Lantech IES-2008 Manuale utente
8 10/100TX with X-Ring Management
Industrial Switch
IES-2008
User Manual
Notice:
This manual contents are based on the below table listing software
kernel version, hardware version, and firmware version. If the switch
functions have any different from the manual contents description,
please contact the local sale dealer for more information.
Firmware Version V1.06
Kernel Version V1.00
Hardware Version A5.00
FCC Warning
This Equipment has been tested and found to comply with the limits for a
Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
Content
Introduction................................................................1
Features ...................................................................1
Package Contents....................................................2
Hardware Description................................................3
Physical Dimension..................................................3
Front Panel...............................................................3
Reset Button......................................................................4
Bottom View .............................................................4
DIP-switch ................................................................4
LED Indicators..........................................................6
Ports.........................................................................7
Cabling .....................................................................9
Wiring the Power Inputs .........................................10
Wiring the Fault Alarm Contact ..............................10
Wiring the Fault Alarm Contact ..............................11
Mounting Installation...............................................12
DIN-Rail Mounting..................................................12
Wall Mount Plate Mounting ....................................14
Hardware Installation...............................................15
Network Application ................................................16
Redundant ring Application....................................16
Coupling Ring Application......................................17
Dual Homing Application........................................18
Web-Based Management ........................................19
About Web-based Management.............................19
Preparing for Web Management............................19
System Login..........................................................20
Port status ..............................................................21
Port Statistics .........................................................22
Port Control ............................................................23
Switch Settings.......................................................23
Port Mirroring..........................................................24
VLAN configuration ................................................25
Alert........................................................................32
Email Alert Configuration .................................................32
Event Configuration .........................................................33
Power Alarm Configuration..............................................35
IP Configuration......................................................35
SNTP Configuration ...............................................36
IP Security..............................................................39
RSTP Configuration ...............................................40
Redundant ring.......................................................44
QoS Configuration..................................................46
IGMP ......................................................................48
SNMP Configuration...............................................49
Security Manager ...................................................51
Configuration Backup.............................................52
TFTP Update Firmware..........................................53
Factory Default.......................................................54
System Reboot.......................................................55
Save Configuration.................................................54
Rate Control ...........................................................55
System Log ............................................................56
Troubles shooting....................................................59
Technical Specification...........................................60
1
Introduction
The 8 10/100TX with redundant ring Web management industrial switch is a
cost- effective solution and meets the high reliability requirements demanded
by industrial applications. The 8 10/100TX with redundant ring Web
management industrial switch can be easily managed through the Web GUI. It
also provides the redundant ring function that can prevent the network
connection failure.
Features
Conform to IEEE 802.3 10Base-T, 802.3u 100Base-TX
8-port 10/100TX industrial switch
RJ-45 port support auto MDI/MDI-X function
Wide-range redundant power design
DIN rail and wall mount design
Easy configuration design
Store-and-Forward switching architecture
Support IEEE 802.1p class of service and provide port base, Tag base and
Type of service priority method
Per port supports 4 priority queues
Support Port based VLAN / 802.1 Q Tag VLAN
Support IGMP with Query mode for multi media application
Support DHCP client
Supports ingress packet filter and egress rate limit
Support Relay alarm output for system events
Support Power polarity reverse protect
Support Port mirror for TX only, TX and RX packet
IEEE 802.3x flow control support
¾Flow control on full-duplex
¾Back pressure on half-duplex
Support Redundant ring function
2
Simple Network Time protocol supported
Management IP security
TFTP firmware update and system configuration restore and backup
1Mbits Embedded memory
2K MAC address table
SNMP, Web management, RMON supported
Package Contents
Please refer to the package content list below to verify them against the
checklist.
8 10/100TX with redundant ring Web management industrial switch
One DIN-Rail (attached on the switch)
One wall mount plate and six screws
User manual
8 10/100TX with redundant ring Web management User Manual
industrial switch
WallMountPlate Screws DIN-Rail
Compare the contents of your industrial switch with the standard checklist
above. If any item is damaged or missing, please contact the local dealer for
exchanging.
3
Hardware Description
In this paragraph, we will introduce the Industrial switch’s hardware spec, port,
cabling information, and wiring installation.
Physical Dimension
8 10/100TX with redundant ring Web management industrial switch dimension
(W x H x D) is 54mm x 135mm x 105mm
Front Panel
The Front Panel of the 8 10/100TX with redundant ring Web management
industrial switch is showed as following figure.
Front Panel of the industrial switch
4
Reset Button
The reset button provides user a quick and easy way to restart and set the
configuration back to default value.
Restart: press the button for 2 seconds and release.
Set to factory default value: press the button for 5 seconds and release.
The switch will set all configurations back to default setting.
Bottom View
The bottom panel of the 8 10/100TX with redundant ring Web management
industrial switch consists one terminal block connector within two DC power
inputs and one DC IN power jack.
Bottom Panel of the industrial switch
DIP-switch
The switch provides the 9 DIP-switch for configuring the relay alarm operation
mode and the ring master operation mode. The default value of Dipswitch is
OFF.
