-inner door\lid,white

10 216141100 Plug-foam hole,black

11 216130021 Panel-outer door\lid,black

14 216822900 Switch,light/lamp ,ramp

15 216846400 Light Bulb/Lamp

16 216817600 Socket,light/lamp ,25 W

18 216897601 Handle,black

27 5303212828 Clip,panel mtg

34 216578502 Shield,light

40 5309948647 Fastener,handle

47 # 216889600 Harness-lid

57 216899501 Overlay,black

79 # 216898700 Control Board,electronic

* 216905300 Screw,control board ,#3-24 x .25

* 5303917276 Insulation-door,fiberglass ,(bulk)

07/03 4

Publication No FFC18C8CB0

5995393252

CABINET

# = Fast-moving Parts 5 07/03

* = Non-Illustrated Parts

FFC18C8CB0 Publication No.

5995393252

POS. NO PART NO DESCRIPTION

1 216909801 Catch-lock,black

1A 216818900 Support,lock catch clip

3 216502600 Plug,drain ,interior

4 216073906 Plug-drain,black ,exterior

6 216111105 Breaker,black ,hinge side

7 216111705 Breaker-lock side,black

11 216110805 Breaker,black ,ends

18 216873600 Knob-control

21 # 216844500 Control-temperature

27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping

28 216035302 Hinge-assy,black

30 216110705 Breaker,black ,corners

59 216916200 Basket,upper ,(2)

59A 216867400 Basket,lower ,(2)

62A 131420300 Screw,cr truss head ,8-18AB x 0.750

75 216034303 Panel-access,black

93 5303161215 Screw,ph truss head ,8-18AB x 0.500

100 216205102 Track-basket

* 216794306 Energy Guide

CABINET

07/03 6

Publication No FFC18C8CB0

5995393252

SYSTEM

# = Fast-moving Parts 7 07/03

* = Non-Illustrated Parts

FFC18C8CB0 Publication No.

5995393252

SYSTEM

POS. NO PART NO DESCRIPTION

1 # 5303280307 Condenser

4 216634500 Drier-filter

5 # 216890300 Harness-main

5 * 216890200 Harness,low voltage- ,w/thermistor

22 216056400 Clip,compressor mtg ,SPRING

27 5308002681 Grommet,compressor

28 5303212615 Support,compressor

29 # 216784500 Compressor,w/o electricals

30 216649300 Controller-regulator LP

32 216649100 Clamp,elec cont mtg ,compressor

42 216232700 Washer,flat ,1"OD x 0.531"ID

43A 5303212614 Clip,harness mount

47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping

55 # 218909913 Capacitor-run,220 VAC ,15 microfarad

78 216893100 Assy-High Voltage

86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming

* 5303298960 Spacer-tube,0.237" ID
