Lightolier Lytespan 6298 Manuale utente

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lytespan®Track Lighting 6298

Page 1 of 2 GeoStar™ Electronic

Features

Compact Lytespot®with unique rounded back ﬁts close to ceiling, integrates

easily with most decor. Uses to wide range of MR-16 lamps to provide precisely

controlled beam spreads from narrow to wide. Lamp is deeply regressed to

eliminate glare. Die-cast matte black step bafe supports lamp and protective

glass lamp guard. Complete bafe/lamp assembly pulls out; spring-tension clips

allow fast snap-out, snap-in relamping. Unit adjusts horizontally and vertically

up to 90° for each side. May be used with color lter, spread lens and framing

projector accessories.

Finish

All painted ﬁnished baked enamel.

Electrical

Light-weight, electronic, low voltage transformer with integral radio frequency

interference lter; soft-start feature for longer lamp life. Constant output lamp

voltage to maintain rated lamp life and light output. Two-pin base socket, pre-

wired with No. 18 braided SF-1 leads with berglass braided outer sleeve.

Dimming

For Dimming control, use only those dimmers speciﬁcally designed for use with

electronic transformers like Lightolier’s Sunrise and Neptune Momentum QE

series. Call (800) 526-2731 for further information.

PUSH TAB: Molded

Polycarbonate detaches unit.

LYTESPAN ATTACHMENT FITTING: Die-Cast aluminum.

Fitter twists onto track and locks on.

PIVOT MOUNTING:

Tensioned; 90° horizontal

stop for each side.

HOUSING: .040"

Aluminum.

LAMP GUARD

TRUNION MOUNTING:

Tensioned, provides 90°

vertical adjustment for

lighting unit.

STEP BAFFLE:

Die-Cast aluminum with stepped conical

surface for low brightness. Matte black ﬁnish.

6 13/16"

2 5/8"Sq.

4" Max 3 1/4"

FRAMING PROJECTOR

ACCESSORY

(Order Separately)

6 1/2"

4 3/16"

MOVABLE BRASS

CONTACT: Extends

for connection to 2nd circuit

in Advent Lytespan Track.

POLARITY KEYWAY

Catalog No. Finishes Track Mounting Lamps Accessories (order separately)

6298 Matte White

All Lytespan Track Systems 35W or 37W Max IR

MR-16 12V

2" Series Color Filters, Louver, Spread Lens

(See Lightolier Specication Sheet 7472.

6299 Matte Black

6297 Matte Black Framing Projector (For performance data see Lightolier Specication Sheet 6497)

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Lytespan®Track Lighting 6298

Page 2 of 2 GeoStar™ Electronic

3,750 5,000

20W MR16 NSP

15ϒ

6’ 104 1.6’ 1.6’

8’ 59 2.1’ 2.1’

10’ 38 2.6’ 2.6’

12’ 26 3.2’ 3.2’

5.’ 2.9’ 97 1.8’ 1.5’

7’ 4.0’ 50 2.5’ 2.1’

9’ 5.2’ 30 3.2’ 2.7’

11’ 6.4’ 20 3.9’ 3.3’

3’ 3.0’ 147 1.6’ 1.1’

5’ 5.0’ 53 2.7’ 1.9’

7’ 7.0’ 27 3.8’ 2.6’

9’ 9.0’ 16 4.8’ 3.4’

2’ 3.5’ 117 2.2’ 1.1’

3’ 5.2’ 52 3.3’ 1.6’

4’ 6.9’ 29 4.4’ 2.1’

5’ 8.7’ 19 5.6’ 2.6’

7’ 151 0.9’ 0.9’

10’ 74 1.2’ 1.2’

13’ 44 1.6’ 1.6’

16’ 29 2.0’ 2.0’

6’ 3.5’ 134 1.0’ 0.8’

9’ 5.2’ 59 1.5’ 1.3’

12’ 6.9’ 33 2.0’ 1.7’

15’ 9.7’ 21 2.4’ 2.1’

4’ 4.0’ 164 1.0’ 0.7’

6’ 6.0’ 73 1.5’ 1.0’

8’ 8.0’ 41 2.0’ 1.4’

