Lenovo IdeaCentre D400 Manuale del proprietario

Lenovo

IdeaCentre D400 Series

Hardware Maintenance Manual

Chapter 1. About this manual .................................................1

Important safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Using eSupport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important information about replacing RoHS compliant FRUs . . . . . . . . 2

Chapter 2. Safety information .................................................5

General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Safety inspection guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Handling electrostatic discharge-sensitive devices . . . . . . . . . . . . . . . . . 9

Grounding requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Safety notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Chapter 3. General information ............................................13

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Chapter 4. General checkout ................................................15

Checkout procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Problem determination tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Chapter 5. Using the Setup Utility .........................................21

Starting the Setup Utility program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Selecting a startup device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Exiting from the Setup Utility program . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Chapter 6. Symptom-to-FRU index ......................................25

Power supply problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

BIOS crisis recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

POST error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Undetermined problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Contents

iii

Hardware Maintenance Manual

Chapter 7. Replacing hardware ............................................33

General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Replacing the hard disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Removing the cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Replacing the front bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Removing the fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Replacing the memory module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Replacing the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Replacing the system board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Replacing the power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Completing the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 8. Additional service information .............................55

Power management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Appendix. Statement ............................................................57

This manual contains service and reference information for Lenovo IdeaCentre

A computers listed on the cover. It is intended only for trained servicers who are

familiar with Lenovo computer products.

Before servicing a Lenovo product, be sure to read the Safety Information.

This manual includes a complete FRU part number listing for each machine

type and model listed on the cover. If you have internet access, FRU part

numbers are also available at: http://consumersupport.lenovo.com.

The description of the TV card in this manual is only used for the machines

which have the TV card. It is invalid for those machines which do not have TV

card.

Important safety information

Be sure to read all caution and danger statements in this book before

performing any of the instructions.

Veuillez lire toutes les consignes de type DANGER et ATTENTION du présent

document avant d’exécuter les instructions.

Lesen Sie unbedingt alle Hinweise vom Typ “ACHTUNG” oder “VORSICHT” in

dieser Dokumentation, bevor Sie irgendwelche Vorgänge durchführen

Leggere le istruzioni introdotte da ATTENZIONE e PERICOLO presenti nel

manuale prima di eseguire una qualsiasi delle istruzioni

Certifique-se de ler todas as instruções de cuidado e perigo neste manual antes

de executar qualquer uma das instruções

Es importante que lea todas las declaraciones de precaución y de peligro de

este manual antes de seguir las instrucciones.

About this manual

Chapter 1. About this manual

Using eSupport

For Key Commodities (Examples - hard disk drive, system board,

microprocessor, LCD, and memory)

• eSupport can be used to view the list of key commodities built in a particular

machine serial.

• eSupport can be accessed at the following Web site:

http://consumersupport.lenovo.com

• To view the key commodities:

1. Click Parts information.

2. Under Parts information, click Parts lookup.

3. Under Parts lookup, type the model type and serial number; then click

Continue.

The key commodities are returned in the eSupport record under Parts

shipped with your system.

For the remaining FRUs (the complete list of FRUs at the MT Model level)

• eSupport can be used to view the complete list of FRUs for a machine type

and model.

• To view the complete list of FRUs for a machine type:

1. Point your browser to http://consumersupport.lenovo.com.

2. Type the machine type (Example: 8129) in the Use Quick Path field; then

click Go.

3. Under Browse by product, click Continue.

4. Under Important information, click Parts information.

5. In the Refine results field, select Service parts; then click the entry for

your machine type.

The list of service parts by description, with applicable machine type

model and FRU part number is displayed.

Important information about replacing RoHS compliant

FRUs

RoHS, The Restriction of Hazardous Substances in Electrical and Electronic

Equipment Directive (2002/95/EC) is a European Union legal requirement

affecting the global electronics industry. RoHS requirements must be

implemented on Lenovo products placed on the market after June 2006.

Products on the market before June 2006 are not required to have RoHS

compliant parts.

Hardware Maintenance Manual

So, if the parts are not compliant originally, replacement parts can also be

noncompliant, but in all cases, if the parts are compliant, the replacement parts

must also be compliant.

Lenovo plans to transition to RoHS compliance well before the implementation

date and expects its suppliers to be ready to support Lenovo’s requirements

and schedule. Products sold in 2005, will contain some RoHS compliant FRUs.

The following statement pertains to these products and any product Lenovo

produces containing RoHS compliant parts.

RoHS compliant Lenovo IdeaCentre A parts have unique FRU part numbers.

Before or after June, 2006, failed RoHS compliant parts must always be

replaced using RoHS compliant FRUs, so only the FRUs identified as compliant

in the system HMM or direct substitutions for those FRUs can be used.

Note: A direct substitution is a part with a different FRU part number that is

automatically shipped by the distribution center at the time of order.

Related Web URLs are:

• Lenovo information for Suppliers website:

http://www-03.ibm.com/procurement/proweb.nsf/

ContentDocsByTitle/United+States~Information+for+suppliers

•RoHSDirective:

http://europa.eu.int/eur-lex/pri/en/oj/dat/2003/l_037/

l_03720030213en00190023.pdf

• California Senate Bills 20, 50:

http://www.ciwmb.ca.gov/HHW/Events/AnnualConf/2004/presentation/

MPaparian.pdf

Products marketed before June 2006 Products marketed after June 2006

Current or original

part Replacement FRU Current or original

part Replacement FRU

Non-RoHS Can be Non-RoHS Must be RoHS Must be RoHS

Non-RoHS Can be RoHS

Non-RoHS Can sub to RoHS

RoHS Must be RoHS

Chapter 1. About this manual

This chapter contains the safety information that you need to be familiar with

before servicing a computer.

General safety

Follow these rules to ensure general safety:

• Observe good housekeeping in the area of the machines during and after

maintenance.

• When lifting any heavy object:

1. Ensure you can stand safely without slipping.

2. Distribute the weight of the object equally between your feet.

3. Use a slow lifting force. Never move suddenly or twist when you attempt

to lift.

4. Lift by standing or by pushing up with your leg muscles; this action

removes the strain from the muscles in your back. Do not attempt to lift

any objects that weigh more than 16 kg (35 lb) or objects that you think

are too heavy for you.

• Do not perform any action that causes hazards to the customer, or that

makes the equipment unsafe.

• Before you start the machine, ensure that other service representatives and

the customer’s personnel are not in a hazardous position.

• Place removed covers and other parts in a safe place, away from all

personnel, while you are servicing the machine.

• Keep your tool case away from walk areas so that other people will not trip

over it.

• Do not wear loose clothing that can be trapped in the moving parts of a

machine. Ensure that your sleeves are fastened or rolled up above your

elbows. If your hair is long, fasten it.

• Insert the ends of your necktie or scarf inside clothing or fasten it with a

nonconductive clip, approximately 8 centimeters (3 inches) from the end.

• Do not wear jewelry, chains, metal-frame eyeglasses, or metal fasteners for

your clothing.

Safety information
