KitchenAid EPS-10 Manuale utente

This attachment has been approved for use with

all KitchenAid®household stand mixers

RVSA

KitchenAid

St. Joseph, Michigan USA

Off Stir 2 4 6 8 10

Solid State Speed Control

ROTOR SLICER/SHREDDER

arb

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put mixer in water or other

liquid.

3. Close supervision is necessary when any appliance is used near children.

4. Unplug from outlet when not in use, before putting on or taking off parts,

and before cleaning.

5. Avoid contacting moving parts. Keep fingers out of discharge opening.

6. Do not operate the mixer with a damaged cord or plug or after the mixer

malfunctions, or is dropped or damaged in any manner. Return the mixer

to the nearest Authorized Service Center for examination, repair or

electrical or mechanical adjustment.

7. The use of attachments not recommended or sold by KitchenAid may cause

fire, electric shock or injury.

8. Do not use the mixer outdoors.

9. Do not let the cord hang over the edge of table or counter.

10. Never feed food by hand. Always use food pusher.

11. Blades are sharp. Handle carefully.

12. This product is designed for household use only.

SAVE THESE INSTRUCTIONS

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on

your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and

others.

All safety messages will be preceded by the safety alert symbol

and the word “DANGER” or “WARNING.” These words mean:

You will be killed or seriously injured

if you don’t follow instructions.

You can be killed or seriously injured

if you don’t follow instructions.

All safety messages will identify the hazard, tell you how to reduce the chance

of injury, and tell you what can happen if the instructions are not followed.

WARNING

DANGER

TO ATTACH:

Before attaching accessory, turn off

and unplug unit.

Loosen attachment knob (1) by turn-

ing it counterclockwise. Remove

attachment hub cover. Insert attach-

ment shaft housing (2) into attachment

hub (3) making certain that attach-

ment power shaft fits into square hub

socket. Rotate attachment back and

forth if necessary. When attachment

is in proper position, the pin on the

attachment will fit into the notch on

the hub rim. Tighten attachment knob

until attachment is completely

secured to mixer.

arb

231

TO ASSEMBLE:

Attach shaft (A) to desired cone (B).

Insert square end of shaft in square

opening of housing and tighten by

turning cone clockwise. Reverse to

remove. Insert the cone assembly into

housing (C) so shaft fits into square

hub socket. As you insert the cone

assembly, lift up on the latch (D) and

turn the cone assembly until it fits

squarely in the attachment hub.

Food Pusher

Housing

Shaft Fine Shredder

Coarse Shredder

Thick Slicer

Thin Slicer

No. 2 Coarse Shredder —

Coarsely shreds carrots, celery,

onions, fruits, nuts or chocolate.

Potatoes can be shredded for shoe-

strings or hash browns.

No. 3 Thick Slicer — Gives a thick

slice for firm foods. Perfect for veg-

etables that are to be steamed, fried,

scalloped or creamed.

No. 4 Thin Slicer — Thinly slices

vegetables for cole slaw, potato chips,

sauerkraut, bread and butter pickles,

sliced cucumbers, radishes, celery

and nuts.

TO CHANGE CONES:

The latch must be raised to remove

cone unit. Cones may be easily

changed by inserting square end of

shaft in square opening and turning

counterclockwise.

TO CLEAN:

The Slicer/Shredder housing and

cones are dishwasher safe. Some foods

such as carrots may stain the housing.

These stains may be removed by using

one of the following methods: (1) place

in dishwasher and use cycle for nor-

mally soiled dishes, or (2) rub a small

amount of oil or shortening over the

stains, wash in warm sudsy water and

rinse.

Lower the latch and pull on the cone

assembly to make sure it is locked in

place. To disassemble, reverse the

assembly process.

TO USE:

To use Slicer/Shredder, lift the han-

dles of the food pusher and place food

in the hopper. Turn to Speed 4 and

push down on handles. If slicing or

shredding single items like celery, one

half of the hopper may be used by

lifting only one handle for adding

food. Catch the food in a deep bowl.

CONES AND THEIR USES:

All cones are numbered on the closed

end. Replacement cones should be

ordered by number.

