TPD-703/TPD-703-64 7" Touch Screen Controller - QuickStart (Apr/2020)

ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717 1

TPD-703/TPD-703-64

7" Touch Screen Controller

Quick Start

What’s in the box?

Thanks for buying ICPDAS TPD-703/703-64 device. This shipping

package contains the following items:

Quick Start x 1

TPD-703/703-64 x 1

(This Document)

Stylus x 1

Related Information

Documents, such as the User Manuals, the API References,

etc.: https://www.icpdas-usa.com/tpd_703.html

https://www.icpdas-usa.com/tpd_703_64.html

Free Development Software, HMIWorks:

https://www.icpdas-usa.com/hmiworks.php

If you have any questions, please feel free to contact us via email.

TPD-703/TPD-703-64 7" Touch Screen Controller - QuickStart (Apr/2020)

ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717 2

1Appearance

Front View

Rear View

7” TFT LCD with

Reset Button

Ethernet

Touch Panel

Buzzer LED Rotary Switch Serial Port Indicator

2Pin Assignments

On the back of the TPD-703(-64)

Description

F.G.

Frame Ground. F.G. is connected to the inside EMI or

ESD suppression circuits. Make sure that F.G. is

connected to the Earth

P.GND

Connected to the power supply’s ground pin

PWR

DC input Voltage (range: +12 V ~ +48 V)

The pin of transmitted data of the RS-232

The pin of received data of the RS-232

GND

Ground pin

D+

The positive data line of the RS-485 network

D-

The negative data line of the RS-485 network

Technical support: s[email protected]om P2

TPD-703/TPD-703-64 7" Touch Screen Controller - QuickStart (Apr/2020)

ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717 3

3 Rotary Switch & Default Settings

The definition of the rotary switch:

Mode

Description

Run &

This is a special run mode which is used in

the development stage. The TouchPAD

Update

device can be updated by a PC from the

remote side through Ethernet. (Default)

While the application run on the TouchPAD

Force

device seriously crashes, use this mode to

Update

update a new application to the TouchPAD

device through Ethernet.

Run Only

Run the program.

Network Default Settings

IP Address

192.168.255.1

Subnet Mask

255.255.0.0

Gateway

192.168.0.1

4 First Use of the TPD-703(-64)

1. Connect wires as the below figure or prepare an Ethernet cable

which will be used to supply power through PoE if there’s a RJ-45

Ethernet port on it. And set the rotary switch to 0 (At this point, the

power is not yet supplied).

TPD-703/TPD-703-64 7" Touch Screen Controller - QuickStart (Apr/2020)

ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717 4

2. Supply power to the TPD-703(-64), wait

for several seconds and then you can see

the default program run on it.

3. Try to touch on the icons on the bottom-right corner of the screen

of the TPD-703(-64) and you can find that TPD-703(-64) switches to

the setting pages.

5Hardware Installation

External Wall Box, EWB-T70 (optional) Outlet Box, OB170 (optional)