10’ 10.0’ 26 2.5’ 1.7’

2’ 3.5’ 231 1.0’ 0.5’

3’ 5.2’ 103 1.5’ 0.7’

4’ 6.9’ 58 2.0’ 1.0’

5’ 8.7’ 37 2.5’ 1.2’

7,400 3,000

20W MR16 VNSP

7ϒ

2’ 131 1.5’ 1.5’

3’ 58 2.2’ 2.2’

4’ 33 2.8’ 2.8’

5’ 21 3.6’ 3.6’

2’ 1.2’ 85 2.0’ 1.7’

3’ 1.7’ 38 3.0’ 2.5’

4’ 2.3’ 21 4.1’ 3.4’

5’ 2.9’ 14 5.1’ 4.2’

2’ 2.0’ 46 3.4’ 2.1’

3’ 3.0’ 21 5.0’ 3.1’

4’ 4.0’ 12 6.7’ 4.1’

5’ 5.0’ 7 8.4’ 5.1’

1’ 1.7’ 66 4.8’ 1.5’

2’ 3.5’ 16 9.7’ 2.9’

3’ 5.2’ 7 14.5’ 4.4’

4’ 6.9’ 4 19.3’ 5.8’

525 5,000

20W MR16 FL

40ϒ

DFCLWDC FC LW DC FC LW DC FC LW

2,800 4,000

35W MR16 SP

20ϒ

6’ 78 2.1’ 2.1’

8’ 44 2.8’ 2.8’

10’ 28 3.5’ 2.3’

12’ 19 4.2 4.2’

5’ 2.9’ 73 2.4’ 2.0’

7’ 4.0’ 37 3.3’ 2.9’

9’ 5.2’ 22 4.3’ 3.7’

11’ 6.4’ 15 5.2’ 4.5’

3’ 3.0’ 110 2.2’ 1.5’

5’ 5.0’ 40 3.6’ 2.5’

7’ 7.0’ 20 5.1’ 3.5’

9’ 9.0’ 12 6.6’ 4.5’

2’ 3.5’ 88 3.1’ 1.4’

3’ 5.2’ 39 4.7’ 2.1’

4’ 6.9’ 22 6.2’ 2.8’

5’ 8.7’ 14 7.8’ 3.5’

7’ 224 1.0’ 1.0’

10’ 110 1.4’ 1.4’

13’ 65 1.8’ 1.8’

16’ 43 2.2’ 2.2’

6’ 3.5’ 198 1.1’ 1.0’

9’ 5.2’ 88 1.7’ 1.5’

12’ 6.9’ 50 2.2’ 1.9’

15’ 8.7’ 32 2.8’ 2.4’

4’ 4.0’ 243 1.1’ 0.8’

6’ 6.0’ 108 1.7’ 1.2’

8’ 8.0’ 61 2.2’ 1.6’

10’ 10.0’ 48 2.5’ 1.8’

2’ 3.5’ 344 1.1’ 0.6’

3’ 5.2’ 153 1.7’ 0.8’

4’ 6.9’ 86 2.3’ 1.1’

5’ 8.7’ 55 2.8’ 1.4’

11,000 4,000

35W MR16 NSP

8°

4’ 88 2.9’ 2.9’

6’ 39 4.4’ 4.4’

8’ 22 5.8’ 5.8’

10’ 14 7.3’ 7.3’

3’ 1.7’ 101 3.0’ 2.5’

5’ 2.9’ 36 5.1’ 4.2’

7’ 4.0’ 19 7.1’ 5.9’

9’ 5.2’ 11 9.1’ 7.6’

3’ 3.0’ 55 5.0’ 3.1’

4’ 4.0’ 31 6.7’ 4.1’

5’ 5.0’ 20 8.4’ 5.1’

6’ 6.0’ 14 10.1’ 6.2’

1’ 1.7 175 4.8’ 1.5’

2’ 3.5’ 44 9.7’ 2.9’

3’ 5.2’ 19 14.5’ 4.4’

4’ 6.9’ 11 19.3’ 5.8’

1,400 4,000

35W MR16 FL

40ϒ

4,400 4,000

4’ 275 1.9’ 1.9’

6’ 122 2.9’ 2.9’