No. 1 Fine Shredder — Finely

shreds hard and crisp vegetables,

such as carrots, beets, turnips, pota-

toes, celery, nuts, firm cold cheese,

coconut and dry bread.

arb

Rotating Blade Hazard

Always use food

pusher.

Keep fingers out of

openings.

Keep away from

children.

Failure to do so can

result in amputation

or cuts.

WARNING

TERIYAKI VEGETABLE SAUTÉ

a~b

QQQQQQQQQQ s QQQQQQQQQQ

4 medium carrots, peeled

and cut into thirds

1 medium red or green

bell pepper, cut into

fourths

1 medium red or yellow

onion, cut into fourths

1 tablespoon oil

⁄

teaspoon red pepper

flakes

1 teaspoon sugar

1 teaspoon cornstarch

⁄

teaspoon ginger

⁄

cup reduced-sodium

chicken broth

2 tablespoons reduced-

sodium soy sauce

Assemble Rotor Slicer/Shredder, using thick

slicing cone (No. 3). Attach Rotor Slicer/Shredder

to mixer. Turn to Speed 4 and slice carrots into

large bowl placed under slicer/shredder. Repeat

with bell pepper and onion.

Heat oil in large skillet over medium-high heat

until oil sizzles. Add vegetables and red pepper

flakes. Cook and stir 4 to 5 minutes, or until

vegetables are crisp-tender.

Combine all remaining ingredients in a small

bowl. Add to mixture in skillet all at once. Cook

and stir until mixture is thickened and vegetables

are coated with sauce.

Yield: 4 to 6 servings.

Per serving: About 94 cal, 2 g pro, 13 g carb,

4 g fat, 0 mg chol, 342 mg sod.

4 medium carrots, cut

into thirds

⁄

cups all-purpose flour

1 cup whole wheat flour

⁄

cups sugar

2 teaspoons baking soda

⁄

teaspoon salt

⁄

teaspoon nutmeg

⁄

cup oil

1 can (8 oz.) crushed

pineapple in juice,

undrained

3 eggs

1 teaspoon vanilla

⁄

cup flaked coconut

Orange Cream Cheese

Frosting, if desired

(see page 7)

Assemble Rotor Slicer/Shredder, using fine

shredding cone (No. 1). Attach Rotor Slicer/

Shredder to mixer. Turn to Speed 4 and shred

carrots into large bowl placed under slicer/

shredder. Set aside.

Combine all-purpose flour, whole wheat flour,

sugar, baking soda, salt, and nutmeg in mixer

bowl. Add oil, pineapple, eggs, and vanilla.

Attach bowl and flat beater to mixer. Turn to

Speed 2 and mix about 1 minute. Stop and scrape

bowl. Turn to Speed 4 and beat about 30 seconds.

Turn to Stir Speed and add coconut and carrots,

mixing just until blended.

Pour batter into greased and floured 13x9x2-inch

baking pan. Bake at 350°F for 30 to 35 minutes,

or until toothpick inserted in center comes out

clean. Cool completely on wire rack. Frost with

Orange Cream Cheese Frosting, if desired.

Yield: 12 to 16 servings.

Per serving: About 330 cal, 5 g pro, 51 g carb,

13 g fat, 53 mg chol, 343 mg sod.

CARROT-COCONUT CAKE

QQQQQQQQQQ s QQQQQQQQQQ

a~b

4 cups powdered sugar

1 package (8 oz.) light

cream cheese

1 teaspoon orange juice

⁄

teaspoon grated

orange peel

Place all ingredients in mixer bowl. Attach bowl

and flat beater to mixer. Turn to Stir Speed and

mix about 30 seconds, or until blended. Turn to

Speed 4 and beat about 2 minutes, or until

smooth and creamy.

Yield: 12 to 16 servings (frosting for 2-layer or

13x9x2-inch cake).

Per serving: About 196 cal, 2 g pro, 41 g carb,

3 g fat, 7 mg chol, 107 mg sod.

