Linn MAJIK 112 Manuale utente

MAJIK 112

CENTRE CHANNEL LOUDSPEAKER

OWNER’S MANUAL

Explanation of symbols used in this manual or on the rear/underside of the

apparatus:

This symbol is intended to alert the user to the presence of uninsulated

dangerous voltages within the enclosure of sufﬁcient magnitude to

cause electric shock.

This symbol is intended to alert the user to the presence of important

operation, maintenance and servicing information in the instruction

and service manuals.

For apparatus connected to the mains electricity supply

CAUTION

• To reduce the risk of electric shock do not remove the cover.

• No user serviceable parts inside.

• Refer servicing to qualiﬁed service personnel.

• Replace the mains fuse in the plug with one of the same type

and rating.

• Disconnect supply cord before changing fuse.

WARNING

To reduce the risk of ﬁre or electric shock do not expose this apparatus to

rain or moisture. Shock hazard - do not open.

IMPORTANT SAFETY INSTRUCTIONS

Majik 112

General Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use the apparatus near water, for example near a bathtub, washbowl,

kitchen sink, laundry tub, in a wet basement, near a swimming pool etc.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions. Site the apparatus so that its location or position

does not interfere with its proper ventilation. For example, the apparatus should

not be situated on a bed, sofa, rug, or similar surface that may block the ventilation

openings, or placed in a built in installation such as a bookcase or cabinet that may

impede the ﬂow of air through the ventilation openings.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarised or grounding type plug.

A polarised plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade or the third prong

is provided for your safety. If the provided plug does not ﬁt into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and at the point where they exit from the

apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with the stand, tripod, bracket, or table speciﬁed by the

manufacturer, or sold with the apparatus.

13. Unplug this apparatus during lightning storms or when unused for long

periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug has

been damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or has

been dropped.

15. Wall or ceiling mounting. Mount the apparatus to a wall or ceiling

only as recommended by the manufacturer.

16. Power sources. Connect the apparatus to a power supply only of the type

described in the operating instructions or marked on the apparatus.

17. Mains plug. Use the mains plug to disconnect the apparatus from the mains

supply. The mains plug must be accessible at all times. Use the mains switch (if

applicable) when the apparatus is not in use.

18. Power lines. An outdoor antenna should be located away from power lines.

19. Outdoor antenna grounding. If an outdoor antenna is connected to the

apparatus, ensure that the antenna system is grounded to provide some protection

against voltage surges and static build up. In the USA see article 810 of the National

Electrical Code ANSI/NFPA 70 concerning installation requirements.

20. Telephone line. Do not connect the apparatus to a telephone line except where

speciﬁcally instructed to do so.

21. Objects and liquid entry. Do not let objects or liquids fall into the apparatus. Do

not expose the apparatus to dripping or splashing.

Do not place a vessel containing liquid on top of the apparatus.

22. No naked ﬂame sources, such as lighted candles, should be placed on the

apparatus.

23. The apparatus has been designed for use in moderate and tropical climates.

Majik 112

Linn Products Ltd declare that this product is in conformance with the Low Voltage

Directive 73/23/EEC and Electromagnetic Compatibility 89/336/EEC as amended

by 92/31/EEC and 93/68/EEC.

The conformity of the designated product with the provisions of Directive number

73/23/EEC (LVD) is proved by full compliance with the following standards:

Standard number Date of issue Test type

EN60065 2002 General requirements

Marking

Hazardous radiation

Heating under normal conditions

Shock hazards under normal

operating conditions

Insulation requirements

Fault conditions

Mechanical strength

Parts connected to the mains

supply

Components

Terminal devices

External ﬂexible cords

Electrical connections and

mechanical ﬁxings

Protection against electric shock

Stability and mechanical hazards

Resistance to ﬁre

The conformity of the designated product with the provisions of Directive number

89/336/EEC (EMC) is proved by full compliance with the following standards:

Standard number Date of issue Test type

EN55013 2001 Conducted emissions

EN55013 2001 Absorbed emissions

EN55020 2002 Immunity

CE Declaration of Conformity

iii

Majik 112

Note: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC notice

Majik 112

Waste Electrical and Electronic Equipment Directive Directive 2002/96/EC

of the European Parliament and of the Council

The symbol (right) is shown on this product. It indicates that the product

should not be disposed of with regular household waste, but should be

disposed of separately.

Electrical and electronic equipment can contain materials that are hazardous

to the environment and human health and therefore should be disposed of at a

designated waste facility or returned to your retailer for the appropriate recycling to

take place (see www.linn.co.uk for further information).

If you wish to dispose of this product and the product still functions, please

consider recycling/reusing it by donating it to a charity shop, selling it or part-

exchanging it with your retailer.

Waste Electrical and Electronic Equipment

(WEEE) Directive

Linn Products Limited, Glasgow Road, Waterfoot, Eaglesham, Glasgow,

G76 OEQ, Scotland, United Kingdom

a retrieval system, or transmitted, in any form or by any means, electronic,

mechanical, photocopying, recording, or otherwise, without the prior written

permission of the publisher.

The content of this manual is furnished for information use only, is subject to

change without notice, and should not be construed as a commitment by Linn

Products Limited. Linn Products Limited assumes no responsibility or liability for

any errors or inaccuracies that may appear in this manual.

Trade marks used in this publication: Linn and the Linn logo are registered

trade marks of Linn Products Limited. Majik and Aktiv are trade marks

of Linn Products Limited.

The information in this manual is furnished for informational use only, is subject to

change without notice, and should not be construed as a commitment by Linn

Products Limited. Linn Products Limited assumes no responsibility or liability for

any errors or inaccuracies that may appear in this manual.

UK Registered Design No: 4008705

Printed in the United Kingdom.

Pack 1520

INTRODUCTION 1

INSTALLATION 2

Unpacking 2

Cleaning 2

Accessories 2

Positioning and levelling 3

Positioning 3

Levelling 3

Connecting 4

General 4

Terminals 4

Conﬁguration options 5

Wiring and amping conﬁgurations 7

TECHNICAL SPECIFICATIONS 9

GUARANTEE AND SERVICE 10

CONTENTS

Majik 112

The Linn Majik 112 full-range centre channel loudspeaker is a unique and

innovative design that builds on thirty years’ experience of loudspeaker

design and manufacture. Majik 112 features Linn’s patented driver array

technology found in our highest performing loudspeakers and a single

bass driver system with matching front-ﬁring bass reﬂex. This combination

delivers complete clarity in high frequency reproduction and a clean and

even dispersion across all frequencies, ideal qualities for a centre channel

loudspeaker.

Majik 112 is the perfect centre channel solution for surround sound

home cinema or multi-channel audio, and completes the Linn Majik

range of loudspeakers. Match Majik loudspeakers with the Majik range of

componenents for an investment in genuine specialist performance.

INTRODUCTION

Majik 112

Unpacking

The Majik 112 loudspeaker comes carefully packaged; take care when removing it

from the packaging to avoid damage to the cabinet. Do not lay the loudspeaker on

its face as this will damage the 2K driver array.

The Majik 112 loudspeaker is supplied with the following:

• Two input terminal link strips (factory ﬁtted to the loudspeaker)

• Two ‘banana’ 4mm plugs (one red, one black)

• An input terminal spanner

We recommend that you retain the packaging in case you need to transport your

loudspeaker at a later date.

INSTALLATION

Cleaning

Remove dust and ﬁngerprints from the cabinet with a soft, dry, lint-free cloth.

Avoid using domestic cleaning products as they may damage the veneer.

Majik 112