8’ 69 3.8’ 3.8’

10’ 44 4.8’ 4.8’

3’ 1.7’ 318 2.0’ 1.7’

5’ 2.9’ 114 3.3’ 2.8’

7’ 4.0’ 58 4.6’ 3.9’

9’ 5.2’ 35 5.9’ 5.0’

3’ 3.0’ 173 3.1’ 2.0’

4’ 4.0’ 97 4.1’ 2.7’

5’ 5.0’ 62 5.1’ 3.4’

6 ’ 6.0’ 43 6.1’ 4.1’

1’ 1.7’ 550 2.3’ 1.0’

2’ 3.5’ 138 4.8’ 1.9’

3’ 5.2’ 61 7.0’ 2.9’

4’ 6.9’ 34 9.3’ 3.8’

8’ 195 1.3’ 1.3’

12’ 87 1.9’ 1.9’

16’ 49 2.5’ 2.5’

20’ 31 3.1’ 3.1’

7’ 4.0’ 166 1.5’ 1.3’

10’ 5.8’ 81 2.1’ 1.8’

13’ 7.5’ 48 2.7’ 2.4’

16’ 9.2’ 32 3.4’ 2.9’

5’ 5.0’ 177 1.6’ 1.1’

7’ 7.0’ 90 2.2’ 1.6’

9’ 9.0’ 55 2.9’ 2.0’

11’ 11.0’ 37 3.5’ 2.4’

3’ 5.2’ 174 1.9’ 0.9’

4’ 6.9’ 98 2.6’ 1.3’

5’ 8.7’ 63 3.2’ 1.6’

6’ 10.4’ 43 3.8’ 1.9’

12,500 4,000

9°

25°

2,250 4,000

40ϒ

60ϒ

4’ 138 2.9’ 2.9’

6’ 61 4.4’ 4.4’

8’ 34 5.8’ 5.8’

10’ 22 7.3’ 7.3’

3’ 1.7’ 159 3.0’ 2.5’

5’ 2.9’ 57 5.1’ 4.2’

7’ 4.0’ 29 7.1’ 5.9’

9’ 5.2’ 18 9.1’ 7.8’

3’ 3.0’ 86 5.0’ 3.1’

4’ 4.0’ 49 6.7’ 4.1’

5’ 5.0’ 31 8.4’ 5.1’

6’ 6.0’ 22 10.1’ 6.2’

1’ 1.7’ 275 4.8’ 1.5’

2’ 3.5’ 69 9.7’ 2.9’

3’ 5.2’ 31 14.5’ 4.4’

4’ 8.9’ 17 19.3’ 5.8’

3’ 128 3.1’ 3.1’

5’ 48 5.2’ 5.2’

7’ 23 7.3’ 7.3’

9’ 14 9.4’ 9.4’

3’ 1.7’ 83 4.6’ 3.6’

5’ 2.9’ 30 7.6’ 6.0’

7’ 4.0’ 15 10.7’ 8.4’

9’ 5.2’ 9 13.7’ 10.8’

2’ 2.0’ 102 5.7’ 2.9’

3’ 3.0’ 45 8.6’ 4.4’

4’ 4.0’ 25 11.4’ 5.9’

5’ 5.0’ 16 14.3’ 7.4’

1’ 1.7’ 144 22.3’ 2.1’

2’ 3.5’ 36 44.5’ 4.2’

3’ 5.2’ 16 66.8’ 6.2’

4’ 6.9’ 9 89.1’ 8.3’

1,100 4,000

37W MR16 VNSP

(I.R.)

37W MR16 NFL

(I.R.)

37W MR16 FL

(I.R.)

37W MR16 WLF

(I.R.)

Rated

Life-Hrs

Beam Center

C.P. Candelas

Beam Spread

50% Max. CP

Lighting Data

DFC L

Lamp 0° Aiming Angle A=30° Aiming Angle A=45° Aiming Angle A=60° Aiming Angle

Aiming Angle 0° 30°, 45° or 60° Horizontal 30°, 45° or 60° Vertical

L Beam Length

W Beam Width

CDistance to center beam

D Distance

A Aiming Angle

FC Footcandles

Land Ware the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.