ORANGE CREAM CHEESE FROSTING

QQQQQQQQQQ s QQQQQQQQQQ

a~b

9704313 Printed in U.S.A.

dZw(1297)

Length of

Warranty:

One Year Full warranty

from date of purchase.

KitchenAid

Will Pay For:

Replacement parts and

repair labor costs to correct

defects in materials or

workmanship. Service must

be provided by an

Authorized KitchenAid

Service Center.

Total Replacement

Warranty.

KitchenAid

Will Not Pay For:

A.Repairs when

attachment/accessory is

used in other than nor-

mal home use.

B. Damage resulting from

accident, alteration,

misuse or abuse.

C. Any incidental

shipping or handling

costs to deliver your

attachment/accessory to

an Authorized

KitchenAid Service

Center.

D.Replacement parts or

repair labor costs for

attachments/accessories

operated outside the

United States.

KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the

exclusion or limitation of incidental or consequential damages, so this exclusion or limita-

tion may not apply to you. This warranty gives you specific legal rights and you may also

have other rights which vary from state to state.

HOW TO ARRANGE FOR SERVICE

To arrange for service, call the KitchenAid Customer Satisfaction Center, toll-free at

1-800-541-6390.

Missing a part? Call 1-800-541-6390 for immediate handling of your problem.

WARRANTY

St. Joseph, Michigan 49085 U.S.A

®KITCHENAID is a registered trademark of KitchenAid, U.S.A.

We’re so confident the quality of our prod-

ucts meets the exacting standards of

KitchenAid that, if your attachment/acces-

sory should fail within the first year of own-

ership, KitchenAid will arrange to deliver a

replacement attachment/accessory to your

door free of charge and arrange to have

your “failed” attachment/accessory returned

to us. Your replacement unit is covered by

our one year full warranty. Please follow

these instructions to receive this quality

service.

If you reside in the United States and

your KitchenAid attachment/accessory

should fail within the first year of owner-

ship, simply call our toll-free Customer

Satisfaction Center at 1-800-541-6390.

Give the consultant your complete shipping

address. (No P.O. Box Numbers, please.)

KitchenAid will arrange to deliver a

replacement attachment/accessory and have

your “failed” attachment/accessory returned

to us.

Put your “failed” attachment/accessory in

the original shipping carton along with a

sheet of paper with your name and address

on it, and proof of purchase (register

receipt, credit card charge slip, etc.)

TOTAL REPLACEMENT WARRANTY

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali KitchenAid Elettrodomestico da cucina

KitchenAid

KitchenAid KESMK4 Manuale utente

KitchenAid

KitchenAid 5KSMFGAG Manuale utente

KitchenAid

KitchenAid KSMSFTA Manuale utente

KitchenAid

KitchenAid KSS3121 Manuale utente

KitchenAid

KitchenAid 5KSM5SSB Manuale utente

KitchenAid

KitchenAid KHBC308OB Manuale utente

KitchenAid

KitchenAid 5KSM7990 Manuale utente

KitchenAid

KitchenAid KEC50C Manuale utente

KitchenAid

KitchenAid 5KCF0201A Manuale utente

KitchenAid

KitchenAid KSM2CB5 Manuale utente

KitchenAid

KitchenAid KPCA Guida rapida

KitchenAid

KitchenAid Mockmill Manuale utente

KitchenAid

KitchenAid KESMK5 Manuale utente

KitchenAid

KitchenAid 5KSMSFTA Manuale utente

KitchenAid

KitchenAid KSMVSA Manuale utente

KitchenAid

KitchenAid KJG02A Series Manuale utente

KitchenAid

KitchenAid SAUSAGE STUFFER Manuale utente

KitchenAid

KitchenAid KMC4241 Istruzioni per il montaggio

KitchenAid

KitchenAid KSMMGA Manuale utente

KitchenAid

KitchenAid 5KGM Manuale utente

KitchenAid

KitchenAid KSM2APC Manuale utente

KitchenAid

KitchenAid KI422BBONA Manuale utente

KitchenAid

KitchenAid 5KSMSFTA Manuale utente

KitchenAid

KitchenAid KSS1121 Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
